2009 Acura RL Owner's Manual

Û
Ý
ÛÝ
ÛÝ
LANGUAGE SELECTION
ADJUST OUTSIDE TEMP.
DISPLAY
Here are the f our custom settings
forthemetersetup:
TRIP A RESET with REFUEL
ELAPSED TIME RESET
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button.
Each time you press the INFO ( / ) button, the screen changes as
shown in the illustration. Press the
INFO ( / ) button until you see
the setting you want to customize,
then press the SEL/RESET button
to enter your selection.
Meter Setup
Multi-Inf ormation Display
94
seepage97
seepage99
seepage101 seepage95
Press the or button. Press the SEL/RESET button.
2009 RL

ÛÝ
There are three language selections
you can make: English, French, and
Spanish. To choose the language you
want, f ollow these instructions:
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button. You will see the
above display.Select the desired language by
pressing the INFO ( / ) button,
then enter your selection by pressing
the SEL/RESET button.
CONT INUED
L anguage Select ion
Multi-Inf ormation Display
Inst rument s and Cont rols
95
2009 RL

ÛÝ
To exit LANGUAGE SELECTION
without changing the current setting,
select EXIT by pressing the INFO
( / ) button, then press the SEL/
RESET button. The screen goes
back to CUSTOMIZE MENU.
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY.
All messages on the multi-
inf ormation display will be shown in
the language you selected. If your choice is not set, you will see
the above display f or several seconds,
then screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
language selection setup.
Multi-Inf ormation Display
96
2009 RL

ÛÝÛ
Ý
While the multi-information display
is in the METER SETUP of the
CUSTOMIZE GROUP, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display. Press the SEL/RESET button. The
screen changes as shown above. The
highlighted number is the current
setting above or below the outside
temperature. Press the INFO ( /
) button repeatedly until the
number you want appears, then
press the SEL/RESET button to
enter your selection.
If you sometimes f ind that the
temperature reading is a f ew
degrees above or below the actual
temperature, you can adjust it by
f ollowing these instructions:
CONT INUED
A djust Outside T emp. Display
Multi-Inf ormation Display
Inst rument s and Cont rols
97
2009 RL

ÛÝ
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY. To exit ADJUST OUTSIDE TEMP.
DISPLAY without changing the
current setting, select EXIT by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
The screen goes back to
CUSTOMIZE MENU.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
adjust outside air temperature
display setup.
Multi-Inf ormation Display
98
2009 RL

ÛÝÛÝ
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display. Press the SEL/RESET button. The
screen changes as shown above.
Select ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
To cause trip A, average f uel
economy A, and average speed to
reset every time you ref uel your
vehicle, f ollow these instructions:
CONT INUED
Multi-Inf ormation Display
T rip A Reset wit h Ref uel
Inst rument s and Cont rols
99
2009 RL

ÛÝ
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY. If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the trip
A reset with ref uel setup.To exit TRIP A RESET with
REFUEL without changing the
current setting, select EXIT by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
The screen goes back to
CUSTOMIZE MENU.
Multi-Inf ormation Display
100
2009 RL

ÛÝ
µ
µ
µ
ÛÝ
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display.
IGN OFF The elapsed time is
reset when you turn the ignition
switch to the LOCK (0) position.
TRIP A The elapsed time is reset
when Trip A is reset.
TRIP B The elapsed time is reset
when Trip B is reset.
Press the SEL/RESET button. The
screen changes as shown above.
Select the desired setting by
pressing the INFO ( / ) button,
then press the SEL/RESET button
to enter your selection.
There are three elapsed time reset
choices you can make:
CONT INUED
Elapsed T ime Reset
Multi-Inf ormation Display
Inst rument s and Cont rols
101
2009 RL
