2009 Acura MDX Owner's Manual

Gross Vehicle Weight Rating
(GVWR)－The maximum allowable
weight of the vehicle, all occupants,
all accessories, all cargo and the
tongue load is 5,952 lbs (2,700 kg).
Gross Axle Weight Ratings
(GAWR) －The maximum allowable
weight of the vehicle, all occupants,
all accessories, all cargo, and the
tongue load must not exceed 2,888
lbs (1,310 kg) on the front axle, and
3,175 lbs (1,440 kg) on the rear axle.
Gross Combined Weight Rating
(GCWR) －The maximum allowable
weight of the fully loaded vehicle and
trailer is 10,053 lbs (4,560 kg) with
the proper hitch. The GCWR must be
reduced 2 percent for every 1,000
feet (305 meters) of elevation. Estimating Loads
The best way to confirm that all loads
are within limits is to check them at a
public scale. For public scales in your
area, check your local phone book,
or contact your trailer dealer or
rental agency for assistance.
To help ensure a safe drive to a scale,
or if you cannot get to a public scale,
we recommend that you estimate
your total trailer weight and tongue
load as described.
To Estimate the Total Trailer WeightAdd the weight of your trailer (as
quoted by the manufacturer) with
everything in or on the trailer. Then
check the tables on page366to make
sure you do not exceed the limit for
your conditions.
To Estimate the Tongue Load1. Park the vehicle on level ground.
2. Measure and record the distance
from the ground to the bottom of
the trailer hitch.
3. Connect the fully loaded trailer to the hitch.
4. Measure again from the ground to the same spot on the bottom of the
hitch.
5. Subtract the second measurement from the first measurement, then
refer to the following table.
CONTINUED
Towing a Trailer
365
Driving
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

MDX and Technology Packages models
If the
difference is: Estimated
tongue load is:
13/32 ’’
11/16 ’’
31/32 ’’
1 1/4 ’’ 150 lbs (68 kg)
250 lbs (114 kg)
350 lbs (159 kg)
450 lbs (205 kg)
U.S. Sport Packages and Canadian Elite
models
If the
difference is: Estimated
tongue load is:
1/2 ’’
27/32 ’’
1 5/32 ’’
1 1/2 ’’ 150 lbs (68 kg)
250 lbs (114 kg)
350 lbs (159 kg)
450 lbs (205 kg)
If the difference is more than 1 ꀨ
inch, you have too much load on the
tongue. Redistribute the load or
remove cargo as needed.
Towing a Trailer36608/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Total Trailer Weight and Tongue Load Limits:
Number of
Occupants
ꭧ
Maximum Total Trailer Weight Maximum Tongue Load
2 5,000 lbs (2,268 kg) 500 lbs (227 kg)
3 4,751 lbs (2,155 kg) 470 lbs (213 kg)
4 4,500 lbs (2,041 kg) 370 lbs (168 kg)
5 4,250 lbs (1,928 kg) 276 lbs (125 kg)
6 3,999 lbs (1,814 kg) 150 lbs (68 kg)
7 Towing is Not Recommended
ꭧ
The corresponding weight limits assume occupants fill seats from the front of the vehicle to the back, each occupant weighs 150 lbs
(70 kg), and each has 15 lbs (7 kg) of cargo in the cargo area. Any additional weight, including cargo or accessories, reduces the
maximum trailer weight and maximum tongue load. Never exceed the gross axle weight ratings (see page 364).
ꭧꭧ
Recommended tongue load should be 5－15% of the total trailer weight for boat trailers, and 8 －15% of the total trailer weight for
all other trailers.
CONTINUED
Towing a Trailer
367
Driving
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Checking Loads
To accurately check your loads at the
public scale, the vehicle and trailer
should be fully loaded, and all
occupants should stay in the vehicle
while the attendant watches the
scale.1. Check the front gross axle weight.Limit: 2,888 lbs (1,310 kg)
2. Check the gross vehicle weight.Limit: 5,952 lbs (2,700 kg)
3. Check the rear gross axle weight. Limit: 3,175 lbs (1,440 kg)
4. If you cannot weigh the rear axle directly, you can calculate the rear
gross axle weight by subtracting
the weight in step 1 from the
weight in step 2.
Limit: 3,064 lbs (1,390 kg)
5. Check the gross combined weight.Limit: 10,053 lbs (4,560 kg)
Remember, maximum gross
combined weight should be
decreased 2% for every 1,000 feet
(305 meters) of elevation.
Towing a Trailer36808/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

