2009 INFINITI QX56 torque

DLN-178
< DISASSEMBLY AND ASSEMBLY >[ATX14B]
TRANSFER ASSEMBLY
7. Install the rear case to the center case. Tighten the bolts to the
specified torque. Refer to DLN-142, "Disassembly and Assem-
bly".
SDIA2092E
Revision: December 20092009 QX56

DLN-184
< SYMPTOM DIAGNOSIS >[PROPELLER SHAFT: 2F1310]
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000003772204
Use the chart below to help you find the cause of the sy mptom. If necessary, repair or replace these parts.
×: ApplicableReference page
DLN-185, "On-Vehicle Service"DLN-185, "On-Vehicle Service"DLN-185, "On-Vehicle Service"
DLN-208, "NVH Troubleshooting Chart"RAX-5, "NVH Troubleshooting Chart"RSU-5, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"FAX-9, "Removal and Installation"BR-6, "NVH Troubleshooting Chart"ST-12, "NVH Troubleshooting Chart"
Possible cause and suspected parts
Uneven rotation torque
Rotation imbalance
Excessive run out
Differential
Axle
Suspension
Tires
Road wheel
Drive shaft
Brakes
Steering
Symptom
Noise
×××××××××××
Shake ×××××××
Vibration ××××××××
Revision: December 20092009 QX56

DLN-194
< SYMPTOM DIAGNOSIS >[PROPELLER SHAFT: 2S1410]
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000003772211
Use the chart below to help you find the cause of the sy mptom. If necessary, repair or replace these parts.
×: ApplicableReference page
DLN-195, "On-Vehicle Service"DLN-195, "On-Vehicle Service"DLN-195, "On-Vehicle Service"
DLN-242, "NVH Troubleshooting Chart"RAX-5, "NVH Troubleshooting Chart"RSU-5, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"

RAX-5, "NVH Troubleshooting Chart"
BR-6, "NVH Troubleshooting Chart"ST-12, "NVH Troubleshooting Chart"
Possible cause and suspected parts
Uneven rotation torque
Rotation imbalance
Excessive run out
Differential
Axle
Suspension
Tires
Road wheel
Drive shaft
Brakes
Steering
Symptom Noise
×××××××××××
Shake ×××××××
Vibration ××××××××
Revision: December 20092009 QX56

DLN-204
< PRECAUTION >[FRONT FINAL DRIVE: M205]
PRECAUTIONS
5. When the repair work is completed, return the ignition switch to the
″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of a ll control units using CONSULT-III.
Precaution for Servicing Front Final DriveINFOID:0000000004193536
 Before starting diagnosis of the vehicle, understand the symptoms well. Perform correct and systematic
operations.
 Check for the correct installation status prior to re moval or disassembly. When matching marks are required,
be certain they do not interfere with the f unction of the parts they are applied to.
 Overhaul should be done in a clean work area, a dust proof area is recommended.
 Before disassembly, completely remove sand and mud from the exterior of the unit, preventing them from
entering into the unit during disassembly or assembly.
 Always use shop paper for cleaning the inside of components.
 Avoid using cotton gloves or a shop cloth to prevent the entering of lint.
 Check appearance of the disassembled parts for dam age, deformation, and abnormal wear. Replace them
with new ones if necessary.
 Gaskets, seals and O-rings should be replaced any time the unit is disassembled.
 Clean and flush the parts sufficiently and blow them dry.
 Be careful not to damage sliding surfaces and mating surfaces.
 When applying sealant, remove the old sealant from the mating surface; then remove any moisture, oil, and
foreign materials from the application and mating surfaces.
 In principle, tighten nuts or bolts gradually in severa l steps working diagonally from inside to outside. If a
tightening sequence is specified, observe it.
 During assembly, observe the specified tightening torque.
 Add new differential gear oil, petroleum jelly, or multi-purpose grease, as specified.
Revision: December 20092009 QX56

DLN-206
< PREPARATION >[FRONT FINAL DRIVE: M205]
PREPARATION
KV40104810
(—)
Drift Installing drive pinion front bearing outer
race.
a: 68 mm (2.68 in) dia.
b: 55 mm (2.17 in) dia.
KV38102200
(—)
Drift Installing front oil seal.
a: 55.3 mm (2.18 in) dia
.
b: 90 mm (3.54 in) dia.
ST33081000
(—)
Adapter Removing and installing side bearing inner
race.
a: 43 mm (1.69 in) dia
.
b: 33.5 mm (1.32 in) dia.
ST3127S000
(J-25765-A)
Preload gauge
1. GG91030000
(J-25765)
Torque wrench
2. HT62940000
( — )
Socket adapter (1/2 ″)
3. HT62900000
( — )
Socket adapter (3/8 ″) Inspecting drive pinion bearing preload and
total preload
—
(C-4040)
Installer Installing drive pinion rear bearing inner race.
KV40105230
(—)
Drift Installing drive pinion rear bearing outer race.
a: 92 mm (3.62 in) dia.
Tool number
(Kent-Moore No.)
Tool name
Description
ZZA1003D
NT660
ZZA1000D
NT124
SDIA2607E
ZZA0898D
Revision: December 20092009 QX56

