2008 SUBARU TRIBECA fog light bulb

10Illustrated index&Exterior
1) Engine hood lock release (page 11-4)
2) Headlight switch (page 3-26)
3) Bulb replacement (page 11-41)
4) Wiper switch (page 3-34)
5) Moonroof (page 2-23)
6) Roof rail (if equipped) (page 8-13)
7) Door locks (page 2-4)
8) Tire pressure (page 11-25)
9) Flat tires (page 9-6)
10) Tire chains (page 8-11)
11) Fog light switch (page 3-32)
12) Tie-down hooks (page 9-15)
13) Towing hook (page 9-15)
ProCarManuals.com

Maintenance and serviceReplacement of wiper blades...................... 11-33
Windshield wiper blade assembly .................. 11-33
Windshield wiper blade rubber ...................... 11-34
Rear window wiper blade assembly ............... 11-35
Rear window wiper blade rubber .................... 11-35
Battery........................................................... 11-37
Fuses ............................................................ 11-38
Main fuse ...................................................... 11-39
Installation of accessories ........................... 11-40
Replacing bulbs ........................................... 11-41
Headlights (Vehicles with HID headlights) ...... 11-42
Headlights (Vehicles without HID headlights) .................................................. 11-43
Parking light (right-hand side) ........................ 11-44 Front turn signal light (right-hand side)
......... 11-45
Front fog light ............................................... 11-45
Rear combination lights ................................ 11-46
Back-up light/Tail light .................................. 11-47
Rear gate light .............................................. 11-47
License plate light ........................................ 11-47
Dome light .................................................... 11-48
Map light ...................................................... 11-49
Vanity mirror light ......................................... 11-49
Door step light .............................................. 11-50
Cargo area light ............................................ 11-50
ProCarManuals.com

11-42
Maintenance and service
Wattage Bulb No.
1) High beam headlight 12V-65W HB3
2) Low beam headlight
Vehicle with HID light 12V-35W D1S
Vehicle without HID light 12V-55W H7
3) Front turn signal/Parking light 12V-28/8W 2357NA
4) Parking/Front side marker light 12V-5W 168(W5W)
5) Map light 12V-8W –
6) Dome light
Vehicles with Rear Seat Entertainment 12V-5W–
Vehicles without Rear Seat Entertainment 12V-8W–
7) Door step light 12V-3W –
8) Vanity mirror light 12V-3W
9) Fog light 12V-55W H3
10) Cargo area light 12V-13W 912
11 ) Tail light 12V-5W 168
12) Brake/tail light 12V-27/8W 1157(W27/8W)
13) Rear turn signal light 12V-27W 1156(W27W)
14) Back-up light 12V-16W 921
15) Rear gate light 12V-5W (W5W)
16) License plate light 12V-5W 168(W5W)
CAUTION
Replace any bulb only with a new
bulb of the specified wattage. Using
a bulb of different wattage could
result in a fire.&
Headlights (Vehicles with HID
headlights)
WARNING
High-intensity-discharge (HID) bulbs
are used for the low beams of the
headlights. These HID bulbs use an
extremely high voltage. To avoid the
risk of an electric shock and result-
ing serious injury, you should not
attempt to replace them. Neither
should you attempt to replace the
high-beam bulbs, remove/refit the
headlight assemblies, or remove
any headlight-assembly compo-
nents. For replacement of the head-
light bulbs (low-beam and high-
beam), removal and installation of
the headlight assemblies, and re-
moval of headlight-assembly com-
ponents, contact your SUBARU
dealer.
ProCarManuals.com

