2009 DODGE CHALLENGER SRT Owners Manual

Windshield Wipers And Washers............122
▫Intermittent Wiper System...............122
▫Mist Feature.........................123
▫Windshield Washers...................123
▫Headlights On With Wipers
(Available With Auto Headlights Only)......124
▫Adding Washer Fluid..................124

Tilt/Telescoping Steering Column...........125

Electronic Speed Control..................126
▫Electronic Speed Control Operation........126
▫To Activate..........................127
▫To Set At A Desired Speed...............127
▫To Deactivate........................127▫To Resume Speed.....................128
▫To Vary The Speed Setting...............128
▫To Accelerate For Passing...............128

Overhead Console......................129
▫Courtesy/Reading Lights................129
▫Sunglasses Storage....................130

Garage Door Opener — If Equipped.........130
▫Programming HomeLink...............131
▫Gate Operator/Canadian Programming.....134
▫Using HomeLink.....................134
▫Reprogramming A Single HomeLink
Button.............................135
▫Security............................135
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73
3

▫Troubleshooting Tips...................135
▫General Information...................136

Power Sunroof — If Equipped.............136
▫Opening Sunroof - Manually.............137
▫Opening Sunroof - Express..............137
▫Closing Sunroof - Manually..............137
▫Closing Sunroof - Express...............138
▫Pinch Protect Feature...................138
▫Pinch Protect Override.................138
▫Venting Sunroof - Express...............138
▫Sunshade Operation...................139
▫Wind Buffeting.......................139
▫Sunroof Maintenance...................139▫Ignition Off Operation..................139
▫Sunroof Fully Closed...................139

Electrical Power Outlets..................140
▫Electrical Outlet Use With Engine Off.......141

Cupholders...........................142
▫Front Cupholders.....................142
▫Rear Cupholders......................142

Console Features.......................143
▫Sliding Center Console Armrest...........143
▫Console Storage......................143

Rear Window Features...................144
▫Rear Window Defroster.................144
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Automatic Dimming Inside Mirror
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn the feature
on or off by pressing the button at the base of the mirror.
A light next to the button will illuminate to indicate when
the dimming feature is activated.
CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE:The passenger-side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
Automatic Dimming Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3

WARNING!
Vehicles and other objects seen in the passenger-side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger-side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger-side convex mirror.
Exterior Mirrors Folding Feature — If Equipped
Some models have exterior mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions, full
forward, full rearward, and normal.
Power Remote Control Mirrors
The power mirror switch is located on the driver’s door
trim panel next to the power door lock switch. A rotary
knob selects the left mirror, right mirror, or off position.
After selecting a mirror, move the knob in the same
direction you want the mirror to move. Use the center off
position to guard against accidentally moving a mirror
position.
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Heated Remote Control Mirrors — If Equipped
These mirrors are heated to melt frost or ice. This feature
is activated whenever you turn on the Electric Rear
Window Defroster.
Illuminated Vanity Mirrors — If Equipped
An illuminated vanity mirror is on the sun visor. To use
the mirror, rotate the sun visor downward and swing the
mirror cover upward. The light turns on automatically.
Closing the mirror cover turns off the light.
Power Mirror Control
Illuminated Vanity Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3

HANDS-FREE COMMUNICATION (UConnect)—
IF EQUIPPED
NOTE:The sales code RER, REN and REU radios contain
an integrated Hands-Free Communication (UConnect)
system. Refer to your “Navigation User’s Manual” for
UConnectsystem operating instructions for these radios.
UConnectis a voice-activated, hands-free, in-vehicle com-
munications system. UConnectallows you to dial a phone
number with your cellular phone using simple voice
commands (e.g.,Call”“Mike””WorkorDial”
“248-555-1212). Your cellular phone’s audio is transmitted
through your vehicle’s audio system; the system will
automatically mute your radio when using the UConnect
system.
NOTE:The UConnectsystem requires a cellular phone
equipped with the BluetoothHands-Free Profile,Ve r -
sion 0.96 or higher. See the UConnectwebsite for
supported phones.NOTE:For UConnectcustomer support, visit the
following websites:
•www.chrysler.com/uconnect
•www.dodge.com/uconnect
•www.jeep.com/uconnect
•or call 1–877–855–8400
UConnectallows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle and enables you to mute the system’s microphone
for private conversation.
The UConnectphonebook enables you to store up to 32
names, with four numbers per name. Each language has
a separate 32-name phonebook accessible only in that
language. This system is driven through your Bluetooth
“Hands-Free profile” cellular phone. UConnectfeatures
Bluetoothtechnology - the global standard that enables
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

different electronic devices to connect to each other
without wires or a docking station, so UConnectworks
no matter where you stow your cellular phone (be it your
purse, pocket, or briefcase), as long as your phone is
turned on and has been paired to the vehicle’s
UConnectsystem. The UConnectsystem allows up to
seven cellular phones to be linked to the system. Only
one linked (or paired) cellular phone can be used with the
system at a time. The system is available in English,
Spanish, or French languages.
Phone Button
The rearview mirror contains the microphone
for the system (depending on the type of
mirror and radio equipped), and either the
radio or the mirror has the two control buttons
(PHONE Button and VOICE RECOGNITION button)
that will enable you to access the system.Voice Recognition Button
Actual button location may vary with radio.
The individual buttons are described in the
“Operation” section.
The UConnectsystem can be used with any Hands-Free
Profile certified Bluetoothcellular phone. See the
UConnectwebsite for supported phones. If your cellu-
lar phone supports a different profile (e.g., Headset
Profile) you may not be able to use any UConnect
features. Refer to your cellular service provider or the
phone manufacturer for details.
The UConnectsystem is fully integrated with the vehi-
cle’s audio system. The volume of the UConnectsystem
can be adjusted either from the radio volume control
knob or from the steering wheel radio control (right
switch), if so equipped.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79
3

The radio display will be used for visual prompts from
the UConnectsystem such asCELLor caller ID on
certain radios.
Operation
Voice commands can be used to operate the UConnect
system and to navigate through the UConnectmenu
structure. Voice commands are required after most
UConnectsystem prompts. You will be prompted for a
specific command and then guided through the available
options.
•Prior to giving a voice command, one must wait for
the beep, which follows theReadyprompt or another
prompt.
•For certain operations, compound commands can be
used. For example, instead of sayingSetupand then
Phone Pairing,the following compound command
can be said:Setup Phone Pairing.
•For each feature explanation in this section, only the
combined form of the voice command is given. You
can also break the commands into parts and say each
part of the command when you are asked for it. For
example, you can use the combined form voice com-
mandPhonebook New Entry,or you can break the
combined form command into two voice commands:
PhonebookandNew Entry.Please remember, the
UConnectsystem works best when you talk in a
normal conversational tone, as if speaking to someone
sitting a few feet/meters away from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
Help Command
If you need assistance at any prompt, or if you want to
know your options at any prompt, sayHelpfollowing
the beep. The UConnectsystem will play all the options
at any prompt if you ask for help.
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
