2008 TOYOTA RAV4 Owners Manual

’08 Rav4_U (L/O 0802)
241
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
This system supports Bluetooth, a
wireless system that allows you to
make or receive calls without taking
your hands from the steering wheel and
without using cables to connect the
phone and system.
The phone must be paired to the system
before using the hands −free feature. If
your cellular phone does not support
Bluetooth , this system will not function.
CAUTION
While you are driving, do not use a
cellular phone or connect the
Bluetooth  phone.
NOTICE
Do not leave your cellular phone in
the car. The temperature indoor may
be high and damage the phone.
The system may not function in the follow-
ing conditions and places:
The cellular phone is turned off.
The current position is outside the
communication area.
The cellular phone is not connected.
The cellular phone has a low battery.
The cellular phone is located behind
the seat or in the glove box and con-
sole box.
The cellular phone touches or is cov-
ered with metal materials.
This system supports the following ser-
vice.
HFP (Hands Free Profile) Ver.1.0
OPP (Object Push Profile) Ver.1.1
If your cellular phone does not support
HFP, you cannot enter the Bluetooth
phone, and take OPP service individually.
Bluetooth is a trademark owned by
Bluetooth SIG. Inc. When transferring ownership of the ve-
hicle:
A lot of personal data is registered
when you use the handsfree system.
When transferring ownership of the ve-
hicle, initialize the system.
If you initialize it, the former state will
never come back again. Pay much atten-
tion when initializing the data.
You can initialize the following data in the
system.
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth
 phone data
Security code

’08 Rav4_U (L/O 0802)
242
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
FCC ID: BABBT010A
IC ID: 2024BBT010A
MADE IN CHINA
This device complies with Part 15 of the
FCC Rules and RSS −210. Operation is
subject to the following two conditions:
(1) This device may not cause harmful
interference, and (2) This device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
NOTE: This equipment has been
tested and found to comply with the
limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installa-
tion. This equipment generates, uses
and can radiate radio frequency ener-
gy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not oc-
cur in a particular installation. If this
equipment does cause harmful inter-
ference to radio or television recep-
tion, which can be determined by turn-
ing the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
− Reorient or relocate the receiving an-
tenna.
− Increase the separation between the
equipment and receiver.
− Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
− Consult the dealer or an experienced
radio/TV technician for help.CAUTION: Radio Frequency Radiation
Exposure
This equipment complies with FCC/IC
radiation exposure limits set forth for
uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65
and RSS −102 of the IC radio frequen-
cy (RF) Exposure rules. This equip-
ment has very low levels of RF ener-
gy that it deemed to comply without
maximum permissive exposure evalua-
tion (MPE). But it is desirable that it
should be installed and operated with
at least 20 cm and more between the
radiator and person’s body (excluding
extremities: hands, wrists, feet and
legs).
Colocation: This transmitter must
not be co −located or operated in con-
junction with any other antenna or
transmitter.

’08 Rav4_U (L/O 0802)
243
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
Steering switches
Microphone
1. Volume control switch
To increase the volume: Push “+”.
To decrease the volume: Push “ −”.
When driving at 80 km/h (50 mph) or
more, the volume automatically increases
without switch adjustment. When your
speed falls below 70 km/h (43 mph), the
volume automatically returns to its original
level.
Voice guidance volume cannot be changed
by pushing the volume control switch on
the steering wheel. 2. Talk switch
Pushing the talk switch turns the hands −
free system on and initiates the speech
command system.
3. Onhook switch
When the hands −free system is on, push-
ing the on −hook switch turns the hands −
free system off.
Pushing and holding the talk switch ends
the speech command system.
4. Offhook switch
Pushing the off −hook switch turns the
hands −free system on.
When receiving a call, pushing the off −
hook switch allows you to talk on the
phone. 5. Microphone
The microphone is used when talking on
the phone or using the speech command
system.
—Control and features
 Steering switches and microphone

’08 Rav4_U (L/O 0802)
244
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
1. Display
Displays such items as the reception lev-
el, a party’s name and phone number. See
“DISPLAY” described on the following
page for further details about the display.
2. “AUDIO CONTROL” knob
Turning the “AUDIO CONTROL” knob dis-
plays the menu items, names, numbers,
etc. to be selected. To select an item,
push the “AUDIO CONTROL” knob. Due to
safety concerns, the “AUDIO CONTROL”
knob does not function while the vehicle
is in motion.
3. “TEXT” button
When the party’s name or phone number
is too long to be displayed, pushing and
holding the “TEXT” button displays the re-
maining characters.
4. Preset buttons
Pushing the preset button displays the
registered speed dial numbers.

