2009 INFINITI QX56 Abs

LAN-46
< FUNCTION DIAGNOSIS >[CAN]
CAN COMMUNICATION SYSTEM
NOTE:
CAN data of the air bag diagnosis sensor unit is not us
ed by usual service work, thus it is omitted.
Tire pressure data signal R T
Tire pressure signal R TR
Turn indicator signal TR
Buzzer output signal TR
Door lock/unlock request signal RT
Hazard request signal RT
Hazard warning lamp request signal RT
Ignition knob switch signal RT
KEY warning signal TR
LOCK warning signal TR
Panic alarm request signal RT
Power window open request signal RT
1st position switch signal R T
4th position switch signal R T
Distance to empty signal RT
Fuel level low warning signal RT
Fuel level sensor signal R T
Parking brake switch signal RT
Seat belt buckle switch signal RT
Stop lamp switch signal R T
Tow mode switch signal R T
Vehicle speed signal RRR RRR R T
RRRT
Steering angle sensor signal TR
ABS malfunction signal RT
ABS warning lamp signal RT
Brake pressure sensor signal RT
Brake warning lamp signal RT
SLIP indicator lamp signal RT
TCS malfunction signal RT
VDC malfunction signal RT
VDC OFF indicator lamp signal RRT
VDC operation signal RT
Front wiper stop position signal RT
High beam status signal R T
Hood switch signal RT
Low beam status signal R T
Rear window defogger control signal R RT
Signal name/Connecting unit
ECM
TCM
LASER ICC
ADP
AV
BCM
HVAC I-KEY M&A
STRG 4WDABS
IPDM-E
Revision: December 20092009 QX56

LAN
TROUBLE DIAGNOSISLAN-47
< FUNCTION DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
TROUBLE DIAGNOSIS
CAN Diagnostic Support MonitorINFOID:0000000003776455
Use “CAN DIAG SUPPORT MNTR” for detecting the root cause.
MONITOR ITEM LIST (CONSULT-III)
ECM
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF→
ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
TCM
NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.
ICC Unit
NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.
ITEMCAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
ECM TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
VDC/TCS/ABS
Signal receivin
g status from the ABS actua-
tor and electric unit (control unit)
METER/M&A Signal receiving status from the combina-
tion meter
BCM/SEC Signal receiving status from the BCM
ICC Signal receiving status from the ICC unit
HVAC Not used even though indicated
TCM Signal receiving status from the TCM OKOK
or
1 – 39
*UNKWN 0
EPS Not used even though indicated
IPDM E/R Signal receiving status from the IPDM E/R OK OK
or
1 – 39
*UNKWN 0
e4WD Not used even though indicated
AWD/4WD Signal receiving status from the transfer
control unit OKOK
or
1 – 39
*UNKWN 0
ITEM CAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
TCM INITIAL DIAG Status of CAN controller
OKNG
TRANSMIT DIAG Signal transmission status
UNKWN
ECM Signal receiving status from the ECM
VDC/TCS/ABS
Signal receiving status from the ABS
actuator and electric unit (con-
trol unit)
METER/M&A Signal receiving status from the combination meter
ICC/e4WD Signal receiving status from the ICC unit
AWD/4WD Signal receiving status from the transfer control unit
Revision: December 20092009 QX56

LAN-48
< FUNCTION DIAGNOSIS >[CAN]
TROUBLE DIAGNOSIS
Driver Seat Control Unit
0: Error at present, 1 – 39: Error in the past (Number m
eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
AV Control Unit
0: Error at present, 1 – 39: Error in the past (Number m eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
BCM
ITEM CAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
ICC INITIAL DIAG Status of CAN controller
OKNG
TRANSMIT DIAG Signal transmission status
UNKWN
ECM
Signal receiving status from the ECM
VDC/TCS/ABS Signal receiving status from the ABS actuator and electric unit (con-
trol unit)
TCM Signal receiving status from the TCM
METER/M&A Not used even though indicated
LANE KEEP
ECM (l)
ICC SENSOR Signal receiving status from the ICC sensor OK UNKWN
STRG
Not used even though indicated
METER/M&A (l)
ERROR (l)
LANE DETEC-
TOR
TCM (l)
BCM/SEC Signal receiving status from the BCM
OK UNKWN
ITEMCAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
ADP TRANSMIT DIAG
Not used even though indicated
METER/M&A Signal receiving status from the combina-
tion meter
OKOK
or
1 – 39
*UNKWN 0
BCM/SEC Signal receiving status from the BCM
TCM Signal receiving status from the TCM
ITEMCAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
AV TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
METER/M&A Signal receiving status from the combina-
tion meter
BCM/SEC Signal receiving status from the BCM
HVAC Signal receiving status from the A/C auto
amp.
STRG Not used even though indicated
IPDM E/R Signal receiving status from the IPDM E/R OK OK
or
1 – 39
*UNKWN 0
TIRE-P Not used even though indicated
Revision: December 20092009 QX56

