5FAMILIARISATION-
INSTRUMENTS AND CONTROLS
12. Windscreen wash-wipe stalk.
13. Audio equipment steering
wheel control.
14. Steering lock and ignition.
15. Fuse box.
16. Passenger air bag disarming
control.
17. Alarm.
18. Steering wheel adjustment
control.
19. Passenger's electric mirror
control.
20. Headlamp height adjustment.
21. Heated seats control.
22. Handbrake.
23. Lighter.
24. Removable ashtray.
25. Gear lever.
26. Storage.
27. Heating/air conditioning controls.
28. Audio RD3.
29. Lower glove box.
30. Upper glove box or passenger
air bag.
31. Bonnet release.
32. Side adjustable heating/
ventilation vents.
33. Side window de-icing/
demisting vents.
1. Speaker (tweeter).
2. Windscreen demisting vents.
3. Controls:
- Electric windows.
- Demisting of rear door windows.
- Air conditioning.
4. Central locking button.
5. Multifunction display or clock.
6. Hazard lights button.
7. Central adjustable heating/
ventilation vents.
8. Lights and direction indicators
stalk.
9. Speed limiter/cruise control.
10. Instrument panel.
11. Driver's air bag
Horn.
Page 8 of 115
11FAMILIARISATION-
SPEED LIMITER
This limiter indicates the status
of selection of the function on the
instrument panel and displays the
programmed speed. The minimum
speed which can be programmed is
at least 18 mph (30 km/h).
It prevents exceeding of the speed
programmed by the driver, this func-
tion remains active regardless of any
action on the brake or clutch pedals.
On the other hand, pressing the acce-
lerator pedal to the point of resis-
tance does not have any effect.
It is possible to exceed the pro-
grammed speed temporarily by pres-
s i n g t h e a c c e l e r a t o r fi r m l y b e y o n d t h i s
point of resistance.
The operating actions must be car-
ried out with the engine running. The cruise control has a display on
the instrument panel to indicate the
programmed reference speed.
It enables the vehicle to maintain the
reference speed programmed by the
driver.
In order for it to be programmed or
activated, the vehicle speed must be
greater than 25 mph (40 km/h) with
at least fourth gear engaged.
74
72 I f t h e v e h i c l e i s fi t t e d w i t h
a speed limiter and cruise
control, these functions can-
not be activated at the same
time.
Page 14 of 115
INSTRUMENTS, CONTROLS and DISPLAYS18 -
1. Seat belt not fastened warning
light
2. Front and side air bags warning
light
3. Passenger air bag disarmed
warning light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
warning light
6. Rear fog lamp indicator light
7. Diesel pre-heat warning light
8. Left hand direction indicator
9. Total distance recorder, service
indicator and engine oil level
indicator
10. Right hand direction indicator
11. Emission control system warning
light
12.
Main beam headlamps indicator light
13. H a n d b r a k e , l o w b r a k e fl u i d
level and electronic brake force
d i s t r i b u t i o n w a r n i n g l i g h t
14. Dipped beam headlamps
indicator light
15. Battery charge warning light
16. E n g i n e o i l p r e s s u r e a n d
t e m p e r a t u r e w a r n i n g l i g h t
17. W a t e r i n d i e s e l fi l t e r w a r n i n g l i g h t
18. Low coolant level warning light
19. C o o l a n t t e m p e r a t u r e i n d i c a t o r
20. T o t a l d i s t a n c e r e c o r d e r b u t t o n
21. Central (STOP) warning light
22. Speedometer *
23. R e v c o u n t e r
24. L i g h t i n g r h e o s t a t b u t t o n
25. F u e l l e v e l i n d i c a t o r
26. L o w f u e l l e v e l w a r n i n g l i g h t
27. S p e e d l i m i t e r / c r u i s e c o n t r o l
display
* Version indicating kilometres, a c c o r d i n g t o c o u n t r y .