DIFFERENTIAL GEAR OILDLN-209
< ON-VEHICLE MAINTENANCE > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE MAINTENANCE
DIFFERENTIAL GEAR OIL
Changing Differential Gear OilINFOID:0000000004193540
DRAINING
1. Stop the engine.
2. Remove the drain plug from the front final drive assembly to drain the differential gear oil.
3. Install the drain plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer to DLN-217, "Disassembly and Assembly"
.
 Use High Performance Thread Sealant or equivalent. Refer to GI-15, "Recommended Chemical Prod-
ucts and Sealants".
FILLING
1. Remove the filler plug from the front final drive assembly.
2. Fill the front final drive assembly with new differential gear oil
until the level reaches the specified level near the filler plug hole.
3. Install the filler plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer
to DLN-217, "Disassembly and Assembly"
.
 Use High Performance Thread Sealant or equivalent. Refer to GI-15, "Recommended Chemical Products and Sealants"
.
Checking Differential Gear OilINFOID:0000000004193541
DIFFERENTIAL GEAR OIL LEAKAGE AND LEVEL
1. Make sure that differential gear oil is not leaki ng from the front final drive assembly or around it.
2. Check the differential gear oil level from the filler plug hole as shown.
CAUTION:
Do not start engine while checki ng differential gear oil level.
3. Install the filler plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer
to DLN-217, "Disassembly and Assembly"
.
 Use High Performance Thread Sealant or equivalent. Refer to GI-15, "Recommended Chemical Products and Sealants"
.
Differential gear oil
grade and capacity
: Refer to
MA-12, "Fluids
and Lubricants".
LDIA0176E
LDIA0176E
Revision: December 20092009 QX56

FRONT OIL SEALDLN-211
< ON-VEHICLE REPAIR > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
FRONT OIL SEAL
Removal and InstallationINFOID:0000000005875037
REMOVAL
1. Remove the drive shafts from the front final drive assembly. Refer to FAX-9, "Removal and Installation".
2. Remove the front propeller shaft from the front final drive assembly. Refer to DLN-186, "Removal and
Installation".
3. Measure the total preload torque. Refer to DLN-234, "General Specification"
.
NOTE:
Record the total preload torque measurement.
4. Remove the drive pinion lock nut using suitable tool.
5. Put matching marks on the companion flange and drive pinion using paint. CAUTION:
Use paint to make the matching marks. Do not da mage the companion flange or drive pinion.
6. Remove companion flange using suitable tool.
7. Place a small hole in the front oil seal case using suitable tool.
BDIA0001E
LDIA0171E
LDIA0129E
Revision: December 20092009 QX56

DLN-212
< ON-VEHICLE REPAIR >[FRONT FINAL DRIVE: M205]
FRONT OIL SEAL
8. Remove the front oil seal using Tool as shown.
INSTALLATION
1. Apply multi-purpose grease to the lips of the new front oil seal.
Then drive the new front oil seal in evenly to the gear carrier
using Tool.
CAUTION:
 Do not reuse front oil seal.
 Do not incline the new fron t oil seal when installing.
 Apply multi-purpose grease to the lips of the new front oil seal.
2. Install the companion flange to the drive pinion while aligning the matching marks.
3. Apply anti-corrosive oil to the threads of the drive pinion and the seating surface of the new drive pinion lock nut. Then adjust the
drive pinion lock nut tightening torque using suitable tool A, and
check the total preload torque using Tool B.
 The total preload torque should be within the total preload
torque specification. When not replacing the collapsible
spacer, it should also be equal to the measurement taken dur-
ing removal plus an additional 0.56 N·m (0.06 Kg-m, 5 in-lb).
 If the total preload torque is low, tighten the drive pinion lock nut in 6.8 N·m (0.69 Kg-m, 5ft-lb) increments until the total pre-
load torque is met.
CAUTION:
 Do not reuse drive pinion lock nut.
 Apply anti-corrosive oil to th e threads of the drive pinion
and the seating surface of the new drive pinion lock nut.
 Adjust the drive pinion lock nut tightening torque to the
lower limit first. Do not exceed the drive pinion lock nut
specified torque. Refer to DLN-217, "Disassembly and
Assembly".
 Do not loosen drive pinion lock nut to adjust the total preload torque. If the drive pinion lock nut
torque or the total preload torque exceeds the sp ecifications, replace the collapsible spacer and
tighten it again to adjust. Refer to DLN-217, "Disassembly and Assembly"
.
 After adjustment, rotate drive pinion back and fo rth 2 to 3 times to check for unusual noise, rota-
tion malfunction, and other malfunctions.
4. Installation of the remaining components is in the reverse order of removal. CAUTION:Tool number : SP8P
LDIA0130E
Tool number : KV38100500 (J-25273)
: KV38102200 ( — )
BDIA0003E
Tool number B: ST3127S000 (J-25765-A)
Total preload torque: Refer to DLN-234, "General
Specification".
WDIA0381E
