I
I N S T R U M E N T S a n d C O N T R O L S
26
Message is on Cause Solution - action Observations
Air bags Fixed Fault in the air bags or
pretensioners. Consult a CITROËN
dealer.
Service Fixed Problem in one of the systems
w h i c h d o e s n o t h a v e a s p e c i fi c
message. Stop the vehicle and
contact a CITROËN
dealer. To identify the
problem, contact a
CITROËN dealer.
Engine oil pressure Fixed Engine oil pressure too low or
fault in the oil circuit. Stop the vehicle and
contact a CITROËN
dealer.
Engine oil level Fixed Engine oil level too low. Stop the vehicle and
check the level using
the dipstick. If there is a lack of
oil, top up the level.
Fuel level warning Fixed The fuel tank level is low. Fill your fuel tank as
soon as possible.
Fuel circuit Fixed Fuel circuit fault. Consult a CITROËN
dealer.
Accesses
not closed correctly Fixed
One of the doors or the tailgate
is not closed correctly. Close the door or the
tailgate. The access
concerned is
indicated on the
display.
Page 24 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
27
Message is on Cause Solution - action Observations
Dynamic stability control
system (ASC) Fixed
Dynamic stability control system
(ASC) fault. Consult a CITROËN
dealer.
Four wheel
drive system Fixed Four wheel drive transmission
system fault. Consult a CITROËN
dealer.
Four wheel
drive system temperature Fixed The temperature of the four
wheel drive transmission
system is too high. Stop the vehicle and
contact a CITROËN
dealer. The vehicle switches
to front wheel
drive (2 WD) mode
automatically.
Automatic headlamp
adjustment system Fixed
The automatic headlamp
adjustment is faulty. Consult a CITROËN
dealer. O n l y o n v e h i c l e fi t t e d
with xenon bulbs.
Battery charge Fixed Battery charge fault. Stop the vehicle and
contact a CITROËN
dealer.
Exterior
temperature Fixed The exterior temperature 3 °C
(37 °F) or below. Road icy.
Pay attention and
drive slowly. Caution: The road
may be icy even
when this screen is
not displayed.
Page 25 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
28
Message is on Cause Solution - action Observations
Saturation of the particle
e m i s s i o n fi l t e r Fixed
Start of saturation of the particle
e m i s s i o n fi l t e r . A s s o o n a s t r a f fi c
conditions permit,
r e g e n e r a t e t h e fi l t e r
by driving at a speed
of at least 35 mph
(60 km/h) until the
message is cleared. If the message is still
displayed, contact a
CITROËN dealer.
Diesel
additive level Fixed Low diesel additive level. Have the level
topped up by a
CITROËN dealer
without delay.
Water in the d i e s e l fi l t e r
(according to country) Fixed The presence of water in the
d i e s e l fi l t e r i s i n d i c a t e d .
Risk of damage to the injection
system on Diesel engines. Contact a CITROËN
dealer without delay.
Page 26 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
29
Prevention messages
I n f o r m a t i o n m e s s a g e s ( i g n i t i o n a t " O N " )
Message is on S t a t u s o f t h e s y s t e m
2WD two wheel drive system Flashing When the "2WD" (2 wheel drive) mode is selected using the
transmission mode selector.
4WD four wheel drive system Flashing When the "4WD" (4 wheel drive) mode is selected using the
transmission mode selector.
This mode is the default mode.
4WD LOCK four
wheel drive system Flashing When the "LOCK" (4 wheel drive) mode is selected using the
transmission mode selector.
Exterior
temperature Fixed This indicates the exterior temperature.
When the vehicle is stationary or if the speed is below 12 mp
h
(20 km/h) the temperature displayed may not correspond to the
exterior temperature.
D i s p l a y is on Cause Solution - action Observations
Service
indicator Fixed Informs the driver of
the time remaining
before the vehicle's
scheduled service. Consult a CITROËN
dealer.
This is displayed for a few
seconds when the ignition is
switched on.
