2008 SMART FORTWO COUPE engine

Let the fun begin!
Take a moment to familiarize yourself with
your smart fortwo coupé or smart fortwo ca

brio and read through the Operator’s Manual
before setting off. This will ensure you get
more fun out of your vehicle
and avoid dan

ger to yourself and others.
This Operator’s Manual contains very impor

tant information about how to safely and ef

fectively operate the vehicle. It is important
to note that this is a unique vehicle. It is obvi

ously smaller than most vehicles on the road
and, for this reason, it can provide both
unique experiences and special responsibili

ties. It is extremely important that you read
this entire Manual and that you familiarize
yourself with how the vehicle works. Some of
the features may be different from the fea

tures on other compact passenger vehicles.
Should you have any questions about the vehi

cle and how to safely operate its features,
please use common sense and contact smart
dealer representatives, who are available to
help you.smart is a vehicle manufactured by
DaimlerChrysler, distributed in the United
States by the Penske Automotive Group, and
sold and serviced by independent, authorized
smart centers.
Because of this vehicle’s unique characteris

tics, we strongly recommend that you service
and maintain the vehicle only at authorized
smart service facilities. A list of service facil

ities is available by calling smart Customer
Assistance representatives at:
1
800
762
7887.
Although we cannot prevent you from servic

ing the vehicle at facilities other than smart
authorized facilities, this is not advisable.
Optional extras are identified with an
asterisk *. The equipment in your vehicle may
vary depending on the model, version and
availability. smart is constantly bringing its
vehicles up to the very latest state of the art
and reserves the right to modify them in form,
equipment and engineering.Should you find that a particular feature in
this manual is important to your decision to
purchase the vehicle, we recommend that you
personally check the vehicle to ensure that
this feature has been installed before buying
the vehicle.
The Operator’s Manual, Quick Guide and Main

tenance/Warranty Booklet (USA only) or Ser

vice/Warranty Booklet (Canada only) belong to
the vehicle. You should always keep these
documents in the vehicle and make sure that
you pass them on to the next owner if and when
you come to sell your smart.
Please contact an authorized smart center if
you have any further questions.
The Technical Documentation team at
DaimlerChrysler AG wishes you many happy
hours at the wheel.

>> Keywords
5
Display message
Data bus . . . . . . . . . . . . . . . . . . . . . . . . . 236
Electronic immobilizer . . . . . . . . . . . . . . 236
Shifting system . . . . . . . . . . . . . . . . . . . . 236
Display, see Multifunction display
Door control panel . . . . . . . . . . . . . . . . . . . 44
Door handle . . . . . . . . . . . . . . . . . . . . . . . . . 85
Door locking system
Locking and unlocking from outside . . . . 83
DOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Drive lock function . . . . . . . . . . . . . . . . . . . 84
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Driving abroad . . . . . . . . . . . . . . . . . . . . . 223
Driving off
Uphill . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Driving safety systems
ABS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Activating the hazard warning flasher . . 76
ESP
® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Hydraulic brake assistant . . . . . . . . . . . . 75
Driving tips . . . . . . . . . . . . . . . . . . . . . . . . 211
Catalytic converter . . . . . . . . . . . . . . . . 215
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
>> EElectric fuses . . . . . . . . . . . . . . . . . . . . . 282
Electrical and electronic devices, see Engine
electronics
Electronic immobilizer . . . . . . . . . . . . . . . 77
Display message . . . . . . . . . . . . . . . . . . 236
Electronic Stability Program, see "ESP
®"
Emergency Tensioning Device . . . . . . . . . 53
Emmission control . . . . . . . . . . . . . . . . . . 221
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Compartment . . . . . . . . . . . . . . . . . . . . 171
Electronics . . . . . . . . . . . . . . . . . . . . . . 290
Malfunction indicator lamp . . . . . . . . . . . 35
Starting . . . . . . . . . . . . . . . . . . . . . . . . . 122
Technical data . . . . . . . . . . . . . . . . . . . 297
Turning off . . . . . . . . . . . . . . . . . . . . . . 127
Engine oil . . . . . . . . . . . . . . . . . . . . . 172, 305
Adding . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Additives . . . . . . . . . . . . . . . . . . . . . . . . 305
Checking the oil level . . . . . . . . . . . . . . 173
Pressure indicator lamp . . . . . . . . . . . . . 35
EPS (Electronic Power Steering)*
Warning lamp . . . . . . . . . . . . . . . . . . . . 243
ESP
®(Electronic Stability Program) . 73, 243Exterior lamp switch . . . . . . . . . . . . . . . . 101
Exterior lighting
Overview . . . . . . . . . . . . . . . . . . . . . . . . 255
See also Brake lamp
See also Front fog lamps*
See also High beam headlamps
See also License plate lamps
See also Low beam headlamp
See also Parking lamps
See also Sidemarker lamps front/rear
See also Turn signal indicators
See also Turn signal lamps, side
Exterior rear view see Mirrors
Exterior view . . . . . . . . . . . . . . . . . . . . . . . 30
>> FFirst
aid kit* . . . . . . . . . . . . . . . . . . . . . . 235
Flat tire . . . . . . . . . . . . . . . . . . . . . . 234, 265
Fluid capacities . . . . . . . . . . . . . . . . . . . . 303
Front fog lamps* . . . . . . . . . . . . . . . 105, 255
Front lamps
Overview . . . . . . . . . . . . . . . . . . . . . . . . 255

