To turn the system off or
on, press and release this
button located on the
center console.
The DIC will display the appropriate message as
described previously when the button is pressed.
Traction Control Operation
Traction control limits wheel spin by reducing engine
power to the wheels (engine speed management)
and by applying brakes to each individual wheel
(brake-traction control) as necessary.
The traction control system is enabled automatically
when the vehicle is started, and it will activate and ash
the ESC/TCS light and display the LOW TRACTION
message if it senses either of the front wheels are
spinning or beginning to lose traction while driving.
For more information on the LOW TRACTION message,
seeDriver Information Center (DIC) on page 3-43.
Notice:If the wheel(s) of one axle are allowed to
spin excessively while the ESC/TCS, ABS and
Brake warning lights and the SERVICE ESC and/or
SERVICE TRACTION messages are displayed,the differential could be damaged. The repairs would
not be covered by the vehicle warranty. Reduce
engine power and do not spin the wheel(s)
excessively while these lights and this message
are displayed.
Notice:When traction control is turned off, it is
possible to lose traction. If you attempt to shift with
the front wheels spinning with a loss of traction,
it is possible to cause damage to the transmission.
Do not attempt to shift when the front wheels do
not have traction. Damage caused by misuse of the
vehicle is not covered. See your warranty book
for additional information.
The traction control system may activate on dry or
rough roads or under conditions such as heavy
acceleration while turning or abrupt upshifts/downshifts
of the transmission. When this happens, a reduction
in acceleration may be noticed, or a noise or vibration
may be heard. This is normal.
If the vehicle is in cruise control when the system
activates, the ESC/TCS light will ash and the cruise
control will automatically disengage. The cruise control
may be re-engaged when road conditions allow.
SeeCruise Control on page 3-10.
Adding non-dealer/non-retailer accessories can affect
the vehicle’s performance. SeeAccessories and
Modifications on page 5-3for more information.
4-9
Lights............................................................3-13
Airbag Readiness........................................3-31
Antilock Brake System (ABS) Warning............3-35
Brake System Warning.................................3-34
Charging System.........................................3-33
Cruise Control.............................................3-42
Engine Coolant Temperature Warning.............3-36
Flash-to-Pass............................................... 3-8
Highbeam On.............................................3-42
High/Low Beam Changer................................ 3-8
Oil Pressure...............................................3-41
On Reminder..............................................3-14
Passenger Airbag Status Indicator..................3-32
Safety Belt Reminders..................................3-30
Security.....................................................3-41
Tire Pressure..............................................3-37
Loading Your Vehicle.......................................4-20
Locks
Delayed Locking..........................................2-11
Door ..........................................................2-10
Lockout Protection.......................................2-12
Power Door ................................................2-10
Programmable Automatic Door Locks.............2-11
Rear Door Security Locks.............................2-12
Loss of Control...............................................4-12
Lower Anchors and Tethers for Children.............1-44
Lumbar
Manual Controls............................................ 1-4M
Maintenance
Footnotes..................................................... 6-7
Maintenance Schedule
Additional Required Services........................... 6-6
At Each Fuel Fill........................................... 6-8
At Least Once a Month.................................. 6-9
At Least Once a Year.................................... 6-9
Maintenance Record....................................6-16
Maintenance Replacement Parts....................6-13
Maintenance Requirements............................. 6-2
Owner Checks and Services........................... 6-8
Recommended Fluids and Lubricants.............6-12
Scheduled Maintenance................................. 6-4
Using.......................................................... 6-2
Your Vehicle and the Environment................... 6-2
Malfunction Indicator Lamp...............................3-38
Manual Lumbar Controls.................................... 1-4
Manual Seats................................................... 1-3
Message
DIC Warnings and Messages........................3-46
Mirrors
Automatic Dimming Rearview........................2-37
Manual Rearview Mirror................................2-37
Outside Automatic Dimming Mirror.................2-39
Outside Heated Mirrors................................2-40
Outside Power Mirrors..................................2-39
MP3 .............................................................3-71
8
W
Warning Lights, Gages, and Indicators...............3-28
Warnings
DIC Warnings and Messages........................3-46
Hazard Warning Flashers............................... 3-6
Safety and Symbols......................................... iii
Wheels
Alignment and Tire Balance..........................5-72
Different Size..............................................5-70
Replacement...............................................5-72
When It Is Time for New Tires..........................5-67
Where to Put the Child Restraint.......................1-42
Windows.......................................................2-15
Power ........................................................2-16Windshield
Washer........................................................ 3-9
Washer Fluid..............................................5-38
Wiper Blade Replacement.............................5-50
Wiper Blades, Cleaning................................5-95
Wiper Fuses...............................................5-98
Wipers......................................................... 3-8
Winter Driving................................................4-17
Winter Tires...................................................5-52
X
XM Radio Messages.......................................3-77
XM™ Satellite Radio Antenna System................3-92
Y
Your Vehicle and the Environment....................... 6-2
14
