WARNING LIGHTS AND MESSAGES
WARNING LIGHTS AND MESSAGESGENERAL WARNINGSTurning on of warning light is accompanied by specific mes-
sage and/or by buzzer sound where provided by instru-
ment panel. These indications are concise and brief and
cautionary and as such must not be considered as ex-
haustive and/or alternative to the information contained
in the Owner Handbook, which shall always be read
through carefully and thoroughly. In case of failure indi-
cation, always refer to the specifications contained in this
chapter.
IMPORTANT Failure indications displayed are divided in-
to two categories: very serious and less serious failures.
Very serious failures are indicated by a repeated and pro-
longed warning “cycle”.
Less serious failures are indicated by a limited “warning”
cycle.
The warning cycle of both failure types can be stopped
by pressing the button MODE. The instrument panel warn-
ing light will stay on until the cause of the failure is elimi-
nated.
For messages relevant to the versions equipped with Dua-
logic gearbox, see the attached Supplement.
CORRECT USE
OF THE CAR
LOW BRAKE FLUID (red)
HANDBRAKE ON (red)
Turning the ignition key to MAR the warning light turns
on, but it should go off after a few seconds.
Low brake fluid
The warning light turns on when the level of the brake flu-
id in the reservoir falls below the minimum level due to
a possible leak in the circuit.
On some versions the display shows the dedicated message.
x
If the warning light xturns on when trav-
elling (on certain versions together with
the message on the display) stop the car imme-
diately and contact a Fiat Dealership.
WARNING
Handbrake on
The warning light turns on when the handbrake is on.
On certain versions, if the car is moving the buzzer will al-
so sound.
IMPORTANT If the warning light turns on when travel-
ling, make sure the handbrake is not engaged.
123-134 PANDA EN 7-10-2009 13:49 Pagina 123

132
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
ESP SYSTEM FAILURE (amber)
Turning the ignition key to MAR the warning light
turns on, but it should go off after a few seconds.
If the warning light does not go off or stays on together
with the LED on the button ASR OFF when travelling, con-
tact a Fiat Dealership.
On some versions the display shows the dedicated message.
NOTE The warning light flashing when driving indicates
that the ESP system is active.
á
GENERIC FAILURE INDICATION
(amber)
The warning light turns on in the following cir-
cumstances.
Engine oil pressure sensor failure
The warning light turns on when failure is detected in en-
gine oil pressure sensor. Contact a Fiat Dealership to have
the failure fixed as soon as possible.
Water in diesel fuel filter
See what described for warning light
c.
Inertia fuel cut-off switch tripped
The warning light comes on when the inertia fuel cut-off
switch is triggered. The display shows the dedicated
message.
è
EXTERNAL LIGHT FAILURE (amber)
The warning light will come on (some versions
only) when a failure to one of the following lights
is detected:
– side lights;
– brake lights (third brake light excluded);
– rear fog lights;
– direction indicators;
– number plate lights.
The failure referring to these lights could be: one or more
blown bulbs, a blown protection fuse or an electric con-
nection cut-off.
The display shows the dedicated message.
W
REAR FOG LIGHTS (amber)
The warning light turns on when the rear fog
lights are turned on.
4
HEATED REAR WINDOW (amber)
The warning light turns on when switching the
heated rear window on.
(
123-134 PANDA EN 7-10-2009 13:49 Pagina 132

133KNOW
YOUR VEHICLE
SAFETY
CORRECT USE
OF THE CARWARNING LIGHTS
AND MESSAGESIN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
FRONT FOG LIGHTS (green)
The warning light comes on when the front fog
lights are turned on. HILL HOLDER FAILURE (amber)
Turning the ignition key to
MAR
the warning light
turns on, but it should go off after a few
seconds.
The warning light will turn on when the Hill Holder sys-
tem is faulty. In this case, contact a Fiat Dealership as soon
as possible.
On some versions the display shows the dedicated message.
SIDE/TAIL LIGHTS AND LOW BEAMS
(green) FOLLOW ME HOME (green)
Side/tail lights and low beams
The warning light comes on when side/tail lights or low
beams are turned on.
Follow me home
The warning light will come when this device is active (see
“Follow me home” in chapter “Know your vehicle”).
The display shows the dedicated message.
*3
LEFT-HAND DIRECTION INDICATOR
(green - blinking)
The warning light turns on when the direction in-
dicator control lever is moved downwards or, together
with the right indicator, when the hazard warning light but-
ton is pressed.
RIGHT-HAND DIRECTION INDICA-
TOR (green - blinking)
The warning light turns on when the direction in-
dicator control lever is moved upwards or, together with
the left indicator, when the hazard light button is pressed.
5FD
123-134 PANDA EN 7-10-2009 13:49 Pagina 133