Break
advised Fixed Informs the driver that
he should stop to take
a break. You are advised to
take a break. This is displayed when the
driving time that you set
previously is reached.
An audible signal is heard
3 times and is then heard every
5 minutes until the vehicle
stops.
Page 27 of 230
I
30
The total distance is dis-
played in zone 1 of the
display and the trip dis-
tance in zone 2 (refer to
the "Distance recorders"
section).
Distance recorder (A and B)
INFORMATION ON THE
INSTRUMENT PANEL DISPLAY
D a t a d i s p l a y s
With the ignition on, press the
INFO but-
ton, located on the fascia to the right of
the instrument panel, to display the vari-
ous information displays in succession:
- the distance recorder A,
- the distance recorder B,
- the service indicator,
- the coolant temperature,
- the range,
- the trip computer,
- the setting menu.
This displays the distance
and the number of months
remaining before the next
service to be carried out in
accordance with the manu-
facturer’s servicing schedule
(refer to the "Service indica-
tor" section).
Service indicator
When the engine is run-
ning, this indicates the
temperature of the cool-
ant (refer to the "Coolant
temperature indicator"
section).
C o o l a n t t e m p e r a t u r e When the engine is run-
ning, this indicates the
number of miles (kilo-
metres) which can still
be travelled with the fuel
remaining in the tank in
relation to the average
consumption over the
last few miles (kilometres) travelled (re-
fer to the "Range" section).
Range
This indicates the aver-
age consumption, the
average speed and the
current consumption (re-
fer to the "Trip computer"
section).
T r i p c o m p u t e r
When the vehicle is
s t a t i o n a r y , this allows
the user to change the
following parameters
(refer to the "Function
parameters" section):
- the display language,
- the temperature dis- play unit,
- the fuel consumption unit,
- the option to reinitialise the aver- age consumption and the average
speed,
- the break (rest) reminder display in- terval.
Setting menu
Page 28 of 230
I
!
!
I N S T R U M E N T S a n d C O N T R O L S
31
The total distance is dis-
played in zone 1 of the
display and the trip dis-
tance in zone 2 .
DISTANCE RECORDERS (A/B)
System for measuring the total dis-
tance travelled by the vehicle during its
service life and the distance travelled in
a day or other period until it is reset to
zero by the driver.
Zero reset
With the ignition on, press the INFO
button for more than 2 seconds until
zeros appear.
When the engine is run-
ning, this indicates the tem-
perature of the coolant.
COOLANT TEMPERATURE
If the bar is close to the critical position
located on the right, the temperature is
too high.
T h e s y m b o l fl a s h e s w h e n y o u r e n g i n e
is overheating.
I t i s i m p e r a t i v e t h a t y o u s t o p y o u r
v e h i c l e s a f e l y .
W a i t a f e w m i n u t e s b e f o r e s w i t c h i n g
o f f t h e e n g i n e .
Wait for the engine to cool before
topping up the level. The cooling
system is pressurised.
When the engine is
running , this indicates
the distance which can
still be travelled with
the fuel remaining in the
tank in relation to the av-
erage consumption over
the last few miles/kilo-
metres travelled.
RANGE
When the range is less than 30 miles
(50 km) , dashes are displayed.
Fill the fuel tank as soon as possible.
The display of the range is updated.
To avoid any risk of scalding, unscrew
the cap by two turns to allow the pres-
sure to drop.
When the pressure has dropped, re-
move the cap and top up the level, if
necessary.
Consult a CITROËN dealer. T h i s fi g u r e m a y i n c r e a s e f o l l o w i n g a
change in the style of driving or the
relief, resulting in a reduction in the
current consumption.
If you only add a few litres, the value
displayed will be incorrect. There-
f o r e , y o u m u s t fi l l t h e t a n k w h e n e v e r
possible.
When you disconnect the battery,
the previous consumption data is
lost and the value displayed will
be different from that displayed before
the battery was disconnected. The dis-
tance displayed must be considered
an approximate indication.