>> Keywords
7
>> KKey
Replacing the transmitter battery . . . . 252
With remote control . . . . . . . . . . . . . . . . . 82
Kickdown . . . . . . . . . . . . . . . . . . . . . . 131, 134
Kilometer reading, see Trip odometer>> LLabels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Lamp in the overhead control panel . . . . . 64Lamps, indicator and warning
ABS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Air bags, SRS indicator lamp . . . . . . . . 246
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 238
Brake system . . . . . . . . . . . . . . . . . . . . 238
Coolant temperature . . . . . . . . . . . . . . 241
Engine malfunction . . . . . . . . . . . . . . . . 242
EPS* warning lamp . . . . . . . . . . . . . . . . 243
ESP
® . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Front fog lamps* . . . . . . . . . . . . . . . . . . 105
High beam headlamps . . . . . . . . . . . . . . 244
Low beam headlamp . . . . . . . . . . . . . . . 244
Oil pressure . . . . . . . . . . . . . . . . . . . . . 242
Passenger air bag off . . . . . . . . . . . . . . 245
Seat belt . . . . . . . . . . . . . . . . . . . . . . . . 245
TPMS combination telltale . . . . . . . . . . 239
Turn signal indicators . . . . . . . . . . . . . 247
Layout of the poly
V
belt . . . . . . . . . . . . 296
License plate lamps . . . . . . . . . . . . . . . . . 255
Light alloy wheels
Technical data . . . . . . . . . . . . . . . . . . . 299Lighting
Automatic headlamp mode . . . . . . . . . . . 102
Coming home function* . . . . . . . . . . . . . 105
Daytime running lamp mode . . . . . . . . . 103
Exterior lamp switch . . . . . . . . . . . . . . . 101
Front fog lamps* . . . . . . . . . . . . . . . . . . 105
Hazard warning flasher . . . . . . . . . . . . . 107
High beam . . . . . . . . . . . . . . . . . . . . . . . 104
High beam flasher . . . . . . . . . . . . . . . . . 104
Interior lighting . . . . . . . . . . . . . . . . . . 107
Low beam . . . . . . . . . . . . . . . . . . . . 102, 223
Multifunction display, instrument
illumination . . . . . . . . . . . . . . . . . . 136, 141
Parking lamps . . . . . . . . . . . . . . . . . . . . 102
Limp
home mode . . . . . . . . . . . . . . . . . . . 134
Loading . . . . . . . . . . . . . . . . . . . 155, 185, 204
Locking
And unlocking, inside . . . . . . . . . . . . . . . 84
And unlocking, outside . . . . . . . . . . . . . . 83
Loss of
Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Service and Warranty Information
Booklet . . . . . . . . . . . . . . . . . . . . . . . . . 289
Low beam headlamp . . . . . . . . . . . . . . . . . 255
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . 303