134
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
LIMITED RANGE (versions with reconfigurable
multifunction display)
The display will show the dedicated message to warn the
driver that the driving range is less than 50 km.
ASR SYSTEM (versions with reconfigurable mul-
tifunction display)
The ASR system can be turned off by pressing the button
ASR OFF.
The display will show the dedicated message to warn the
driver that the system is off; at the same time the button
LED will come on.
Pressing again the button ASR OFF, the button LED will
turn off and the display will show the dedicated message
to warn the driver that the system is on again. POSSIBLE PRESENCE OF ICE ON THE ROAD
(versions with reconfigurable multifunction
display)
When the outside temperature reaches or falls below
3 °C the outside temperature indication flashes to warn
the driver about the possible presence of ice on the road.
The display shows the dedicated message.
SPEED LIMIT EXCEEDED
The display will show the dedicated message when the car
exceeds the set speed limit (see “Multifunction Display” in
chapter “Know your vehicle”).“DUALDRIVE” ELECTRIC POWER
STEERING ACTIVATION (green)
The wording “CITY” will turn on when engag-
ing the “Dualdrive” electric power steering by pressing the
relevant button. Press the button again to turn the “CITY”
wording off.
MAIN BEAM HEADLIGHTS (blue)
The warning light comes on when the main
beams are turned on.
CITY1
123-134 PANDA EN 7-10-2009 13:49 Pagina 134

216KNOW
YOUR VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONSINDEX
– interior ..................................... 158
Bulb types ...................................... 150
Bulbs
– bulb types ................................ 150
– generals instructions for
replacement ............................ 149Car inactivity ............................... 122
Car maintenance..................... 169
Car speed indicator
(speedometer) ........................... 14
Car washing
– engine compartment ............ 189
– exterior ................................... 189
– interior ..................................... 190
Carrying children ......................... 98
Ceiling light switching-on/off ..... 68
Central locking ............................. 61
Cigar lighter .................................. 55
Climate control system .............. 43
Climate control system
controls .................................. 41-44
Climate control system vents ... 41
Clock adjustment ................... 16-18Clock
– adjustment ........................... 16-18
Clutch
– technical specifications ......... 195
CO
2emissions ............................. 207
CODE card ................................... 6
Control buttons ........................... 53
Controls (pushbuttons) ............. 53
Correct use of the car.......... 111
Current sockets ........................... 58
Changing a wheel ......................... 137
– general information
and warnings ........................... 137
– tyre and wheel types ............ 199
– tyre inflation pressure .......... 199
Child lock ...................................... 62
Child seats ..................................... 103
– fitness for child seat use ...... 101
– preparation for child seats .. 103
Children (carrying in safety) ..... 98
– preparation for Isofix seat
mounting ................................. 103
Dashboard .................................... 3Defrosting-demisting
– rear window ........................... 40
– windscreen and front side
windows ........................... 39-42-46
Demisting-defrosting
– door mirrors .......................... 36
– rear window ........................... 40
– windscreen and side
front windows ............... 39-42-46
Diesel particulate filter (DPF) ... 90
Digital display ................................ 16
– control buttons ...................... 16
– standard screen ..................... 16
– warning light test .................... 17
Dipped headlights (lights)
– bulb replacement ................... 153
– switching-on ........................... 48
Dipped headlights
– bulb replacement ................... 153
– switching on ............................ 48
Direction indicator
– front bulb replacement ........ 154
– rear bulb replacement .......... 155
– switching on ............................ 49
215-224 PANDA EN 7-10-2009 15:09 Pagina 216

221KNOW
YOUR VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONSINDEX
– passenger compartment
ventilation and heating ......... 42
– system servicing ..................... 43
– windscreen and front side
window demisting/
defrosting ................................ 42
Mirror adjustment ....................... 36
MSR (system) ................................ 78
MSR system ................................... 78
Multifunction display ................... 17
– control buttons ...................... 19
– setup menu ............................. 20
– standard screen ..................... 17N
umber plate lights
– bulb replacement ................... 156
O
n board instruments (panel) .. 14
Paint (maintenance) ................... 188
– bodywork colour plate ........ 192
Paraflu
– level check and top-up ......... 177
– specifications .......................... 205Parking (sensors) ......................... 82
Parking lights ................................. 48
Parking sensors ............................ 82
Parking the vehicle ...................... 113
Passenger compartment light
adjustment .................................. 52
Performance ................................. 201
Pollen filter .................................... 181
Power sun roof ............................ 58
– opening/closing ...................... 59
Power windows ........................... 63
Preparation for child seats ........ 103
Q
uality specifications of fluid
and lubricants ................... 204-205
Radio transmitters and mobile
phones ......................................... 87
Radio transmitters and mobile
phones ......................................... 87
Rear door locking
emergency device ..................... 62
Rear fog light
– bulb replacement ................... 155– switching on ............................ 54
Rear fog lights ............................... 54
Rear fog lights
– bulb adjustment ..................... 156
– switching on ............................ 54
Rear light units
– bulb replacement ................... 155
Rear seats
– cleaning .................................... 190
– headrests ................................. 32
Rear view mirrors
– inside ........................................ 35
– outside ..................................... 36
Rear window washer ................... 51
– fluid level check
and top-up ............................... 178
– jet .............................................. 187
– operation ................................. 51
Rear window wiper
– blade replacement .................. 186
– operation .................................. 51
– rear window washer fluid
features ..................................... 179
215-224 PANDA EN 7-10-2009 15:09 Pagina 221

