2008 TOYOTA xD Accessories, Audio & Navigation (in English)

25
Radio ID
Refer to the corresponding chart to
verify the Radio ID Code before
contacting XM Satellite Radio to
activate your service.
Corresponding chart
ID Display
1
2
3
5
6
8 7
9 4
0E C B
A
D
G F (Not used.)
J
K I (Not used.) HO (Not used.)
L
MR
U Q P
S (Not used.)
T
V
Z X W
ID Display ID
Y Display
N

26
Using the AUX
By inserting a mini plug into the
AUX adapter, you can listen to
music from a portable audio device
through the vehicle’s speaker sys-
tem.
1AUX•iPod
Switches to the AUX mode.
1AUX•iPod
CAUTION
When using a portable audio
device connected to the
power outlet or cigarette
lighter, noise may occur dur-
ing playback.
If this happens, use the
power source of the portable
audio device.

27
NOTICE
•If the mini plug of a com-
mercially available cable
connected to a portable
audio or other component is
not connected to the car
AUX adapter, the mode will
not change to the AUX
mode even if you press the
AUX•iPod button.
•Volume level when playing
a component connected
with a mini plug differs to
that when listening to the
built-in CD player or radio
so please make adjust-
ments.
•If you install an audio sys-
tem other than a Scion
Genuine Audio, you will not
be able to use the AUX
adapter.

28
Changing the
Opening Screen
With the main unit switched on
after pressing the Power button,
once the key is turned from the
ACC position to the off position and
back to ACC again, “Scion” is dis-
played as the Opening Screen.
Users can edit the text themselves
to make another Opening Screen,
as an alternate to the default
“Scion” display. Up to a maximum
of 16 characters can be displayed.
The procedure is described below.
1Moving to “Customize Mode”
to Enable Editing
1 With the main unit on, turn the
key from the ACC position to the
off position.
2
On the main unit, press and hold
MUTE button then turn the key to
ACC. The horizontal line in the LCD
display will start flashing.
3 Within 15 sec. after confirming
the horizontal line is flashing, press
and hold the PRESET 1 button
then turn the key to OFF position.
(If 15 sec. elapses before you com-
plete the button presses, “TIME
OUT” will be displayed and the
unit will beep twice. If this occurs,
repeat the procedure from Step 1).
This completes shifting to the cus-
tomize mode.
POWER
MUTE
PRESET3-6PRESET1

29
2Editing the Text
After completing the shift to cus-
tomize mode, a flashing cursor
shows the letter that can be edited by
selecting a letter starting from “A”.
The letter selection method is
described below. The time allowed
for editing is limited to 60 sec.
1 Press the PRESET 3 or 4 buttons
to change the flashing letter by
displaying other letters one by
one. The letters will change con-
tinuously if you press and hold the
PRESET 3 or 4 button.
List of the letters and numbers
that can be selected.
•Upper case letters (A to Z)
•Lower case letters (a to z)
•Numbers 0 to 9, spaces, sym-
bols (!”# and so on)
2 With the character that you want
to select displayed, press the
PRESET 6 button to select it.
After selecting the character, the
cursor moves to the right so you
can edit the next character. After
you select the 16th character, the
entire line starts flashing.
To delete a selected character,
press the PRESET 5 button. After
you delete a character the cursor
shifts left so you can edit the pre-
vious character. If you delete all ofthe text, you can edit from the
first character.
3 After you are finished selecting
the text for the line, press and
hold down the PRESET 6 button.
The selected text string is regis-
tered as the Opening Screen. The
customize mode ends and the
registered text string is displayed
for 6 sec.
3New Message Display
The next time the ACC is switched
on, the text edited by the user will be
displayed.
NOTICE
To prevent the battery from
being discharged, do not
leave the car audio on longer
than necessary when the
engine is not running.
NOTICE
•If the unit leaves the cus-
tomize mode during editing,
repeat procedure
1from
Step 2.
•If the edit is registered with
no new text, the original
Opening Screen, “Scion” ,
will be restored.

30
Using the Steering
Controller
In vehicles equipped with one, you can use the steering controller to operate this product.
Operation button names and functions
7Volume buttons (ª, ·)
Press ªto raise the volume level.
Press ·to lower the volume level.
7Mode selection button (MODE)
•When power to this product is OFF:
Press the button and power switch-
es ON.
•When power to this product is ON:
Each time you press the button the
*source changes. If you continue
pressing the button for an extended
period, power to this product switch-
es OFF.
*The source switches in the follow-
ing order:
FM1 =FM2 =CD(MP3/WMA/AAC) =
(CD-CH)=(iPod) =(AUX) =AM =
(SAT1) =(SAT2) =(SAT3) =FM1
7Track/station selection button
(4, ¢)
•When listening to the radio:
Press the button and the preset
memory is recalled in order. If you
continue pressing the button for an
extended period, automatic station
selection begins.
•When listening to a CD:
Press the button to select a track.
•When listening to MP3/ WMA/A AC:
Press the button to select a file.
Press and hold the button to select a
folder.
•When listening to the iPod:
Press the button to select a track.
•When listening to a SAT broadcast:
Press the button to recall preset
channels in order.