LAN
TROUBLE DIAGNOSISLAN-49
< FUNCTION DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.
A/C Auto Amp.
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF→
ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
Intelligent Key Unit
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF→ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
Combination Meter
ITEMCAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
BCM INITIAL DIAG Status of CAN controller
OKNG
TRANSMIT DIAG Signal transmission status
UNKWN
ECM Signal receiving status from the ECM
IPDM E/R Signal receiving status from the IPDM E/R
METER/M&A Signal receiving status from the combination meter
I-KEY Not used even though indicated
ITEM
CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
HVAC TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM Signal receiving status from the ECM
TCM Not used even though indicated
BCM/SEC Signal receiving status from the BCM OKOK
or
1 – 39
*UNKWN 0
VDC/TCS/ABS Signal receivin
g status from the ABS actua-
tor and electric unit (control unit)
IPDM E/R Not used even though indicated
DISPLAY Signal receiving status from the AV control
unit
OKOK
or
1 – 39
*UNKWN 0
I-KEY
Not used even though indicated
EPS
AWD/4WD
e4WD
ICC
LANE KEEP
TIRE-P
ITEM
CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
I-KEY TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
METER/M&A Signal receiving status from the combina-
tion meter
BCM/SEC Signal receiving status from the BCM
Revision: December 20092009 QX56

LAN-50
< FUNCTION DIAGNOSIS >[CAN]
TROUBLE DIAGNOSIS
0: Error at present, 1 – 39: Error in the past (Number m
eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
Transfer Control Unit
0: Error at present, 1 – 39: Error in the past (Number m eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
ABS Actuator and Electric Unit (Control Unit)
CAUTION:ITEM
CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
M&A TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
TCM Signal receiving status from the TCM
BCM/SEC Signal receiving status from the BCM
VDC/TCS/ABS Signal receiving stat
us from the ABS actua-
tor and electric unit (control unit)
IPDM E/R Signal receiving status from the IPDM E/R
DISPLAY Not used even though indicated
I-KEY Signal receiving status from the Intelligent
Key unit
OKOK
or
1 – 39
*UNKWN 0
EPS Not used even though indicated
AWD/4WD
e4WD
ICC Signal receiving status from the ICC unit OK OK
or
1 – 39
*UNKWN 0
LANE KEEP Not used even though indicated
TIRE-P
ITEM CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
4WD TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
VDC/TCS/ABS Signal receiving stat
us from the ABS actua-
tor and electric unit (control unit)
TCM Signal receiving status from the TCM
STRG Signal receiving status from the steering an-
gle sensor
ITEMCAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
ABS INITIAL DIAG Status of CAN controller
OKNG
Caution
TRANSMIT DIAG Signal transmission status
UNKWN
ECM Signal receiving status from the ECM
TCM Signal receiving status from the TCM
METER/M&A Not used even though indicated
STRG Signal receiving status from the steering angle sensor
OK UNKWN
ICC Signal receiving status from the ICC unit
AWD/4WD Signal receiving status from the transfer control unit
Revision: December 20092009 QX56

