2008 TOYOTA FJ CRUISER engine

192 3−2. Using the audio system
 Welcome function (type B only)
When you turn the engine switch to the ACC or ON position, “FJ CRUISER”
will appear scrolling on the display. A
nd then “FJammer” will appear for 6
seconds.
While this function is operating, the display is illuminated with full intensity
and the instrument panel light control dial is disabled. However, you can turn
off the display illumination by pushing the .
 Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
Ti t l ePage
Using the radioP. 194
Using the CD playerP. 200
Playing back MP3 and WMA discsP. 208
Optimal use of the audio systemP. 217
Operating the sub wooferP. 220
Changing display colorP. 221
Using the AUX adapterP. 222
Using the steering wheel audio switchesP. 224

193
3−2. Using the audio system
3
Interior features
CAUTION
 For vehicles sold in U.S.A. and Canada
 Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifications to this equipment will void the
user ’s authority to operate this device.
 Laser products
Do not take this unit apart or attempt to make any changes yourself.
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disas−
semble the player or alter any of its parts since you may be exposed to
laser rays and dangerous voltages.
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation expo−
sure.
NOTICE
 To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine off.

To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.

226
3−3. Using the interior lights
Interior lights list
 Illuminated entry system
When the interior light switch is in the DOOR position, the interior light auto−
matically turns on/off according to whether the doors are locked/unlocked
and whether the doors are open/closed and the engine switch position.
 To prevent the battery from being discharged
If the interior light remains on when the door is not fully closed and the inte−
rior light switch is in the DOOR position, the light will go off automatically
after 30 minutes.
 Customization that can be configured at Toyota dealer
Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features
P. 386)
Front interior light (P. 227)
Rear interior light (
P. 227)
1
2

237
3−5. Other interior features
3
Interior features
Clock
 The clock is displayed when
The engine switch is in the ACC or ON position.
When disconnecting and reconnecting battery terminals
The time display will automatically be set to 1:00.
Adjusts the hours
Adjusts the minutes

238
3−5. Other interior features
Outside temperature display (if equipped)
 When – –C or – –F is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
The outside air temperature is displayed when
The engine switch is in the ON position.
 When disconnecting and reconnecting battery terminals
The display will automatically be set to the initial mode.
Displays the outside air
temperature.
The temperature range that
can be displayed is from −22°F
(−30°C) to 122°F (50°C).
Switches the outside air
temperature display
between English/U.S. Cus−
tomary System and metric.

239
3−5. Other interior features
3
Interior features
Power outlet (12V DC)
 The power outlet can be used when
The engine switch is in the ACC or ON position.
NOTICE
 To avoid damaging the power outlet
Close the power outlet lid when not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir−
cuit.
 To prevent the fuse from being blown
Do not use an accessory that uses more than 12V/10A.
To prevent the battery discharge
Do not use the power outlet longer than necessary when the engine is not
running.
The power outlet can be used for 12 V accessories that run on less
than 10A.

241
3−5. Other interior features
3
Interior features
 The power outlet can be used when
The engine is started.
The indicator light changes according the maximum available capacity,
as follows:
 When the power outlet is in operation
The sound of the cooling fan may be heard from the right side of the luggage
compartment. This is normal and does not indicate a malfunction.
The maximum capacity is 115V AC/400W when the following
condition applies:
Vehicles with an automatic transmission:
The shift lever is in P or N.
Vehicles with a manual transmission:
The shift lever is in N and the clutch pedal is not depressed.
A maximum capacity of 400W can only be restored by turning
the power outlet main switch off and then on again under con−
dition described above.
The maximum capacity is 115V AC/100W when the following
condition applies:
Vehicles with an automatic transmission:
The shift lever is moved to any positions other than P and
N.
Vehicles with a manual transmission:
The clutch pedal is depressed.
Indicates 115V AC/400W
Indicates 115V AC/100W

242 3−5. Other interior features
 If the engine is started with the power outlet main switch on
The maximum capacity of the power supply may decrease to below the stan−
dard, or may be cut off completely, even when the vehicle is stationary.
 The protection circuit may be activat ed to cut the power supply if any
of the following conditions apply:
The engine is started with the power outlet main switch on.
Use of electrical appliances exceeding the maximum capacity is
attempted.
A sound may be heard when the protection circuit is activated.
This is normal and does not indicate a malfunction.
 Electrical appliances, which consume power exceeding 100W, have
been used continuously for a long time period.
The total power usage by all electrical features (headlights, air condition−
ing, etc.) has exceeded the total vehicle maximum for an extended
period of time.
 If the protection circuit is activated
and the power supply is cut, con
duct the following procedure:
Park the vehicle in a safe place, and then securely apply the park−
ing brake.
Check and ensure the following conditions
Vehicles with an automatic transmission:
The shift lever is in P or N.
Vehicles with a manual transmission:
The shift lever is in N and the clutch pedal is not depressed.
Make sure that the power consumption of the electric appliance is
within the maximum capacity of the power outlet and the appliance
is not broken.
Press the power outlet main switch again.
When the cabin temperature is high, open the windows to cool the tempera−
ture down. Once it reaches the normal temperature, turn the power outlet
main switch on again.
If the power supply is not resumed even after performing the above proce−
dure, have the vehicle inspected by a Toyota dealer.
