2009 MAZDA MODEL B4000 CAB PLUS 4 TRUCK Owners Manual

Speedometer:Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool.
Refer to Engine coolant in theMaintenance and Specifications
chapter.
WARNING: Never remove the coolant reservoir cap and/or the
radiator cap while the engine is running or hot, this may result
in serious burns.
Odometer: Registers the total miles
(kilometers) of the vehicle.
Trip odometer: Registers the miles
(kilometers) of individual journeys.
Press the button once until “TRIP”
appears in the display (this
represents the trip mode). To reset
the trip, press and hold the control
again for approximately two
seconds, until the trip reading is 0.0 miles (kilometers). To toggle
between trip and odometer, press and release the control.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Instrument Cluster
17

AUDIO SYSTEMS
AM/FM stereo (if equipped)
WARNING:Driving while distracted can result in loss of vehicle
control, accident and injury. Mazda strongly recommends that
drivers use extreme caution when using any device that may take their
focus off the road. The driver’s primary responsibility is the safe
operation of their vehicle. Only use cell phones and other devices not
essential to the driving task when it is safe to do so.
1. Seek: Press
/to find
the next strong station down/up
the frequency band.
2. Tune: Press
/to
manually change radio
frequency down/up.
1234AM/FM
SEEKTONE
CLK
TUNE
TONE VOL
12 FMSTDX
VOL
PUSH ON
5
3
67
4
12
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Entertainment Systems
19

AM/FM stereo single CD/MP3 Satellite Compatible system
(if equipped)
WARNING:Driving while
distracted can result in loss
of vehicle control, accident and
injury. Mazda strongly
recommends that drivers use
extreme caution when using any
device that may take their focus
off the road. The driver’s primary
responsibility is the safe operation
of their vehicle. Only use cell
phones and other devices not
essential to the driving task when
it is safe to do so.
1. CD eject: Press to eject the CD.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Entertainment Systems
21
