2009 FIAT IDEA Dualogic Transmission Manual

16
TRANSMISSION UNIT
1.4 16V 95 HP- 1.3 Multijet 70 HP - 1.3 Multijet 90 HP - 1.3 Multijet 95 HP
Gearbox Five forward speeds plus reverse with
electronically managed electrohydraulic control system
Clutch
Electronically controlled
electrohydraulic system
Drive Front wheel
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 16

17
1.4 16V 95 HP
1160
500
940
805
1660
1000
400
75
60
WEIGHTS
Weights (kg)
Kerb weight
(with supplies, spare wheel,
tools and accessories):
Payload (*)
including the driver:
Maximum permitted loads (**)
– front axle:
– rear axle:
– total:
Towable loads:
- braked trailer:
- non braked trailer:
Maximum load on roof:
Maximum load on the ball:
(*) If special equipment is fitted (sun roof, tow hook, etc.) the unladen weight increases and consequently the payload will
decrease in relation to the maximum permitted loads.
(**) Loads not to be exceeded. The driver is responsible for arranging goods in the luggage compartment and/on load carrying platform within
the maximum permitted loads.1.3 Multijet 70 HP - 1.3 Multijet 90 HP - 1.3 Multijet 95 HP
1205
500
940
805
1705
1000
400
75
60
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 17

18
CO2emissions in accordance with directive 2004/3/EC (gr x 100 km)
The CO
2emission value, with reference to combined consumption equivalent to 136 (gr x 100 km) with 1.4 16V95 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 121 (gr x 100 km) with 1.3 Multijet 70 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 118 (gr x 100 km) with 1.3 Multijet 90 HP engine.
The CO
2emission value, with reference to combined consumption equivalent to 115 (gr x 100 km) with 1.3 Multijet 95 HP engine.
CO2EMISSIONS
CAPACITIES
Dualogic gearbox hydraulic
activation system
1.3 Multijet 70 HP
1.3 Multijet 90 HP - 1.3 Multijet 95 HP 1.4 16V 95 HP
litres
0.70kg
0.59litres
0.70kg
0.59 Recommended fuels
Recommended products
TUTELA CAR CS SPEED -
Special oil with
“ATF DEXRON III” additive
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 18

19
FUEL CONSUMPTION
Fuel consumption according to Directive 2004/3/EC (litres x 100 km) Urban Extra urban Combined
1.4 16V 95 HP7.7 4.6 5.7
1.3 Multijet 70 HP5.8 4.2 4.8
1.3 Multijet 90 HP5.6 3.8 4.5
1.3 Multijet 95 HP5,5 3,7 4,4
The fuel consumption figures in the table refer to the AUTO-ECO logic.
603_97_015 IDEA DUAL GB 1e 4-02-2009 16:25 Pagina 19

Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print n° 603.97.015 - 02/2009 - 1
stEdition