LAN-52
< COMPONENT DIAGNOSIS >[CAN]
CAN COMMUNICATION SYSTEM
COMPONENT DIAGNOSIS
CAN COMMUNICATION SYSTEM
Component Parts LocationINFOID:0000000003776457
1. ECM E16
2. IPDM E/R E122 3. ICC sensor E42
4. AV control unit M45 5. Combination meter M246. ABS actuator and electric unit (con-
trol unit) E125
7. Intelligent Key unit M70 8. BCM M189. Data link connector M22
10. Steering angle sensor M17 11. Driver seat control unit B202 12. ICC unit B13
13. Air bag diagnosis sensor unit M35 14. A/T assembly F9 15. A/C auto amp. M50
16. Transfer control unit E142
AWMIA0011ZZ
Revision: December 20092009 QX56

LAN-60
< COMPONENT DIAGNOSIS >[CAN]
MALFUNCTION AREA CHART
MALFUNCTION AREA CHART
Main LineINFOID:0000000003776459
Branch LineINFOID:0000000003776460
Short CircuitINFOID:0000000003776461
Malfunction Area
Reference
Main line between TCM and driver seat control unit LAN-61, "
Diagnosis Procedure"
Main line between TCM and ICC sensorLAN-63, "Diagnosis Procedure"
Main line between ICC sensor and ICC unitLAN-64, "Diagnosis Procedure"
Main line between ICC unit and driver seat control unitLAN-65, "Diagnosis Procedure"
Main line between driver seat control unit and AV control unitLAN-66, "Diagnosis Procedure"
Main line between AV control unit and data link connectorLAN-67, "Diagnosis Procedure"
Main line between data link connector and combination meterLAN-68, "Diagnosis Procedure"
Main line between combination meter and ABS actuator and
electric unit (control unit)LAN-69, "Diagnosis Procedure"
Malfunction Area
Reference
ECM branch line circuit LAN-70, "
Diagnosis Procedure"
TCM branch line circuitLAN-71, "Diagnosis Procedure"
ICC sensor branch line circuitLAN-72, "Diagnosis Procedure"
ICC unit branch line circuitLAN-73, "Diagnosis Procedure"
Driver seat control unit branch line circuitLAN-74, "Diagnosis Procedure"
AV control unit branch line circuitLAN-75, "Diagnosis Procedure"
BCM branch line circuit LAN-76, "Diagnosis Procedure"
Data link connector branch line circuit LAN-77, "Diagnosis Procedure"
A/C auto amp. branch line circuitLAN-78, "Diagnosis Procedure"
Intelligent Key unit branch line circuitLAN-79, "Diagnosis Procedure"
Combination meter branch line circuit LAN-80, "Diagnosis Procedure"
Steering angle sensor branch line circuit LAN-81, "Diagnosis Procedure"
Transfer control unit branch line circuit LAN-82, "Diagnosis Procedure"
ABS actuator and electric unit (control unit) branch line circuit LAN-83, "Diagnosis Procedure"
IPDM E/R branch line circuit LAN-84, "Diagnosis Procedure"
Malfunction Area Reference
CAN communication circuit LAN-85, "
Diagnosis Procedure"
Revision: December 20092009 QX56

LAN
MAIN LINE BETWEEN M&A AND ABS CIRCUITLAN-69
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
M&A AND ABS CIRCUIT
Diagnosis ProcedureINFOID:0000000003776469
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector M31
- Harness connector E152
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- Combination meter
- Harness connectors M31 and E152
2. Check the continuity between the combinati on meter harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the combination meter and the harness connector M31.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ABS actuat or and electric unit (control unit).
2. Check the continuity between the harness connector and the ABS actuator and electric unit (control unit)
harness connector.
Is the inspection result normal?
YES (Present error)>>Check the following items again. • Decision of CAN system type.
• Not received CONSULT-III data [SELF-DIAG RESULTS, CAN DIAG SUPPORT MNTR (“ECU
list” included)].
• Procedure for detecting root cause.
YES (Past error)>>Error was detected in the main line between the combination meter and the ABS actuator
and electric unit (control unit).
NO >> Repair the main line between the harness connec tor E152 and the ABS actuator and electric unit
(control unit).
Combination meter harness connector Harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
M24 10
M31 31G
Existed
11 42GExisted
Harness connector ABS actuator and electric unit (control unit)
harness connector Continuity
Connector No. Terminal No.Connector No. Terminal No.
E152 31G
E125 11
E x i s t e d
42G 15Existed
Revision: December 20092009 QX56
