2008 TOYOTA FJ CRUISER engine

252
3−5. Other interior features
Compass (if equipped)
The compass indicates the direction that the vehicle is heading.
 Operation
The compass points north for
about 3 seconds after the
engine switch is turned to the
ON position, and then indi−
cates the actual direction the
vehicle facing.
When the engine switch is
turned to the ACC or LOCK
position, it indicates the actual
direction for about 5 seconds
and then points in a random
direction.
 Displays and directions
Display Direction
NNorth
EEast
SSouth
WWest

255
3−5. Other interior features
3
Interior features
 Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:
The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
The engine switch is turned off immediately after turning.
The vehicle is on an inclined surface.
The vehicle is in a place where the earth’s magnetic field is subject to
interference by artificial magnetic fields (underground car park/parking
lot, under a steel tower, between buildings, roof car park/parking lot, near
an intersection, near a large vehicle, etc.).
 The vehicle has become magnetized.
(There is a magnet or metal object on or near the accessory meter.)

The battery has been disconnected.
CAUTION
 While driving the vehicle
Do not adjust the display. Be sure to adjust the display only when the vehicle
is stopped.
 When doing the circling calibration
Be sure to secure a wide space, and watch out for people and vehicles in the
neighborhood. Do not violate any local traffic rules while performing circling
calibration.

264 4−2. Maintenance
 Allow inspection and repairs to be performed by a Toyota dealer
 Toyota technicians are well−trained specialists and are kept up to date
with the latest service information. They are well informed about the
operations of all systems on your vehicle.
 Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty coverage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly
take care of it.
CAUTION
 Warning in handling of battery
 Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause cancer and birth defects and other reproductive harm. Work in a
well ventilated area.
 Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor−
nia to cause cancer and birth defects or other reproductive harm. Avoid
exposure and wash any affected area immediately.
 Battery posts, terminals and related accessories contain lead and lead
compounds which are known to cause brain damage. Wash your hands
after handling. (
P. 283)

265
4−2. Maintenance
4
Maintenance and care
General maintenance
Engine compartment
Items Check points
Battery Maintenance−free. ( P. 283)
Brake fluid At the correct level? ( P. 280)
Engine coolant At the correct level? ( P. 279)
Engine oil At the correct level? ( P. 275)
Exhaust system No fumes or strange sounds?
Power steering fluid At the correct level? (
P. 282)
Radiator/condenser/hosesNot blocked with foreign matter?
(
P. 280)
Washer fluid At the correct level? (
P. 286)
Listed below are the general maintenance items that should be per
formed at the intervals specified
in the “Scheduled Maintenance
Guide” or “Owner ’s Manual Supp lement”. It is recommended that
any problem you notice should be brought to the attention of your
Toyota dealer or qualifie
d service shop for advice.

267
4−2. Maintenance
4
Maintenance and care
Vehicle exterior
Steering wheel
Moves smoothly?
Has correct free play?
No strange noises?
Items Check points
DoorOperate smoothly?
Engine hoodThe lock system works properly?
Fluid leaksIs there any leakage after park−
ing?
Ti reInflation pressure is correct?
Tire surfaces not worn or dam−
aged?
Tires rotated according to the
maintenance schedule?
Wheel nuts are not loose?
CAUTION
 If the engine is running
Turn the engine off and ensure that there is adequate ventilation before per−
forming maintenance checks.
ItemsCheck points

269
4
Maintenance and care
4−3. Do−it−yourself maintenance
Do−it−yourself ser vice precautions
If you perform maintenance yourself, be sure to follow the correct
procedures as given in these sections.
Items Parts and tools
Battery condition ( P. 283)Warm water
Baking soda
Grease
Conventional wrench
(for terminal clamp bolts)
Brake fluid level ( P. 280)FMVSS No.116 DOT 3 or SAE
J1703 brake fluid
Rag or paper towel
Funnel (used only for adding
brake fluid)
Engine coolant level ( P. 279)“Toyota Super Long Life Coolant”
or similar high quality ethylene
glycol based non−silicate, non−
amine, non−nitrite and non−borate
coolant with long−life hybrid
organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant”
is pre−mixed with 50% coolant
and 50% deionized water.
Canada:
“Toyota Super Long Life Coolant”
is pre−mixed with 55% coolant
and 45% deionized water.
Funnel (used only for adding
engine coolant)
Engine oil level P. 275)Toyota Genuine Motor Oil or
equivalent
Rag or paper towel
Funnel (used only for adding oil)
Fuses ( P. 303)Fuse with same amperage rating
as original

271
4−3. Do−it−yourself maintenance
4
Maintenance and care
CAUTION
The engine compartment contains many mechanisms and fluids that may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury observe the following precautions.
 When working on the engine compartment
 Keep hands, clothing, and tools away from the moving fan and engine
drive belt.
Be careful not to touch the engine, radiator, exhaust manifold, etc. right
after driving as they may be hot. Oil and other fluids may also be hot.
 Do not leave anything that may burn easily, such as paper or rags, in the
engine compartment.
Do not smoke, cause sparks or expose an open flame to fuel or the bat−
tery. Fuel and battery fumes are flammable.
 Be extremely cautious when working on the battery. It contains poisonous
and corrosive sulfuric acid.
Take care because brake fluid can harm your hands or eyes and damage
painted surfaces.
If fluid gets on your hands or in your eyes, flush the affected area with
clean water immediately.
If you still experience discomfort, see a doctor.
When working near the cooling fan or radiator grille
Be sure the engine switch is off.
With the engine switch on, the cooling fan may automatically start to run if
the air conditioning is on and/or the coolant temperature is high.
 Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc. from
getting in the eyes.

272 4−3. Do−it−yourself maintenance
NOTICE
 If you remove the air cleaner
Driving with the air cleaner removed may cause excessive engine wear due
to dirt in the air. Also a backfire could cause a fire in the engine compart−
ment.
 If the fluid level is low or high
It is normal for the brake fluid level to go down slightly as the brake pads
wear or when the fluid level in the accumulator is high.
If the reservoir needs frequent refilling, it may indicate a serious problem.