Page 29 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
32
SERVICE INDICATOR Resetting the service indicator to zero
Your CITROËN dealer carries out this
operation after each service.
If you have carried out your vehicle's
service yourself, the zero reset proce-
dure is the following:
switch off the ignition.
press the INFO button several times
in succession until the service indi-
cator is displayed.
press and hold the INFO button for
a few seconds until the s p a n n e r
fl a s h e s .
press the INFO button while the
s p a n n e r i s fl a s h i n g t o c h a n g e t h e
display "---" to "CLEAR" then the
time remaining before the next serv-
ice is due is displayed.
Service overdue
O p e r a t i o n
When the ignition is switched on, you
must press the INFO button several
times in succession until the service
indicator is displayed. The distance re-
corder display line indicates the number
of miles (kilometres) remaining and the
time elapsed line indicates the number
of months remaining before the next
service is due.
After a certain distance and a certain
time, the displaying of "---" is reinitialised
and the display indicates the time re-
maining before the next service is due.
System which informs the driver when
the next service is due in accordance
with the manufacturer's servicing
schedule.
The point at which the next service is
due is calculated from the last service
indicator zero reset.
It is determined by two parameters:
- the distance travelled (in miles (km),
- the time elapsed since the last service (in months).
The distance remaining to be travelled
may be weighted by the time factor, de-
pending on the user's driving habits.
E x a m p l e : the display indicates that
7 300 miles (kilometres) remain before
the next service is due.
The symbol "--" remains displayed
u n t i l t h e fi r s t s e r v i c e o f a n e w v e h i c l e
has been carried out.
E x a m p l e : the display indicates that the
service is overdue. This service must
be carried out by a CITROËN dealer.
Each time the ignition is switched on,
the display
"SCHEDULED SERVICE"
is displayed for a few seconds to indi-
cate that the service must be carried
out without delay.
Page 30 of 230
I
!
!
I N S T R U M E N T S a n d C O N T R O L S
31
The total distance is dis-
played in zone 1 of the
display and the trip dis-
tance in zone 2 .
DISTANCE RECORDERS (A/B)
System for measuring the total dis-
tance travelled by the vehicle during its
service life and the distance travelled in
a day or other period until it is reset to
zero by the driver.
Zero reset
With the ignition on, press the INFO
button for more than 2 seconds until
zeros appear.
When the engine is run-
ning, this indicates the tem-
perature of the coolant.
COOLANT TEMPERATURE
If the bar is close to the critical position
located on the right, the temperature is
too high.
T h e s y m b o l fl a s h e s w h e n y o u r e n g i n e
is overheating.
I t i s i m p e r a t i v e t h a t y o u s t o p y o u r
v e h i c l e s a f e l y .
W a i t a f e w m i n u t e s b e f o r e s w i t c h i n g
o f f t h e e n g i n e .
Wait for the engine to cool before
topping up the level. The cooling
system is pressurised.
When the engine is
running , this indicates
the distance which can
still be travelled with
the fuel remaining in the
tank in relation to the av-
erage consumption over
the last few miles/kilo-
metres travelled.
RANGE
When the range is less than 30 miles
(50 km) , dashes are displayed.
Fill the fuel tank as soon as possible.
The display of the range is updated.
To avoid any risk of scalding, unscrew
the cap by two turns to allow the pres-
sure to drop.
When the pressure has dropped, re-
move the cap and top up the level, if
necessary.
Consult a CITROËN dealer. T h i s fi g u r e m a y i n c r e a s e f o l l o w i n g a
change in the style of driving or the
relief, resulting in a reduction in the
current consumption.
If you only add a few litres, the value
displayed will be incorrect. There-
f o r e , y o u m u s t fi l l t h e t a n k w h e n e v e r
possible.
When you disconnect the battery,
the previous consumption data is
lost and the value displayed will
be different from that displayed before
the battery was disconnected. The dis-
tance displayed must be considered
an approximate indication.