Page 15 of 115
19INSTRUMENTS, CONTROLS and DISPLAYS-
INSTRUMENTS AND CONTROLS
A permanently lit warning light
o r o n e fl a s h i n g , w i t h t h e e n g i n e
r u n n i n g , i n d i c a t e s a n o p e r a t i n g
f a u l t o f t h e u n i t c o n c e r n e d . T h e
i l l u m i n a t i o n o f c e r t a i n w a r n i n g
l i g h t s m a y b e a c c o m p a n i e d b y a n
a u d i b l e s i g n a l a n d a m e s s a g e o n
t h e d i s p l a y . D o n o t i g n o r e t h i s w a r -
n i n g : c o n s u l t a CITROËN d e a l e r
a s s o o n a s p o s s i b l e .
I f t h e c e n t r a l S T O P w a r n i n g l i g h t
c o m e s o n w h e n y o u a r e d r i v i n g ,
s t o p y o u r v e h i c l e i m m e d i a t e l y ,
w h e r e i t i s s a f e t o d o s o .
Central (STOP)
warning light
Linked to the warning
lights:
- ' ' e n g i n e o i l p r e s s u r e a n d t e m p e r a - t u r e ' ' ,
- ''low coolant level'',
- 'handbrake'',
- ' ' l o w b r a k e fl u i d l e v e l ' ' ,
- ' ' e l e c t r o n i c b r a k e f o r c e d i s t r i b u t i o n s y s t e m f a u l t ' ' .
L i n k e d w i t h t h e " c o o l a n t t e m p e r a t u r e "
i n d i c a t o r .
Y o u m u s t s t o p i f t h e l i g h t fl a s h e s
with the engine running.
C o n s u l t a C I T R O Ë N d e a l e r . E n g i n e o i l p r e s s u r e
a n d t e m p e r a t u r e
warning light
Linked to the central (STOP) warning
l i g h t .
Y o u m u s t s t o p .
This warning light indicates one of
the following:
- i n s u f fi c i e n t o i l p r e s s u r e i n d i c a t e d by the message " O i l p r e s s u r e
i n s u f fi c i e n t " o n t h e d i s p l a y .
- a l a c k o f o i l i n t h e l u b r i c a t i o n c i r c u i t . T o p u p t h e l e v e l .
- a n o i l t e m p e r a t u r e w h i c h i s t o o h i g h . T o l o w e r t h e o i l t e m p e r a t u r e , r e d u c e
y o u r s p e e d .
Lighting of the warning light is acco-
m p a n i e d b y a n a u d i b l e s i g n a l .
C o n s u l t a C I T R O Ë N d e a l e r .
L o w e n g i n e c o o l a n t
l e v e l w a r n i n g l i g h t
Linked to the central (STOP)
w a r n i n g l i g h t .
This comes on for a few seconds
w h e n t h e i g n i t i o n i s s w i t c h e d o n .
Lighting of this warning light is acco-
m p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " T o p u p e n g i n e fl u i d l e v e l "
o n t h e d i s p l a y .
Y o u m u s t s t o p .
Wait for the engine to cool before
t o p p i n g u p t h e l e v e l .
T h e c o o l i n g c i r c u i t i s p r e s s u r i s e d . H a n d b r a k e , l o w
b r a k e f l u i d l e v e l a n d
E l e c t r o n i c B r a k e F o r c e
D i s t r i b u t i o n s y s t e m
fault warning light
Linked to the central (STOP) warning
l i g h t .
This comes on each time the ignition
i s s w i t c h e d o n .
Lighting of this warning light is acco-
m p a n i e d b y a n a u d i b l e s i g n a l a n d a
message on the display indicating
t h e c a u s e o f t h e w a r n i n g :
- " H a n d b r a k e o n " , if the handbrake
i s a p p l i e d o r n o t f u l l y r e l e a s e d .
- " B r a k e fl u i d l e v e l l o w " if there is
a n e x c e s s i v e d r o p i n b r a k e fl u i d
level (if the warning light remains
on even when the handbrake is
r e l e a s e d ) .
- " B r a k i n g f a u l t " is displayed to-
gether with the ABS warning
l i g h t , i n d i c a t i n g a m a l f u n c t i o n o f
the Electronic Brake Force Distri-
b u t i o n s y s t e m . Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
In the event of breakdown and to
pre-
v e n t a n y r i s k o f b u r n s , u n s c r e w t h e
c a p b y t w o t u r n s t o a l l o w t h e p r e s s u r e
t o d r o p .
W h e n t h e p r e s s u r e h a s d r o p p e d , r e -
m o v e t h e c a p a n d t o p u p t h e l e v e l .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 16 of 115
INSTRUMENTS, CONTROLS and DISPLAYS20 - B a t t e r y c h a r g e w a r n i n g
light
This comes on for a few se-
conds when the ignition is
s w i t c h e d o n . L i g h t i n g o f t h i s w a r n i n g
l i g h t , w h e n t h e e n g i n e i s r u n n i n g ,
a c c o m p a n i e d b y a n a u d i b l e s i g n a l
and the message " B a t t e r y c h a r g e
fault" on the display, indicates one of
the following:
- f a u l t y o p e r a t i o n o f t h e c h a r g i n g c i r c u i t ,
- slack battery or starter terminals,
- a c u t o r s l a c k a l t e r n a t o r b e l t ,
- a n a l t e r n a t o r f a i l u r e .
C o n s u l t a C I T R O Ë N d e a l e r . E m i s s i o n c o n t r o l
s y s t e m w a r n i n g l i g h t
This comes on for a few sec-
onds each time the ignition is
s w i t c h e d o n .
I f i t c o m e s o n w i t h t h e e n g i n e r u n n i n g ,
a c c o m p a n i e d b y a n a u d i b l e s i g n a l
and the message on the display:
- " A n t i p o l l u t i o n f a u l t " , this indi-
c a t e s a f a i l u r e o f t h e e m i s s i o n
control system
- " C a t a l y t i c c o n v e r t e r f a u l t " , this
i n d i c a t e s a m a l f u n c t i o n o f t h e i n j e -
c t i o n o r i g n i t i o n s y s t e m . T h e r e i s
a risk of damage to the catalytic
c o n v e r t e r ( p e t r o l e n g i n e o n l y ) .
C o n s u l t a C I T R O Ë N d e a l e r .
D i e s e l e n g i n e p r e - h e a t
warning light
W a i t u n t i l t h e w a r n i n g l i g h t
g o e s o u t b e f o r e s t a r t i n g t h e
e n g i n e .
I f t h e t e m p e r a t u r e i s h i g h e n o u g h ,
the warning light comes on for less
t h a n o n e s e c o n d . Y o u c a n s t a r t t h e
e n g i n e w i t h o u t w a i t i n g . L o w f u e l l e v e l
warning light
This comes on for a few
seconds when the igni-
t i o n i s s w i t c h e d o n .
When the ignition is on, it is acco-
m p a n i e d b y a n a u d i b l e s i g n a l a n d
the message " F u e l l e v e l l o w " on the
d i s p l a y .
I f i t fl a s h e s w i t h t h e f u e l g a u g e n e e d l e
in the lowest position, when the igni-
t i o n i s o n , t h i s i n d i c a t e s a m a l f u n c t i o n
o f t h e f u e l g a u g e .
W h e n t h i s w a r n i n g l i g h t fi r s t c o m e s
o n , y o u h a v e e n o u g h f u e l l e f t t o d r i v e
a p p r o x i m a t e l y 3 0 m i l e s ( 5 0 k m ) .
Capacity of the tank:
- approximately 55 litres for petrol engines,
- approximately 60 litres for Diesel e n g i n e s .
W a t e r i n d i e s e l f i l t e r
i n d i c a t o r *
There is a risk of damage to
t h e i n j e c t i o n s y s t e m .
C o n s u l t a C I T R O Ë N d e a l e r a s s o o n
a s p o s s i b l e .
A n t i - l o c k b r a k i n g
s y s t e m ( A B S ) w a r n i n g
light
This comes on for a few seconds each
t i m e t h e i g n i t i o n i s s w i t c h e d o n .
If the warning light remains on or
comes on above 8 mph (12 km/h),
t h i s i n d i c a t e s a n A B S m a l f u n c t i o n .
However, the vehicle retains conven-
t i o n a l s e r v o - a s s i s t e d b r a k i n g .
Lighting of this warning light, acco-
m p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " A B S f a u l t " on the display,
i n d i c a t e s a n A B S f a u l t .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y .
Page 17 of 115
21INSTRUMENTS, CONTROLS and DISPLAYS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is acco-
mpanied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when the
ignition is switched on and it remains
o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few se-
conds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 18 of 115
21INSTRUMENTS, CONTROLS and DISPLAYS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is acco-
mpanied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when the
ignition is switched on and it remains
o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few se-
conds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 19 of 115
INSTRUMENTS, CONTROLS and DISPLAYS22 - S e r v i c e i n d i c a t o r
T h i s i s a v i s u a l r e m i n d e r o f w h e n t h e
n e x t s e r v i c e i s d u e . T h i s s e r v i c e i s t o
b e c a r r i e d o u t a c c o r d i n g t o t h e m a n u -
f a c t u r e r ' s s e r v i c i n g s c h e d u l e . 5 seconds after the ignition is switched
o n , t h e t o t a l d i s t a n c e r e c o r d e r r e s u m e s
normal operation and the display shows
t h e t o t a l o r t r i p d i s t a n c e s .
T h e d i s t a n c e r e m a i n i n g b e f o r e t h e n e x t
s e r v i c e i s l e s s t h a n 5 0 0 m i l e s ( 1 , 0 0 0 k m ) .
Example: 400 miles (900 km) remain
b e f o r e t h e n e x t s e r v i c e i s d u e .
When switching on the ignition and
for 5 seconds, the display shows:
5 seconds after the ignition is switched
o n , t h e t o t a l d i s t a n c e r e c o r d e r r e s u m e s
normal operation and the symbol re-
m a i n s l i t .
T h i s i n d i c a t e s t h a t a s e r v i c e s h o u l d
b e c a r r i e d o u t s h o r t l y . T h e d i s p l a y
s h o w s t h e t o t a l o r t r i p d i s t a n c e s . T h e s e r v i c e i s o v e r d u e .
Each time the ignition is switched on
and for 5 seconds, the symbol and
t h e e x c e s s d i s t a n c e fl a s h .
Example: t h e s e r v i c e i s o v e r d u e b y
3 0 0 m i l e s / k m . T h e s e r v i c e s h o u l d b e
c a r r i e d o u t v e r y s h o r t l y .
When the ignition is switched on and
for 5 seconds, the display shows:
5 seconds after the ignition is switched
o n , t h e t o t a l d i s t a n c e r e c o r d e r r e s u m e s
normal operation and the symbol re-
m a i n s l i t . T h e d i s p l a y s h o w s t h e t o t a l o r
t r i p d i s t a n c e s .
Note: the spanner lights if the two-year
i n t e r v a l h a s b e e n e x c e e d e d .
INSTRUMENT PANEL DISPLAY
After switching on the ignition, three
f u n c t i o n s a r e s h o w n i n s u c c e s s i o n :
- service indicator,
- engine oil level indicator,
- total distance recorder/total and t r i p d i s t a n c e s .
Note
: the total and trip distances are
displayed for 30 seconds when the
ignition is switched off, on opening
the driver's door, as well as on lock-
i n g a n d u n l o c k i n g t h e v e h i c l e .
Example: 4,800 miles/km remain be-
f o r e t h e n e x t s e r v i c e i s d u e . W h e n t h e
ignition comes on and for 5 seconds
the display shows:
Operation
As soon as the ignition is switched
on and for 5 seconds, the spanner
s y m b o l i s i n g ' ' s e r v i c e o p e r a t i o n ' ' i s l i t .
The trip recorder display shows the
d i s t a n c e r e m a i n i n g ( i n r o u n d fi g u r e s )
b e f o r e t h e n e x t s e r v i c e .