31
MP3, WMA and A AC
files
• MP3 is short for MPEG Audio Layer 3 and
refers to an audio compression technology
standard.
• WMA is short for Windows Media
TMAudio
and refers to an audio compression tech-
nology that is developed by Microsoft
Corporation. WMA data can be encoded
by using Windows Media Player version 7
or later.
• AAC is short for Advanced Audio Coding
and refers to an audio compression tech-
nology standard.
• With some applications used to encode
WMA files, this unit may not operate cor-
rectly.
• With some applications used to encode
WMA files, album names and other text
information may not be correctly dis-
played.
• This unit allows playback of MP3/ WMA /A AC
files on CD-ROM, CD-R and CD-RW discs.
Disc recordings compatible with level 1
and level 2 of ISO9660 and with the
Romeo and Joliet file system can be
played back.
• MP3/WMA/AAC files are not compatible
with packet write data transfer.
• The maximum number of characters which
can be displayed for a file name, including
the extension (.mp3, .wma, .m4a), is 64 ,
from the first character.
• The maximum number of characters whichcan be displayed for a folder name is 64 .
• In case of files recorded according to the
Romeo file system, only the first 64 char-
acters can be displayed.
• The folder selection sequence for playback
and other operations becomes the writing
sequence used by the writing software.
For this reason, the expected sequence at
the time of playback may not coincide with
the actual playback sequence. However,
there also is some writing software which
permits setting of the playback order.
MP3 additional infor-
mation
• Files are compatible with the ID3 Tag Ver.
1.0, 1.1, 2.2, 2.3 and 2.4 formats for dis-
play of album (disc title), track (track title),
artist (track artist) and comments. Ver. 2.x
of ID3 Tag is given priority when both Ver.
1.x and Ver. 2.x exist.
• The emphasis function is valid only when
MP3 files of 32, 44.1 and 48 kHz frequen-
cies are played back. (16, 22.05, 24, 32,
44.1, 48 kHz sampling frequencies can be
played back.)
• There is no m3u play list compatibility.
• There is no compatibility with the MP3i
(MP3 interactive) or mp3 PRO formats.
• The sound quality of MP3 files generally
becomes better with an increased bit
rates. This unit can play recordings with bit
rates from 32 kbps to 320 kbps, but in
order to be able to enjoy sound of a certain
quality, we recommend using only discs
recorded with a bit rate of at least 128
kbps.
IMPORTANT
•When naming an MP3/
WMA/AAC file, add the cor-
responding filename exten-
sion (.mp3, .wma, .m4a).
•This unit plays back files
with the filename extension
(.mp3, .wma, .m4a) as an
MP3/ WMA /AAC file. To pre-
vent noise and malfunc-
tions, do not use these
extensions for files other than
MP3/WMA/AAC files.

32
WMA additional infor-
mation
• This unit plays back WMA files encoded by
Windows Media Player version 7, 7.1, 8, 9
and 10.
• You can only play back WMA files in the
frequencies 32, 44.1 and 48 kHz.
• The sound quality of WMA files generally
becomes better with an increased bit rate.
This unit can play recordings with bit rates
from 48 kbps to 320 kbps (CBR) or from
48 kbps to 384 kbps (VBR), but in order to
be able to enjoy sound of a certain quality,
we recommend using discs recorded with
a higher bit rate.
• This unit doesn’t support the following for-
mats.
Windows Media Audio 9 Professional(5.1ch)
Windows Media Audio 9 Lossless
Windows Media Audio 9 Voice
AAC additional infor-
mation
• This unit plays back AAC files encoded by
iTunes®version 4.8 and earlier.
• This unit plays back AAC files in the sam-
pling frequencies 11.025, 16, 22.05, 24, 32,
44.1 and 48 kHz
• The sound quality of AAC files generally
becomes better with an increased trans-
mission rate. This unit can play recordings
with transmission rates from 16kbps to
320kbps,but in order to be able to enjoy
sound of a certain quality, we recommend
using discs recorded with a higher trans-
mission rate.
• This unit doesn’t support the following for-
mats.
- Apple Lossless
About folders and
MP3/WMA/AAC files
• An outline of a CD-ROM with MP3/WMA/AAC
files on it is shown below. Subfolders are
shown as folders in the folder currently
selected.
001.mp3
(001.wma, 001.m4a)
010.mp3
(010.wma, 010.m4a)
021.mp3
(021.wma, 021.m4a)
030.mp3
(030.wma, 030.m4a)
011.mp3
(011.wma, 011.m4a)
020.mp3
(020.wma, 020.m4a)
First
levelSecond
levelThird
level
01
(ROOT)
02
04
05
03