6. Check the weight of the hitchedtrailer. Write this number down.
7. Check the weight of the unhitchedtrailer. Limit: See page366.
8. Calculate the tongue load. Subtract the weight in step 6 from the
weight in step 7.
Limit: See page366.
Recommended: see page364.
Range: 5-10% for boat trailers 8-15% for other trailers Towing Equipment and
Accessories
Towing generally requires a variety
of supplemental equipment. To
ensure the best quality, we
recommend that you purchase Acura
equipment whenever possible.
Your dealer offers a trailer package
that includes a hitch, a ball mount,
and a wiring harness.
Discuss any additional needs with
your trailer sales or rental agency,
and make sure all equipment is
properly installed, maintained, and
also meets state, federal, province,
and local regulations.
CONTINUED
Towing a Trailer
369
Driving
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

HitchWe strongly recommend that you
have your dealer install a class 3
hitch. Using non-Acura equipment
may result in serious damage to your
vehicle.
Read the trailer manufacturer's
instructions, and select the
appropriate draw bar for the height of
the trailer you will be towing.Weight Distributing HitchA weight distributing hitch is not
recommended for use with your
vehicle, as an improperly adjusted
weight distributing hitch may reduce
handling, stability, and braking
performance.
Trailer BrakesAcura recommends that any trailer
with a total trailer weight of 1,000 lbs
(450 kg) or more has its own brakes.
There are two common types of
trailer brakes: surge and electric.
Surge brakes are common for boat
trailers, since the brakes will get wet.
If you choose electric brakes, be sure
they are electronically actuated. Do
not attempt to tap into your vehicle's
hydraulic system. No matter how
successful it may seem, any attempt
to attach trailer brakes to your
vehicle's hydraulic system will lower
braking effectiveness and create a
potential hazard.
See your trailer manufacturer for
more information on installing
electric brakes.A 4-pin gray connector is available as
an option at your dealer. This
connector has all of the circuits
required to install most electric
trailer brake controllers. A jumper
harness to adapt your electric trailer
brake controller to the vehicle is
included with the optional Acura
Genuine trailer hitch kit. To obtain a
connector and a trailer hitch kit, see
your dealer.
Have a qualified mechanic install
your trailer brake controller
following the trailer brake controller
manufacturer's instructions. Failure
to properly install the trailer brake
controller may increase the distance
it takes for you to stop your vehicle
when towing a trailer.
Towing a Trailer37008/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Use this illustration to identify each
terminal in the trailer brake
controller connector.
Safety ChainsAlways use safety chains when you
tow a trailer. Make sure the chains
are secured to the trailer and hitch,
and that they cross under the tongue
and can catch the trailer if it becomes
unhitched. Leave enough slack to
allow the trailer to turn corners
easily, but do not let the chains drag
on the ground.Sway ControlThis device is recommended if your
trailer tends to sway. Your trailer
maker can tell you what kind of sway
control you need and how to install it.Trailer MirrorsMany states and provinces require
special exterior mirrors when towing
a trailer. Even if they don't, you
should install special mirrors if you
cannot clearly see behind you, or if
the trailer creates a blind spot.
Spare TiresWhen towing a trailer, we
recommend that you carry a full-size
spare wheel and tire for your vehicle
and trailer. See page419for proper
tire size, page425for how to store a
full size wheel and tire, and page425
for information on changing a flat
tire.
Remember to unhitch the trailer
before changing a flat. Ask your
trailer sales or rental agency where
and how to store the trailer's spare
tire.
BRAKE
(20A)
(BLUE)
ELECTRIC BRAKE
(YELLOW)
GROUND
(BLACK)
STOP
(LIGHT GREEN)
CONTINUED
Towing a Trailer
371
Driving
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
2009 MDX

Trailer LightsTrailer lights and equipment must
comply with federal, state, province,
and local regulations. Check trailer
light requirements for the areas
where you plan to tow, and use only
equipment designed for your vehicle.
Your vehicle is equipped with a
connector to install an optional trailer
lighting connector that mates with
your vehicle. You can get this
optional connector from your dealer.Refer to the above illustration for
wiring information.
We recommend that you have your
dealer install an Acura wiring
harness and converter. This harness
has been designed for your vehicle.If you use a non-Acura trailer lighting
harness and converter, you can get
the mating connector and pins that
mate with the connector in your
vehicle from your dealer.
Since lighting and wiring vary with
trailer type and brand, you should
also have a qualified mechanic install
a suitable connector between the
vehicle and the trailer.
ACCESSORY OPTION TRAILER BACK-UP LIGHT
BACK-UP LIGHT (ꭥ)
BRAKE
DIAGNOSTIC
ELECTRIC BRAKE
TRAILER HAZARD
LIGHT
TAILLIGHTS
ꬽ B CHARGE
LEFT TURN
SIGNAL
RIGHT TURN
SIGNAL ILLUMINATION
LIGHTS
Towing a Trailer37208/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