Reconfigurable multifunction
display .......................................... 19
– control buttons ...................... 19
– set up menu ............................ 20
– standard screen ..................... 19
Refuelling
– diesel engines ......................... 88
– petrol engines ......................... 87
– technical specifications
(quantity) ................................. 203
Remote control ........................... 7
– additional remote control ... 8
– battery replacement ............. 9
– remote door opening/
closing ...................................... 8
– tailgate opening ...................... 8
Replacing the battery of
the key with remote control .. 9
Rev counter .................................. 14
Reversing light
– bulb replacement ................... 155
Reversing light
– bulb replacement ................... 156Roof rack – ski rack
(preparation) .............................. 71
Roof rack bar fasteners .............. 71
Roof rack/ski-rack bars
(preparation) .............................. 71
Rubber pipes ................................. 185
Safety........................................... 91
Safety belts .................................... 91
– carrying children safely ........ 98
– general instructions .............. 95
– load limiters ............................ 95
– pretensioners ......................... 94
– SBR ........................................... 91
– seat belt height
adjustment .............................. 92
– seat belt maintenance ........... 97
– using the seat belts ............. 91-93
SBR system .................................... 91
Scheduled servicing ..................... 172
Scheduled Servicing
Programme ......................... 170-171
Seat adjustment ...................... 31-32Seat belt pretensioners .............. 94
– load limiters ............................ 95
Side air bags
(side bag - window bag) ........... 107
– general warnings .................... 109
Side light
– front bulb replacement ........ 152
– rear bulb replacement .......... 155
– switching on ............................ 48
Smart washing
(windscreen wiper) ................... 50
Snow chains ..................................
Sound system
(preparation system) ................ 84
Sound system presetting ............ 84
Space-saver wheel ....................... 137
– technical specifications ......... 199
Spark plugs (type) ........................ 194
Speedometer ................................ 14
Steering column lock .................. 10
Steering wheel adjustment ........ 34
Steering wheel levers .............. 48-50
Steering wheel
– adjustment lever .................... 34
222KNOW
YOUR VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONSINDEX
215-224 PANDA EN 7-10-2009 15:09 Pagina 222

223KNOW
YOUR VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONSINDEX
– turning circle .......................... 196
Steering
– steering wheel adjustment
lever .......................................... 34
– technical specifications ......... 196
Sun visors ...................................... 56
Suspension .................................... 196
Symbols .......................................... 5Tailgate
– opening with remote
control ..................................... 8
Technical specifications....... 191
Temperature gauge
Third brake light .......................... 157
Top speed ..................................... 201
Towing of trailers ........................ 117
Towing of vehicle ........................ 167
Trailer (towing) ............................ 117
– installing the tow hook ........ 118
Transmission
– technical specifications ......... 195
Trip Computer ............................ 28
– control button ....................... 29– start of journey
procedure ............................... 30
Turning circle ............................... 196
Tyre pressure ............................... 199
Tyre puncturing
– general instructions .............. 137
– quick tyre repair kit
Tyre repair kit Fix&Go
automatic .................................... 143
– bottle replacement
procedure ............................... 148
– inflation procedure ............... 146
Tyres
– in case of puncture ............... 137
– inflation pressure ................... 199
– quick repair kit Fix&Go
automatic ................................. 143
– reading the tyre code ........... 197
– snow chains ............................ 122
– snow tyres .............................. 121
– tool and space-saver wheel
compartment ................... 138-139
– tyre and wheel types ............ 199
– wheel replacement ................ 143– winter tyres ............................ 122
Vehicle dimensions .................... 200
Vehicle end of life ........................ 209
Vehicle identification data .......... 191
Vehicle identification plate ........ 191
Vehicle identification ................... 191
Vehicle lifting points .................... 140
Vehicle scrapping ......................... 209
Vehicle weights ............................ 202W
arning lights and messages
.. 123
Wheel rims ................................... 199
– understanding rim
marking .................................... 198
Wheel trim ................................... 197
Wheels and tyres.......................... 183
– geometry ................................. 197
– in case of puncture ............... 137
– quick repair kit Fix&Go
automatic ................................. 143
– reading the tyre code ........... 197
– snow chains ............................ 122
– snow tyres .............................. 122
215-224 PANDA EN 7-10-2009 15:09 Pagina 223