8>> Keywords>> MMain dimensions . . . . . . . . . . . . . . . . . . . 302
Main odometer display . . . . . . . . . . . . . . 136
Maintenance service interval display . . 139
Malfunction
Data bus . . . . . . . . . . . . . . . . . . . . . . . . 236
Electronic immobilizer . . . . . . . . . . . . . 236
Shifting system . . . . . . . . . . . . . . . . . . . 236
Manual gearshift
Gear selector lever,
gearshift paddle . . . . . . . . . . . . . . . . . . 132
Gearshift pattern . . . . . . . . . . . . . . . . . 128
Maximum load rating . . . . . . . . . . . . . . . . 205
Maximum loaded vehicle weight . . . . . . . 205
Maximum tire inflation pressure . . . . . . 205
Miles reading, see Trip odometer
Mirrors
Exterior . . . . . . . . . . . . . . . . . . . . . . . . . 96
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . 97
MON . . . . . . . . . . . . . . . . . . . . . . . . . 170, 306
Motor Octane Number see MON
MP3 interface* . . . . . . . . . . . . . . . . . . . . . 144Multifunction display
Digital clock . . . . . . . . . . . . . . . . . . . . . 138
Illumination . . . . . . . . . . . . . . . . . . . . . . 136
Selecting display for status indicator . 138
>> NNeutral gear position
Automatic/manual transmission . . 128, 129
Normal occupant weight . . . . . . . . . . . . . 205
Number, Vehicle identification (VIN) . . . 294>> OOccupant Classification System see OCS
Occupant distribution . . . . . . . . . . . . . . . 205
Occupant safety . . . . . . . . . . . . . . . . . . . . . 48
OCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Passenger front air bag off
indicator lamp . . . . . . . . . . . . . . . . . . . . . 64
Seat belts . . . . . . . . . . . . . . . . . . . . . 50, 98
SRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
OCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Self
test . . . . . . . . . . . . . . . . . . . . . . . . . 64
Oil, see Engine oilOn
board Diagnostics Socket (OBD) . . . . 292
Operating safety . . . . . . . . . . . . . . . . . . . . . 22
Operating your vehicle outside the USA or
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operator’s Manual . . . . . . . . . . . . . . . . . . . 17
Outside temperature display . . . . . . . . . . 136
Overhead control panel . . . . . . . . . . . . . . . 43
>> PPaintwork care see Vehicle care
Panic alarm . . . . . . . . . . . . . . . . . . . . . . . . . 71
Panorama roof* . . . . . . . . . . . . . . . . . . . . 164
Parcel net bag . . . . . . . . . . . . . . . . . . 41, 156
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Parking brake . . . . . . . . . . . . . . . . . . . . . . 125
Parking lamps . . . . . . . . . . . . . . . . . . . . . . 255
Parts service . . . . . . . . . . . . . . . . . . . . . . 288
PASS AIR BAG OFF indicator lamp see Passen

ger front air bag off indicator lamp
Passenger air bag see Air bags
Passenger compartment . . . . . . . . . . . . . 220
Passenger front air bag off indicator
lamp . . . . . . . . . . . . . . . . . . . . . . . . . . 64, 245
Passenger safety see Occupant safety