2. Pull the bulb out of the socket. Install a
new bulb.
3. Set the bulb socket into the headlight
assembly and turn it clockwise until it
locks.NOTEContact your SUBARU dealer for the
bulb replacement of the left-hand side.
&Front turn signal light (right-
hand side)1. Remove the bulb socket from the
headlight assembly by turning it counter-
clockwise.
2. Remove the bulb from the socket by
pushing it and turning counterclockwise.
Install a new bulb.
3. Set the bulb socket into the headlight
assembly and turn it clockwise until it
locks.NOTEContact your SUBARU dealer for the
bulb replacement of the left-hand side.&Front fog lightIt may be difficult to replace the bulbs.
Have the bulbs replaced by your SUBARU
dealer if necessary.
Maintenance and service
11-45
–CONTINUED –
ProCarManuals.com

12-8
Specifications
Bulb chartDescriptionWattageBulb No.
High beam headlight 12V-65WHB3
Low beam headlight
Vehicles with HID light 12V-35WD1S
Vehicles without HID light 12V-55WH7
Fog light 12V-55WH3
Front turn signal/Parking light 12V-28/8W
2357NA
Parking/Front side marker light 12V-5W
168(W5W)
Rear combination light Rear turn signal light 12V-27W1156(W27W)
Brake/tail 12V-27/8W1157(W27/8W)
Tail light 12V-5W
168
Back-up light 12V-16W
921
License plate light 12V-5W
168(W5W)
Cargo area light 12V-13W
912
Dome light Vehicles with Rear Seat Entertainment 12V-5W
–
Vehicles without Rear Seat Entertainment 12V-8W
–
Map light 12V-8W
–
Vanity mirror light 12V-3W
–
Door step light 12V-3W
–
Rear gate light 12V-5W
(W5W)
ProCarManuals.com

Wiper blades....................................................... 11-35
Recommended Automatic transmission fluid .................................. 11-16
Brake fluid. .......................................................... 11-21
OIL grade and viscosity ............. 11-9, 11-10, 11-17, 11-18
Power steering fluid .............................................. 11-20
Spark plugs ......................................................... 11-15
Remote engine start system ......................................... 7-8
Remote keyless entry system ....................................... 2-7
Replacement Brake pad and lining ............................................ 11-22
Wiper blades ....................................................... 11-33
Replacing Air cleaner element .............................................. 11-14
Battery (remote keyless entry system) ....................... 2-7
Lost transmitters (keyless entry system) .................... 2-11
Replacing bulbs ....................................................... 11-41
Backup light/Tail light ............................................ 11-47
Cargo area light ................................................... 11-50
Clearance light .................................................... 11-44
Dome light .......................................................... 11-48
Door step light ..................................................... 11-50
Front fog light ...................................................... 11-45
Front turn signal light ............................................ 11-45
Headlight ............................................................ 11-42
License plate light ................................................ 11-47
Map light ............................................................. 11-49
Rear combination light .......................................... 11-46
Rear gate light ..................................................... 11-47
Vanity mirror light ................................................. 11-49
Rocking the vehicle .................................................... 8-11 Roof rail and crossbar
................................................ 8-13
S
Safety Precautions when driving ............................................. 4
Symbol ...................................................................... 2
Warnings ................................................................... 2
Seat Fabric .................................................................. 10-5
Heater .................................................................... 1-6
Memory function ...................................................... 1-4
Seatbelt. ........................................................................\
4
Maintenance ......................................................... 1-27
Pretensioners ........................................................ 1-27
Safety tips ............................................................ 1-15
Warning light and chime ................................. 1-17, 3-10
Seatbelts .................................................................. 1-15
Security ID plate .......................................................... 2-3
Selector lever ............................................................ 7-13
Position indicator ................................................... 3-20
Shift lock release ....................................................... 7-17
Shock sensors .......................................................... 2-18
Shopping bag hook .................................................... 6-12
Snow tires ................................................................ 8-10
Snowy

and icy roads ................................................... 8-9
Sounding a panic alarm ............................................. 2-10
Spare tire ................................................................... 9-2
Spark plugs ............................................................. 11-15
Specifications ............................................................ 12-2
Speedometer .............................................................. 3-6
SPORT mode indicator light ........................................ 3-20
Index
14-7
