2009 INFINITI QX56 engine

DLN-18
< FUNCTION DIAGNOSIS >[ATX14B]
DIAGNOSIS SYSTEM (T
RANSFER CONTROL UNIT)
DIAGNOSIS SYSTEM (TRA NSFER CONTROL UNIT)
CONSULT-III Function (ALL MODE AWD/4WD)INFOID:0000000003772079
FUNCTION
CONSULT-III can display each diagnostic item us ing the diagnostic test modes shown following.
SELF-DIAG RESULT MODE
Operation Procedure
1. Connect CONSULT-III.
2. With engine at idle, touch SELF-DIAG RESULTS.
Display shows malfunction experienced since the last erasing operation.
NOTE:
The details for TIME are as follows:
 0: Error currently detected with transfer control unit.
 Except for 0: Error detected in the pa st and memorized with transfer control unit.
Detects frequency of driving after DTC occurs (frequency of turning ignition switch ON/OFF).
How to Erase Self-d iagnostic Results
1. Perform applicable inspection of malfunctioning item and then repair or replace.
2. Start engine and select SELF-DIAG RESULTS m ode for ALL MODE AWD/4WD with CONSULT-III.
3. Touch ERASE on CONSULT-III screen to erase DTC memory. CAUTION:
If memory cannot be erased, pe rform applicable diagnosis.
SELF-DIAGNOSTIC PROCEDURE (WITHOUT CONSULT-III)
Description
If the engine starts when there is a malfunction in the 4W D system, the 4WD warning lamp turns ON or flickers
in the combination meter. When the system functions properly, the warning lamp turns ON when the ignition
switch is turned to ON, and it turns OFF after engine starts . To locate the cause of a malfunction, start the self-
diagnosis function. The 4WD warning lamp in the co mbination meter will indicate the malfunction area by
flashing according to the self-diagnostic results. Refer to DLN-97, "DTC Index"
.
Diagnostic Procedure
1. Warn up engine.
2. Move A/T selector lever to P position.
3. Turn 4WD shift switch to 2WD position.
4. Turn ignition switch ON and OFF at least twice, and then turn ignition switch OFF.
5. Turn 4WD shift switch to AUTO position.
6. Turn ignition switch ON. (Do not start engine.)
7. 4WD warning lamp ON.
8. Move A/T selector lever to R position.
9. Turn 4WD shift switch to 2WD, AUTO and 2WD in order.
10. Move A/T selector lever to D position.
11. Turn 4WD shift switch to 4H, AUTO and 4H in order.
ALL MODE AWD/4WD diagnostic mode Description
SELF-DIAG RESULTS Displays transfer control unit self-diagnosis results.DATA MONITOR Displays transfer control unit input/output data in real time.
WORK SUPPORT Supports inspections and adjustments. Commands are transmitted to the transfer control
unit for setting the status suitable for required operation, input/output signals are received
from the transfer control unit and received data is displayed.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read. ECU PART NUMBER Transfer control unit part number can be read.
Revision: December 20092009 QX56

DIAGNOSIS SYSTEM (TRANSFER CONTROL UNIT)
DLN-19
< FUNCTION DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
12. Move A/T selector lever to N position.
13. Turn 4WD shift switch to AUTO position.
14. Move A/T selector lever to P position.
15. Read the flickering of 4WD warning lamp.
Self-diagnosis example
ERASE SELF-DIAGNOSIS
 In order to make it easier to find the cause of hard-to-duplicate malfunctions, malfunction information is
stored into the control unit as necessary during use by the user. This memory is not erased no matter how
many times the ignition switch is turned ON and OFF.
 However, this information is erased by turning igni tion switch OFF after performing self-diagnostics or by
erasing the memory using the CONSULT-III.
DATA MONITOR MODE
Operation Procedure
1. Connect CONSULT-III.
2. Touch DATA MONITOR.
3. Select from SELECT MONITOR ITEM, screen of data monitor mode is displayed.
NOTE:
When malfunction is detected, CONSUL T-III performs REAL-TIME DIAGNOSIS.
Also, any malfunction detected while in th is mode will be displayed at real time.
Display Item List
×: Standard –: Not applicable
PDIA0227E
Monitored item (Unit) Monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELEC-
TION FROM MENU
VHCL/S SEN·FR [km/h] or [mph] ×–×Wheel speed calculated by ABS actuator and
electric unit (control unit).
Signal input with CAN communication line.
VHCL/S SEN·RR [km/h] or [mph] ×–×Wheel speed calculated by TCM.
Signal input with CAN communication line.
ENGINE SPEED [rpm] ×–×Engine speed calculated by ECM.
Signal input with CAN communication line.
THRTL POS SEN [V] ×–×Accelerator peda
l position (APP) sensor sig-
nal voltage is displayed.
Signal input with CAN communication line.
FLUID TEMP SE [V] ×–×Transfer fluid temperature sensor signal volt-
age is displayed.
BATTERY VOLT [V] ×–×Power supply voltage for transfer control unit.
2WD SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
AUTO SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
LOCK SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
(LOCK means 4H of 4WD shift switch.)
Revision: December 20092009 QX56

DLN-22
< COMPONENT DIAGNOSIS >[ATX14B]
P1811 POWER SUPPLY CIRCUIT
FOR TRANSFER CONTROL UNIT
COMPONENT DIAGNOSIS
P1811 POWER SUPPLY CIRCUIT FOR TRANSFER CONTROL UNIT
DescriptionINFOID:0000000003772080
Power supply to transfer control unit is abnormally low while driving.
DTC LogicINFOID:0000000003772081
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1811 detected?
YES >> Perform diagnosis procedure. Refer to DLN-22, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772082
1.CHECK POWER SUPPLY
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Connect transfer control unit harness connector.
3. Check voltage between transfer control unit harness connector terminals and ground.
4. Turn ignition switch ON. (Do not start engine.)
5. Check voltage between transfer control unit harness connector terminals and ground.
Are the inspection results normal?
YES >> GO TO 2.
NO >> Check the following. If any items are damaged, repair or replace damaged parts.
DTC CONSULT-III Diagnostic item is detected when... Reference
[ P 1 8 11 ] B AT T E R Y V O LTA G E Power supply voltage for transfer control
unit is abnormally low while driving.Refer to
DLN-22
.
Connector Terminal Voltage (Approx.)
E142 16 - Ground
0V
22 - Ground
E143 29 - Ground
30 - Ground
Battery voltage
47 - Ground
WDIA0165E
Connector Terminal Voltage (Approx.)
E142 16 - Ground
Battery voltage
22 - Ground
E143 29 - Ground
30 - Ground 0V
47 - Ground Battery voltage
WDIA0166E
Revision: December 20092009 QX56

DLN-24
< COMPONENT DIAGNOSIS >[ATX14B]
P1802 – P1804, P1809 T
RANSFER CONTROL UNIT
P1802 – P1804, P1809 TRANSFER CONTROL UNIT
DescriptionINFOID:0000000003772084
The transfer control unit controls the transfer contro l device which controls shifts between AUTO, 4H and 4LO
and between 2WD and 4WD. A DTC may se t when any of the following occur:
 Malfunction is detected in the memory (RAM) system of transfer control unit.
 Malfunction is detected in the memory (ROM) system of transfer control unit.
 Malfunction is detected in the memory (E EPROM) system of transfer control unit.
 AD converter system of transfer control unit is malfunctioning.
DTC LogicINFOID:0000000003772085
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Are DTC's P1802 - P1804 or P1809 detected?
YES >> Perform diagnosis procedure. Refer to DLN-24, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772086
1.INSPECTION START
Do you have CONSULT-III?
YES or NO
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM SELF-DIAGNOSIS (WITH CONSULT-III)
With CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select SELF-DIAG RESULTS mode for ALL MODE AWD/4WD with CONSULT-III.
3. Touch ERASE.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Perform the self-diagnosis again.
Is the CONTROL UNIT 1 [P1802], CONTROL UNIT 2 [P1803], CONTRO L UNIT 3 [P1804] or CONTROL
UNIT 4 [P1809] displayed?
YES >> Replace transfer control unit. Refer to DLN-130, "Removal and Installation".
NO >> Inspection End.
3.PERFORM SELF-DIAGNOSIS (WITHOUT CONSULT-III)
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1802] CONTROL UNIT 1 Malfunction is detected in the memory
(RAM) system of transfer control unit.
Refer to DLN-24
.
[P1803] CONTROL UNIT 2
Malfunction is detected in the memory
(ROM) system of transfer control unit.
[P1804] CONTROL UNIT 3 Malfunction is detected in the memory
(EEPROM) system of transfer control
unit.
[P1809] CONTROL UNIT 4 AD converter system of transfer control
unit is malfunctioning.
Revision: December 20092009 QX56

DLN-28
< COMPONENT DIAGNOSIS >[ATX14B]
P1810 NEUTRAL-4LO SWITCH
P1810 NEUTRAL-4LO SWITCH
DescriptionINFOID:0000000003772093
The neutral-4LO switch detects that the transfer case
is in neutral or 4LO range. DTC P1810 will set when an
improper signal from the neutral-4LO switch is input due to an open or short circuit.
DTC LogicINFOID:0000000003772094
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1810 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-28, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772095
1.CHECK 4LO POSITION SWITCH SIGNAL
With CONSULT-III1. Start engine.
2. Select DATA MONITOR mode for A LL MODE AWD/4WD with CONSULT-III.
3. Read out the value of N POSI SW TF.
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminal and ground.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1810] 4L POSI SW TF Improper signal from neutral-4LO switch
is input due to open or short circuit.Refer to
DLN-28
.
Condition Display value
 Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch: 2WD,
AUTO or 4H
OFF
4WD shift switch: 4H to
4LO (While actuator mo-
tor is operating.) OFF
→ ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.) ON
→ OFF
4WD shift switch: 4LO ON
SDIA2693E
Revision: December 20092009 QX56

P1810 NEUTRAL-4LO SWITCHDLN-29
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Are inspection results normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TR ANSFER CONTROL UNIT AND NEUTRAL-4LO SWITCH
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connecto r and the neutral-4LO switch harness connector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 25 and neutral-4LO switch harness connector
F60 terminal 13.
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect neutral-4LO switch harness connector.
3. Check continuity between neutral-4LO switch harness connec- tor F60 terminal 12 and ground.
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK 4LO SWITCH
1. Turn ignition switch OFF.
2. Disconnect neutral-4LO switch harness connector.
3. Remove neutral-4LO switch.
Connector Te r m i n a l
(Wire col-
or) Condition
Voltage
(Approx.)
E143 25 -
Ground  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de- pressed 4WD shift switch:
2WD, AUTO or 4H
Battery
voltage
4WD shift switch: 4H to
4LO (While actuator
motor is operating.) Battery
voltage
→
0V
4WD shift switch: 4LO
to 4H (While actuator
motor is operating.) 0V
→
Battery
voltage
4WD shift switch: 4LO 0V
Continuity should exist.
SDIA2694E
Continuity should exist.
SDIA2695E
Revision: December 20092009 QX56

P1813 4WD SHIFT SWITCHDLN-31
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1813 4WD SHIFT SWITCH
DescriptionINFOID:0000000003772097
The 4WD shift switch allows the driver to select AUTO, 2WD or 4WD and 4H or 4LO. DTC P1813 will set if
more than two switch inputs are simultaneously detected by the transfer control unit due to a short circuit in the
4WD shift switch.
DTC LogicINFOID:0000000003772098
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1813 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-31, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772099
1.CHECK 4WD SHIFT SWITCH SIGNAL
With CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out ON/OFF switching action of the 2WD SWITCH, AUTO SWITCH, LOCK SWITCH, 4L SW with
operating 4WD shift switch.
Without CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Check voltage between transfer control unit harness connector
terminals and ground.
Are inspection results normal?
YES >> GO TO 5.
NO >> GO TO 2.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1813] 4WD MODE SW More than two switch inputs are simulta-
neously detected due to short circuit of
4WD shift switch.Refer to
DLN-31
.
Connector Terminal Condition Voltage (Ap-
prox.)
E142 9 - ground
4WD shift switch: 2WD Battery voltage
4WD shift switch: AUTO, 4H or 4LO 0V
18 - ground 4WD shift switch: 4H Battery voltage
4WD shift switch: 2WD, AUTO or
4LO
0V
23 - ground 4WD shift switch: 4LO Battery voltage
4WD shift switch: 2WD, AUTO or 4H 0V
24 - ground 4WD shift switch: AUTO Battery voltage
4WD shift switch: 2WD, 4H or 4LO 0V
WDIA0148E
Revision: December 20092009 QX56

DLN-32
< COMPONENT DIAGNOSIS >[ATX14B]
P1813 4WD SHIFT SWITCH
2.CHECK 4WD SHIFT SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect 4WD shift switch harness connector.
3. Check voltage between 4WD shift switch harness connector ter- minal 1 and ground.
4. Turn ignition switch ON. (Do not start engine.)
5. Check voltage between 4WD shift switch harness connector ter- minal 1 and ground.
Are inspection results normal?
YES >> GO TO 3.
NO >> Refer to DLN-22, "Diagnosis Procedure"
.
3.CHECK HARNESS BETWEEN 4WD SHIFT SWITCH AND TRANSFER CONTROL UNIT
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the 4WD shift switch harness connector.
3. Check continuity between the following terminals.
- Transfer control unit harness connector E142 terminal 9 and 4WD shift switch harness connector M141 terminal 2.
- Transfer control unit harness connector E142 terminal 18 and 4WD shift switch harness connector M141 terminal 5.
- Transfer control unit harness connector E142 terminal 23 and 4WD shift switch harness connector M141 terminal 6.
- Transfer control unit harness connector E142 terminal 24 and
4WD shift switch harness connector M141 terminal 3.
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 4.
NO >> Check the following. If any items are damaged, repair or replace damaged parts.  Harness for short or open between battery and transfer shut off relay harness connector E69
terminal 5.
 Power supply circuit for transfer control unit. Refer to DLN-22, "Diagnosis Procedure"
.
4.CHECK 4WD SHIFT SWITCH
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect 4WD shift switch harness connector.
Connector Terminal Voltage (Approx.)
M141 1 - Ground 0V
SDIA2383E
Connector Terminal Voltage (Approx.) M141 1 - Ground Battery voltage
PDIA0210E
Continuity should exist.SDIA2699E
Revision: December 20092009 QX56