10
>> Keywords Self
test
OCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Service
Information . . . . . . . . . . . . . . . . . . . . . . . 19
Maintenance . . . . . . . . . . . . . . . . . . . . . . 19
Service and warranty
Booklet . . . . . . . . . . . . . . . . . . . . . . . . . 289
Information . . . . . . . . . . . . . . . . . . . . . . . 17
Service flap . . . . . . . . . . . . . . . . . . . . . . . 176
Service interval display . . . . . . . . . . . . . 139
Display . . . . . . . . . . . . . . . . . . . . . . . . . 136
Service life (Tire) . . . . . . . . . . . . . . . . . . 183
Shifting . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Side rails
Mounting . . . . . . . . . . . . . . . . . . . . . . . . 118
Removing . . . . . . . . . . . . . . . . . . . . . . . 116
Side windows . . . . . . . . . . . . . . . . . . . . . . 120
Sidemarker lamps front/rear . . . . . . . . . 255
Sidewall . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Sign and labels . . . . . . . . . . . . . . . . . . . . 293
Smartmove Assistance . . . . . . . . . . . . . . . . 19
Snow chains* . . . . . . . . . . . . . . . . . . . . . . 209Soft top system
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 230
Closing rear soft top . . . . . . . . . . . . . . 251
Mounting the side rails . . . . . . . . . . . . . 118
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Opening and closing, rear soft top . . . 115
Opening and closing, retractable
soft top . . . . . . . . . . . . . . . . . . . . . . . . . 113
Removing the side rails . . . . . . . . . . . . 116
Sound package* . . . . . . . . . . . . . . . . . . . . 144
SRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Indicator lamp . . . . . . . . . . . . . . . . . . . . 246
Standing water, driving instructions . . . 219
Steering wheel gearshift control*
Activating, shifting . . . . . . . . . . . . . . . . 132
Overview . . . . . . . . . . . . . . . . . . . . . . . . . 42
Storage compartments
Coin holder . . . . . . . . . . . . . . . . . . . . . . 159
Coinholder . . . . . . . . . . . . . . . . . . . . . . . . 41
Cup holder . . . . . . . . . . . . . . . . . . . . 41, 155
Door pockets . . . . . . . . . . . . . . . . . . 41, 160
Glove box . . . . . . . . . . . . . . . . . . . . . 41, 160
Next to the steering wheel . . . . . . . 41, 160
Tailgate coupé . . . . . . . . . . . . . . . . 41, 161
Storing tires . . . . . . . . . . . . . . . . . . . . . . 184
Sun roof see Panorama roof*
Sun screen* . . . . . . . . . . . . . . . . . . . . . . . 164Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . 164
>> TTachometer* . . . . . . . . . . . . . . . . . . . . . . . 140
Tail lamps . . . . . . . . . . . . . . . . . . . . . . . . . 255
Tailgate
cabrio . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
coupé . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Technical data
Air conditioning refrigerant . . . . . . . . . 305
Brake fluid . . . . . . . . . . . . . . . . . . . . . . . 305
Coolants . . . . . . . . . . . . . . . . . . . . . . . . . 309
Electrical system . . . . . . . . . . . . . . . . . . 300
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . 305
Fuel additives . . . . . . . . . . . . . . . . . . . . 307
Fuel requirements . . . . . . . . . . . . . . . . . 306
Premium unleaded gasoline . . . . . . . . . . 306
Rims and tires . . . . . . . . . . . . . . . . . . . . 298
Service fluids and capacities . . . . . . . . 303
Vehicle main dimensions . . . . . . . . . . . . 302
Weights . . . . . . . . . . . . . . . . . . . . . . . . . 301
Windshield/rear window washer system 308

>> Keywords
11
Temperature
Setting (air conditioning with
automatic climate control*) . . . . . . . . . . 152
Setting (heating) . . . . . . . . . . . . . . . . . . 148
TIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Tire and Loading Information . . . . . . . . . 186
Placard . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Tire and loading terminology . . . . . . . . . . 204
Tire care and maintenance . . . . . . . . . . . . 183
Tire Identification Number see TIN
Tire inflation pressure, checking . . 191, 192
Tire inflation pressure, recommended . . 189
Tire repair kit . . . . . . . . . . . . . . . . . . 234, 265Tires
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 184
Direction of rotation . . . . . . . . . . . . . . 184
Flat tire . . . . . . . . . . . . . . . . . . . . . . . . . 265
Important guidelines . . . . . . . . . . . . . . 182
Life of tire . . . . . . . . . . . . . . . . . . . . . . 183
Pressure Monitoring System (TPMS) . . 192
Problems under
/overinflation . . . . . . 195
Rims and tires . . . . . . . . . . . . . . . . . . . . 298
Rotating tires . . . . . . . . . . . . . . . . . . . . 207
Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
Snow chains* . . . . . . . . . . . . . . . . . . . . . 209
Speed rating . . . . . . . . . . . . . . . . . . . . . 218
Storing . . . . . . . . . . . . . . . . . . . . . . . . . 184
Temperature . . . . . . . . . . . . . . . . . 190, 203
TIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Traction . . . . . . . . . . . . . . . . . . . . . . . . 203
Tread depth . . . . . . . . . . . . . . . . . 183, 208
Treadwear indicators (TWI) . . . . . . . . . 184
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Top tether* . . . . . . . . . . . . . . . . . . . . . . . . 69
Tow
away alarm* . . . . . . . . . . . . . . . . . . . . 78
Towing (Vehicle) . . . . . . . . . . . . . . . . . . . 278
Traction . . . . . . . . . . . . . . . . . . . . . . . 73, 203
Transmission position indicator . . . . . . 137
Transmitting power values see Engine elec

tronicsTransporting the vehicle . . . . . . . . . . . . . . 78
Tread . . . . . . . . . . . . . . . . . . . . 183, 206, 208
Tread depth . . . . . . . . . . . . . . . . . . . . . . . 208
Treadwear indicators (TWI) . . . . . . . . . . . 184
Trip odometer . . . . . . . . . . . . . . . . . . . . . 139
Turn signal indicators . . . . . . . . . . . 104, 255
Indicator lamp . . . . . . . . . . . . . . . . . . . . 247
Turn signal lamps, side . . . . . . . . . . . . . . 255
Replacing . . . . . . . . . . . . . . . . . . . . . . . 258
TWI see Treadwear indicators
>> UUniform Tire Quality Grading Standards . 202
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . 83
From inside . . . . . . . . . . . . . . . . . . . . . . . 84
Vehicle manually . . . . . . . . . . . . . . . . . . 250
Unlocking/locking manually . . . . . . . . . . 250
Useful features . . . . . . . . . . . . . . . . . . . . 164

Operator’s Manual
20
>> Introduction.
Change of address or ownershipI f y o u c h a n g e y o u r a d d r e s s , b e s u r e t o s e n d i n
the "Change of Address Notice" found in the
Service and Warranty Information Booklet, or
simply call the smart Customer Assistance
Center (in the USA) at 1
800
FOR
SMART, or
Customer Service (in Canada) at
1
800
387
0100. Maintaining your current
address information with smart will enable us
to contact you should important new informa

tion about the vehicle, such as recalls, become
available.
If you sell your smart, please leave all litera

ture with the vehicle to make it available to the
next operator.
If you bought this vehicle used, be sure to
send in the "Notice of Purchase of Used Car"
found in the Warranty Information Booklet, or
call the smart Customer Assistance Center (in
the USA) at 1
800
FOR
SMART, or Customer
Service (in Canada) at 1
800
387
0100.
Operating your vehicle outside
the USA or CanadaIf you plan to operate your vehicle in foreign
countries, please be aware that:
• service facilities or replacement parts may
not be readily available,
• unleaded gasoline for vehicles with
catalytic converters may not be available;
the use of leaded fuels will damage the
catalysts,
• gasoline may have a considerably lower
octane rating, and improper fuel can cause
engine damage.

Operating safety
22
>> Introduction.G
Warning!
Work improperly carried out on elec

tronic components and associated
software could cause them to cease func

tioning. Because the vehicle’s electronic
components are interconnected, any
modifications made may produce an
undesired effect on other systems.
Electronic malfunctions could seriously
impair the operating safety of your
vehicle.
See an authorized smart center for
repairs or modifications to electronic
components.
Improper work or modifications on other
vehicle systems could also have a nega

tive impact on the operating safety of the
vehicle.
G
Warning!
Some safety systems only function while
the engine is running. You should there

fore never turn off the engine while
driving.G
Warning!
Heavy blows against the vehicle under

body or tires/wheels, for example when
running over an obstacle, road debris or
a pothole, may cause serious damage and
impair the operating safety of your
vehicle.
If you feel a sudden significant vibration
or ride disturbance, or you suspect that
damage to your vehicle has occurred, you
should turn on your hazard warning
flashers, carefully slow down, and drive
with caution to an area which is a safe
distance from the road.
Inspect the vehicle underbody and tires/
wheels for possible damage. If the vehicle
appears unsafe, have it towed to the
nearest authorized smart center or other
qualified maintenance or repair facility
for further inspection or repairs.
