2009 Citroen C6 DAG Owner's Manual

130
IV
C A P A C I T I E S
ENGINE TYPEV62.2 HDi 16VV6 HDi
Engine oil capacities (in litres) (1)5.255.255.55
(1) After draining with change of oil fi lter.
Capacity of fl uid for windscreen wash and headlamp wash (in litres)6.5

131
VA
A
F U E L
If you should put in fuel that is not suitable for your vehicle's engine type, it is imperative to have the tank drained be fore you start the engine again.
While you are refuelling, the engine must be stopped and the ignition switched off.
For a petrol engine with a cata-lytic converter, unleaded fuel is compulsory.
The fi ller neck is narrower to ensure that only unleaded petrol can be put in.
When you are seeking to fi ll your tank, do not persist after the third cut-off; that could cause your vehicle to malfunction.
Fuel must be added in quantities of more than 5 litres to be recog-nised by the fuel gauge.
To open the fl ap, press button A. Undo the cap and attach it to the tab on the inside of the fl ap.
Opening the cap can trigger a vac-uum. This results in a noise caused by the sealing of the fuel circuit.Note: The fuel fl ap is locked when you lock your vehicle with the remote control.
FUEL QUALITY
A label inside the fi ller fl ap tells you which type of fuel to use.
The petrol engines are designed to run on RON 95.
However, for better performance (petrol engine), we recommend RON 98

132
V
DEF
ACB
UPPER FRONT LENSA Lateral lampB Dipped/main beamC Sidelamp
Note: In some climatic condi-tions, condensation can appear in the lighting/signalling units. This is normal and should disappear after a while (when the functions have been on for a few minutes for example).Ifthis does not happen, consult your CITROËN dealer.this does not happen, consult this does not happen, consult
For maintenance of the front lenses and for changing of bulbs, contact a CITROËN dealer. The bulbs for and for changing of bulbs, contact and for changing of bulbs, contact
lamps D and E have a common bulb-holder.
C H A N G I N G B U L B S
Your headlamps have Xenon bulbs.
Because of risks of electrocution, we advise you to contact a CITROËN dealer if there is any problem.Because of risks of electrocution, we advise Because
It is recommended to change both bulbs at the same time i f there is a failure of one of them.
Your vehicle is equipped with an active bonnet. To be sure that this safety feature is functioning correctly, contact a CITROËN dealer Your vehicle is equipped with an active bonnet.
for replacement of any of the components on the front panel.
LOWER FRONT LENSD Direction indicatorE Daytime-running lampF Front foglamp
SIDE REPEATER
To change the side repeater, push it forwards or rearwards to detach it and contact a CITROËN dealer.

133
V
A
B
and change the bulbs.Note: The tool for undoing the screws is to be found in the toolbox in the spare wheel. See "Changing a wheel".
REAR CENTRAL LENSA Reversing lampB Foglamp
The bulbs for lamps A and B have a common bulb-holder. Contact a CITROËN dealer.
THIRD STOPLAMP
Contact a CITROËN dealer.
To gain access to the bulb-hold-ers, open the boot and undo the four screws on the bodywork. Then lower the boot lid in order to be able to pull out the two rear lamp units, without pulling on the electric cables.
NUMBER PLATE
Detach the transparent shield, then pull out the bulb. Bulb: W 5 W.
After each operation, check that the lamps work.
C H A N G I N G B U L B S

134
V
A
BC
D
C H A N G I N G B U L B S
REAR LATERAL LENSA Parking lamp.Bulb: W 5 W.
B Stoplamp and parking lamp.Bulb: P21 W/5 W.C Direction indicator.Bulb: P21 W cristal.
D Lateral lamp.Bulb: W 5 W.
1. Open the rear LH fl ap or the two rear RH fl aps, by rotating the pins a 1/4 turn.

135
V
B
C
D
A
C H A N G I N G B U L B S
2. Use a tool to detach the two lugs holding the lens.
3. Without touching the seal, disengage the lamp unit upwards and orient it so that the bulbs are pointing outwards.
5. Reposition the lens, fi rst inserting the pin furthest forward, then push.Make sure that the rear screen seals and the lamp units are correctly located.
6. Secure the two lugs.
4. Replace bulbs that are faulty.

136
V
S A F E T Y R E C O M M E N D A T I O N S
It is recommended that you have your towbar installed and removed by a CITROËN dealer.It is recommended that you have recommended that
If you are towing another vehicle, the latter must be free-wheeling (gearbox in neutral).
Dimensions (in metres):
A: 0.971
TOWBAR
(Boat, caravan, etc.)
It is recommended that you have your towbar installed and removed by a CITROËN dealer.have your towbar installed and towbar installed
If you are climbing a steep gradient and the engine gets excessively hot, certain functions become una-vailable (e.g. sequential control of the automatic gearbox, the air con-ditioning).
If you are towing, it is necesaary to deactivate the parking assist-ance by pressing the control on the dashboard. See "Parking assist-ance".
It is recommended that you remove the towing ball, so that it does not interfere with the functioning of the proximity sensors, when you are not using a trailer.
MAINTENANCE
if cleaning the vehicle with a high pressure systemYour Piloted Defl ector has to be closed.
It is not advisable to clean the underside of the vehicle, for fear of damaging the electric parking brake.As water may penetrate into the vehicle interior via the door apertures, do not target these areas.
Do not direct at the headlamps, lamps and their edges for too long or you may damage their coating and seals.

137
V
R O O F B A R S
Do not exceed the maximum permitted load.
For the maximum distributed load on the roof bars: see the chapter "General".
Recommendations:Spread the load evenly, avoiding overloading on one side.
Position the heaviest weight as low down as possible.Tie the load down securely and add warning signs if it is protruding.
Drive conservatively, as the vehicle will be more vulnerable to side winds.
The stability of your vehicle may be altered.Remove the roof rack or roof bars when you are not using them.
