FRONT WIPER AND WASHER SYSTEMWW-5
< FUNCTION DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
• BCM transmits the front wiper request signal (INT) to IPDM E/R with CAN communication according to the
front wiper INT operation condition and the intermittent operation delay interval judged value.
Front wiper INT operating condition- Ignition switch ON
- Front wiper switch INT
Intermittent operation delay interval judgment- BCM calculates the intermittent operation delay inte rval from the vehicle speed signal received from the
wiper dial position and the combination meter with CAN communication.
• IPDM E/R turns the integrated front wiper relay ON so that the front wiper is operated only once according to the front wiper request signal (INT).
• BCM detects stop position/except st op position of the front wiper motor according to the front wiper stop
position signal received from IP DM E/R with CAN communication.
• BCM transmits the front wiper request signal (INT) again after the intermittent operation delay interval after the front wiper motor is stopped.
FRONT WIPER AUTO STOP OPERATION
• BCM stops transmitting the front wiper request si gnal when the front wiper switch is turned OFF.
• IPDM E/R detects the front wiper auto stop signal fr om the front wiper motor and detects the front wiper
motor position (stop positi on/except stop position).
Wiper intermittent dial posi-
tion Intermittent
operation interval Intermittent operation delay Interval (s)
Vehicle speed
Vehicle stopped or less than 5 km/h (3.1 MPH) 5 km/h (3.1 MPH)
or more or less
than 35 km/h (21.7 MPH) 35 km/h (21.7
MPH) or more or
less than 65 km/h (40.4 MPH) 65 km/h (40.4
MPH) or more
1S hort
↑
↓
Long 0.8
0.60.40.24
2 4321 .2
31 07.5 5 3
41 612 84.8
5 241 8127.2
6 322 4169.6
7 423 1.52 11 2.6
JPLIA0094GB
Revision: December 20092009 QX56

WW-6
< FUNCTION DIAGNOSIS >
FRONT WIPER AND WASHER SYSTEM
• When the front wiper request signal is stopped, IPDM E/R turns ON the front wiper relay until the front wiper
motor returns to the stop position.
NOTE:
• BCM stops the transmitting of the front wiper request signal when the ignition switch is OFF.
• IPDM E/R turns the front wiper relay OFF when the ignition switch is OFF.
FRONT WIPER OPERATION LINKED WITH WASHER
• BCM transmits the front wiper request signal (LO) to IPDM E/R with CAN communication according to the
washer linked operating condition of the front wiper.
• BCM transmits the front wiper request signal (LO) so that the front wiper operates approximately 3 times when the front washer s witch OFF is detected.
Washer linked operating condition of front wiper
- Ignition switch ON
- Front washer switch ON (0.4 second or more)
• IPDM E/R turns ON the integrated front wiper rela y according to the front wiper request signal (LO).
• The front and rear washer motor is grounded through the combination switch with the front washer switch
ON.
FRONT WIPER DROP WIPE OPERATION
• BCM controls the front wiper to operate once accordi ng to the conditions of front wiper drop wipe operation.
Front wiper drop wipe operating condition- Ignition switch ON
- Front wiper switch OFF
- Front washer switch OFF
• BCM transmits the front wiper request signal (LO) to IPDM E/R with CAN communication so that the front
wiper operate once three seconds after front wiper operation linked with washer.
• IPDM E/R turns ON the integrated front wiper rela y according to the front wiper request signal (LO).
FRONT WIPER FAIL−SAFE OPERATION
• IPDM E/R performs the fail-safe function when the front wiper auto stop circuit is malfunctioning. Refer to
WW-64, "
FailSafe".
JPLIA0095GB
Revision: December 20092009 QX56

FRONT WIPER AND WASHER SYSTEMWW-7
< FUNCTION DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Component Parts LocationINFOID:0000000004115468
Component DescriptionINFOID:0000000003776279
1. IPDM E/R E121, E122, E124 2. Air cleaner case 3. Front and rear washer motor E105
4. Washer fluid reservoir 5. Front wiper motor E23
(view with cowl top removed) 6. Combination switch M28
7. BCM M18, M20
ALLIA0841ZZ
Part Description
BCM • Judges each switch status by the combination switch reading function.
• Requests (with CAN communication) the front wiper relay and the front wiper high relay ON to
IPDM E/R.
IPDM E/R • Controls the integrated relay according to the request (with CAN communication) from BCM.
• Performs the auto stop control of the front wiper.
Combination switch
(Wiper and washer
switch) Refer to WW-4, "
System Diagram".
Combination meter Transmits the vehicle speed signal to BCM with CAN communication.