Audio unit

’08 Rav4_U (L/O 0802)
245
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
DISPLAY1. Bluetooth  display
Displays when a Bluetooth  connection is
made. If there is no display, the
Bluetooth  connection has not been made
and communication between the phone
and system is not possible. When using
the hands −free system, make sure that
[BT] is displayed. The display is updated
in real time. 2. Reception level display
Displays the cellular phone reception lev-
els. This may not match the display on
the cellular phone. The reception level of
some cellular phones may not be dis-
played.
The number of bars is greater when the
signal received is stronger.
3. Message display
Displays phone numbers, names, com-
ments, menu items, etc. The phone setup menu includes the fol-
lowing:
Pair Phone
To use the hands −free system, you need
to register your phone in the system.
Once you have registered it, you can
make a hands −free call. Up to 6 phones
can be registered.
Select Phone
When the system connects to Bluetooth ,
the phone previously used is automatically
selected. Select a different phone if nec-
essary. Only the selected phone can be
used with the hands −free system.
Change Name
The registered phone names can be
changed.
List Phones
The registered phone names can be
checked.
The following can be performed during the
name playback:
Select phone
Change name
Delete
—Phone Setup

’08 Rav4_U (L/O 0802)
246
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
Set PassKey
The passkey can be c hanged. A 4 to 8
digit code can be input as a pa sskey.
Delete
The registered phones can be deleted.
To enter the phone setup menu 1. Push the off −hook switch to turn the
hands −free system on.
2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Setup] is displayed and push the knob.
[Setup. Please push the talk switch and
say security, or phone setup.] is heard.
3. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Phone Setup] is displayed and push
the knob.
[Phone setup. Push the talk switch and
say pair phone, select phone, change
name, list phones, set pa sskey or delete.]
is heard.
[XXX (phone name) already selected.] is
heard and the phone name is displayed.
If no phone has been registered, the sys-
tem may not function properly. To pair phones
1. Push the talk switch and say [Pair phone], or turn the “AUDIO CONTROL”
knob until [Pair Phone] is displayed
and push the knob.
[Pair. Push the talk switch and say a
name for the phone.] is heard. 2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Record Name] is displayed, push the
knob and say the desired phone name.
[Push the talk switch and say confirm.
Otherwise, say go back.] is heard. 3. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Confirm] is displayed and push the
knob.
[XXX (desired phone name) Ready for
phone pairing. Please use the phone to
connect it to the hands −free system. The
passkey for the p hone is....] is heard.
After [HANDS FREE] is displayed, a pass-
key
∗ is displayed and [Searching.] is
heard.
4. Input the displayed passkey into the phone. [The phone is paired and ready for use.
Returning to the main menu.] is heard and
[Paired] is displayed.
The system may not function in the follow-
ing cases:
If 6 phones have already been regis-
tered.
If the vehicle is moving.
If the system cannot communicate with
the phone.
∗: Passkey is a password r
equired to reg-
ister a phone to the system.
INFORMATION
To use the handsfree system, you
need to register your phone in the
system. Once you have registered
it, you can make a handsfree call.
Up to 6 phones can be registered.
For the operation of the phone, see
the manual that comes with your
cellular phone.
The passkey can be changed. See
page 249 for changing the passkey.

’08 Rav4_U (L/O 0802)
247
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
To select a phone1. Push the talk switch and say [Select phone], or turn the “AUDIO CONTROL”
knob until [Select Phone] is displayed
and push the knob.
[Select phone. Push the talk switch and
say the phone name or say list phones.]
is heard. 2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
the desired phone name is displayed
and push the knob.
When the phone is selected by a voice
command:
[XXX (phone name) Push the talk switch
and say confirm. Otherwise, say go back.]
is heard and the phone name is displayed.
Follow voice guidance instructions, or turn
the “AUDIO CONTROL” knob until [Con-
firm] is displayed and push the knob.
[XXX selected. Returning to the phone
setup.] is heard. When the phone is selected by using
the knob:
[XXX selected. Returning to the phone
setup.] is heard.
The system may not function in the follow-
ing cases:
If the phone is not found.
If the system does not recognize the
voice command.
To change a name
1. Push the talk switch and say [Change name], or turn the “AUDIO CONTROL”
knob until [Change Name] is displayed
and push the knob.
[Change name. Push the talk switch and
say the phone name to change.] is heard. 2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
the phone name that you want to
change is displayed and push the
knob.

’08 Rav4_U (L/O 0802)
248
2008 RAV4 from Feb. ’08 Prod. (OM42726U)
When the phone is selected by a voice
command:
[XXX (phone name) Push the talk switch
and say confirm. Otherwise, say go back.]
is heard and the phone name is displayed.1. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Confirm] is displayed and push the
knob.
[Push the talk switch and say a new
name.] is heard. 2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Record Name] is displayed, push the
knob and say the desired phone name.
[XXX Push the talk switch and say con-
firm. Otherwise, say go back.] is heard. 3. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Confirm] is displayed and push the
knob.
[Name changed. Returning to the phone
setup.] is heard and [Changed] is dis-
played. When the phone is selected by using
the knob:
[XXX Push the talk switch and say con-
firm. Otherwise, say go back.] is heard
and the phone name is displayed.
1. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Confirm] is displayed and push the
knob.
[Push the talk switch and say a new
name.] is heard. 2. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Record Name] is displayed, push the
knob and say the desired phone name.
[XXX Push the talk switch and say con-
firm. Otherwise, say go back.] is heard. 3. Follow voice guidance instructions, or turn the “AUDIO CONTROL” knob until
[Confirm] is displayed and push the
knob.
[Name changed. Returning to the phone
setup.] is heard and [Changed] is dis-
played. The system may not function in the follow-
ing cases:
If no phone has been registered.
If the system does not recognize the
voice command.
To list phones 1. Push the talk switch and say [List phones], or turn the “AUDIO CON-
TROL” knob until [List Phones] is dis-
played and push the knob.
[List phones. To select a name, push the
talk switch during the name playback.] is
heard. 2. Follow voice guidance instructions.
[Push the talk switch and say select
phone, change name, or delete.] is heard.
Select one of the following:
