2008 SATURN OUTLOOK relay

Relays Usage
LT/PWR/SEAT Driver Side Power Seat Relay
RT/PWR/SEAT Passenger Side Power Seat Relay
PWR/WNDW Power Windows Relay
PWR/COLUMN Power Steering Column Relay
L/GATE Liftgate Relay
LCK Power Lock Relay
REAR/WSW Rear Window Washer Relay
Relay Side
5-114
ProCarManuals.com

UNLCK Power Unlock Relay
DRL2 Daytime Running Lamps 2 Relay
LT/UNLCK Driver Side Unlock Relay
DRL Daytime Running Lamps Relay
SPARE Spare
FRT/WSW Front Windshield Washer RelayUnderhood Fuse Block
The underhood fuse block is located in the engine
compartment, on the passenger side of the vehicle.
Lift the cover for access to the fuse/relay block.
Notice:Spilling liquid on any electrical components
on your vehicle may damage it. Always keep the
covers on any electrical component.
5-115
ProCarManuals.com

Relays Usage
A/C CMPRSR
CLTCHAir Conditioning Compressor Clutch
CRNK Switched Power
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
FAN 3 Cooling Fan 3
FOG LAMP Fog Lamps
FUEL PUMP Fuel Pump
HI BEAM High-Beam Headlamps
HID/LO BEAMHigh Intensity Discharge (HID)
Low-Beam Headlamps
HORN HornRelays Usage
IGN Ignition Main
LT TRLR
STOP/TRNTrailer Left Stoplamp and Turn
Signal Lamp
PRK LAMP Park Lamp
PWR/TRN Powertrain
RR DEFOG Rear Window Defogger
RT TRLR
STOP/TRNTrailer Right Stoplamp and Turn
Signal Lamp
SPARE Spare
TRLR BCK/UP Trailer Back-up Lamps
WPR Windshield Wiper
WPR HI Windshield Wiper High Speed
