2009 DODGE CARAVAN service indicator

filler cap message will be displayed in the instrument
cluster. Tighten the gas cap until aclickingsound is
heard. This is an indication that the gas cap is properly
tightened. Press the odometer reset button to turn the
message off. If the problem persists, the message will
appear the next time the vehicle is started. If the problem
is detected twice in a row, the system will turn on the
Malfunction Indicator Light (MIL). Resolving the prob-
lem will turn the MIL light off. Take your vehicle in to an
authorized dealer.
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states that require an Inspection and Mainte-
nance (I/M), this check verifies the MalfunctionIndicator Light (MIL) is functioning and is not on when
the engine is running, and that the OBD II system is
ready for testing.
Normally, the OBD II system will be ready. The OBD II
system maynotbe ready if your vehicle was recently
serviced, recently had a dead battery, or a battery replace-
ment. If the OBD II system should be determined not
ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key-actuated test,
which you can use prior to going to the test station. To
check if your vehicle’s OBD II system is ready, you must
do the following:
1. Insert your ignition key into the ignition switch.
2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
436 MAINTAINING YOUR VEHICLE
ProCarManuals.com

EMISSIONS CONTROL SYSTEM MAINTENANCE
The Scheduled Maintenance services listed inbold type,
must be done at the times or mileages specified to ensure
the continued proper functioning of the Emissions Con-
trol System. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions, such as dusty areas and very short trip
driving.
Inspection and service should also be done anytime a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sions control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part that has been
certified pursuant to U.S. EPA or in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULE
The oil change indicator system will remind you that it is
time to take your vehicle in for scheduled maintenance.
On Non-EVIC equipped vehicles,CHAngE OILwill
flash in the instrument cluster odometer and a single
chime will sound, indicating that an oil change is neces-
sary.
On Electronic Vehicle Information Center (EVIC)
equipped vehicles,Oil Change Requiredwill be dis-
played in the EVIC and a single chime will sound,
indicating that an oil change is necessary.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Have your vehicle
serviced as soon as possible, within the next 500 miles
(805 km).
484 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
ProCarManuals.com

Airbag......................66,71,75,94,244
Alarm.............................. 244
Anti-Lock........................... 237
Automatic Headlights................... 174
Back-Up............................. 477
Battery Saver......................... 177
Brake Assist Warning................... 348
Brake Warning........................ 238
Bulb Replacement...................474,475
Center Mounted Stop................... 478
Daytime Running...................... 176
Dimmer Switch, Headlight............... 174
Engine Temperature Warning.............. 243
Fog ..........................177,244,476
Hazard Warning Flasher................. 410
Headlight Switch...................... 174
Headlights........................... 475
Headlights On Reminder................. 176
High Beam Indicator.................... 237High Beam/Low Beam Select............. 179
Illuminated Entry....................... 20
Interior..........................172,174
License............................. 478
Lights On Reminder.................... 176
Low Fuel............................ 245
Malfunction Indicator (Check Engine)........ 242
Oil Pressure.......................... 244
Park.............................174,476
Passing............................. 179
Reading............................. 195
Rear Servicing........................ 477
Rear Tail............................ 477
Seat Belt Reminder..................... 244
Security Alarm (Theft Alarm).............. 244
Service...........................474,475
Service Engine Soon (Malfunction Indicator) . . . 242
Side Marker.......................... 477
Theft Alarm (Security Alarm).............. 244
INDEX 521
10
ProCarManuals.com

Tire Pressure Monitoring (TPMS)........... 245
Turn Signal........................476,477
Voltage............................. 245
Warning (Instrument Cluster Description)..... 236
Load Leveling System.................... 224
Loading Vehicle...................216,389,391
Capacities........................... 391
Tires ............................... 354
Locks
Door................................ 31
Lower Anchors and Tether for CHildren
(LATCH).............................. 86
Lubrication, Body....................... 448
Luggage Rack (Roof Rack)................. 225
Lumbar Support........................ 149
Maintenance Free Battery.................. 444
Maintenance Procedures................... 438
Maintenance Schedule.................... 484Maintenance, Sunroof..................... 206
Malfunction Indicator Light (Check Engine) . . 242,436
Manual, Service......................... 507
Map/Reading Lights..................... 195
Memory Feature (Memory Seat)............. 166
Memory Seat........................105,166
Mini-Trip Computer...................248,255
Mirrors............................... 102
Automatic Dimming.................... 102
Electric Remote....................... 104
Exterior Folding....................... 104
Heated............................. 105
Memory............................. 166
Outside............................. 103
Rearview............................ 102
Vanity.............................. 106
Modifications/Alterations, Vehicle............. 7
Monitor, Tire Pressure System............... 370
Mopar Parts.........................437,506
522 INDEX
ProCarManuals.com

Adjustment.......................... 144
Cleaning............................ 464
Easy Entry........................... 153
Fold in Floor (Stow nGo) ................ 149
Heated............................. 147
Lumbar Support....................... 149
Memory............................. 166
Power.............................. 145
Reclining............................ 148
Stow n Go (Fold in Floor)................ 149
Tilting.............................. 153
Security Alarm (Theft Alarm)................ 18
Selection of Coolant (Antifreeze)..........451,480
Sentry Key (Immobilizer)................... 15
Sentry Key Programming................... 17
Sentry Key Replacement................... 16
Service Assistance....................... 503
Service Contract......................... 505Service Engine Soon Light
(Malfunction Indicator).................... 242
Service Manuals........................ 507
Setting the Clock..................263,267,276
Settings, Personal........................ 259
Shoulder Belts........................... 56
Signals, Turn................177,178,237,476,477
Sirius Backseat TV™..................... 297
Sliding Door............................ 42
Slippery Surfaces, Driving On............... 334
Snow Chains (Tire Chains)................. 367
Snow Tires............................ 368
Spare Tire.......................361,362,413
Speed Control (Cruise Control).............. 183
Speedometer........................... 237
Starting............................... 324
Automatic Transmission................. 324
Cold Weather......................... 325
Engine Fails to Start.................... 325
526 INDEX
ProCarManuals.com

Automatic........................... 327
Operation........................... 327
Selection of Lubricant................458,481
Transmission........................... 458
Automatic........................... 458
Fluid............................458,481
Transmitter Battery Service
(Remote Keyless Entry).................... 26
Transmitter, Garage Door Opener (HomeLink) . . 197
Transmitter, Remote Keyless Entry (RKE)........ 21
Transporting Pets........................ 90
Tread Wear Indicators.................... 364
Trip Computer.......................... 248
Trip Odometer.......................... 240
Turn Signals...................178,237,476,477
UCI Connector......................... 286
UConnect(Hands-Free Phone).............. 115
Uniform Tire Quality Grades................ 509Universal Consumer Interface (UCI) Connector . . . 286
Universal Joints......................... 448
Universal Transmitter..................... 197
Unleaded Gasoline....................... 378
Upholstery Care........................ 463
Vanity Mirrors.......................... 106
Variance, Compass....................250,258
Vehicle Certification Label................. 389
Vehicle Identification Number (VIN)............ 6
Vehicle Loading...................355,389,391
Vehicle Modifications/Alterations.............. 7
Vehicle Storage.......................319,474
Video Entertainment System™
(Rear Seat Video System).................. 297
Warning Flasher, Hazard.................. 410
Warning Lights (Instrument
Cluster Description)...................... 236
Warnings and Cautions..................... 6
INDEX 529
10
