2008 PORSCHE CAYENNE technical data

The Cayenne models
The Cayenne models 6
Model range 20
Drive 38
Chassis 68
Off road 82
Safety 90
Environment 104
Comfort 112
Transport 138
Personalisation 148
Factory collection 174
Service 178
Summary 180
Technical data 182
Index 190
· 6 ·

· 183 · · 182 ·
Technical data
Technical data
Cayenne Cayenne S
Engine
Cylinders68
Displacement3,598 cm34,806 cm3
Max. power (DIN)213 kW (290 hp) 283 kW (385 hp)
at6,200 rpm 6,200 rpm
Max. torque385 Nm 500 Nm
at3,000 rpm 3,500 rpm
Compression ratio12.3 :1 12.5 :1
Transmission
LayoutAll-wheel drive All-wheel drive
6-speed manual gearboxStandard Standard
6-speed Tiptronic SOptional Optional
Low-range ratio2.7:1 2.7:1
Cayenne GTS Cayenne Turbo
88
4,806 cm34,806 cm3
298 kW (405 hp) 368 kW (500 hp)
6,500 rpm 6,000 rpm
500 Nm 700 Nm
3,500 rpm 2,250 – 4,500 rpm
12.5 :1 10.5 :1
All-wheel drive All-wheel drive
Standard –
Optional Standard
2.7:1 2.7:1

· 185 · · 184 ·
Technical data
* Weight is calculated in accordance with the relevant EC Directives and is valid for standard specification vehicles only.
Some optional equipment may increase this weight. The figure given includes 68 kg for the driver and 7 kg for luggage.
Cayenne Cayenne S
Chassis
Front axle
Extra-large format double Extra-large format double
wishbone suspension, wishbone suspension,
fully independent fully independent
Rear axleMulti-link suspension, Multi-link suspension,
fully independent fully independent
SteeringPower-assisted (hydraulic) Power-assisted (hydraulic)
Brakes6-piston monobloc aluminium 6-piston monobloc aluminium
fixed calipers at front, fixed calipers at front,
4-piston monobloc aluminium 4-piston monobloc aluminium
brakes at rear, brakes at rear,
ABS ABS
Wheels7.5J x 17 8J x 18
Ty r e s235/65 R 17 255/55 R 18
Unladen weightManual/ Tiptronic SManual/ Tiptronic S
DIN2,160 kg/2,170 kg 2,225 kg/2,245 kg
EC*2,235 kg/2,245 kg 2,300 kg/2,320 kg
Permissible gross weight2,945 kg/2,945 kg 3,080 kg/3,080 kg
Maximum payload785 kg/775 kg 855 kg/835 kg
Cayenne GTS Cayenne Turbo
Extra-large format double Extra-large format double
wishbone suspension, wishbone suspension,
fully independent fully independent
Multi-link suspension, Multi-link suspension,
fully independent fully independent
Power-assisted (hydraulic) Power-assisted (hydraulic)
6-piston monobloc aluminium 6-piston monobloc aluminium
fixed calipers at front, fixed calipers at front,
4-piston monobloc aluminium 4-piston monobloc aluminium
brakes at rear, brakes at rear,
ABS ABS
10J x 21 8J x 18
295/35 R 21 275/45 R 19
Manual/ Tiptronic S Tiptronic S
2,225 kg/2,245 kg 2,355 kg
2,300 kg/2,320 kg 2,430 kg
3,080 kg/3,080 kg 3,080 kg
855 kg/835 kg 725 kg

· 186 ·· 187 ·
Technical data
Cayenne Cayenne S
PerformanceManual/ Tiptronic S Manual/ Tiptronic S
Top speed227 km / h (141 mph)/ 252 km / h (157 mph)/
227 km / h (141 mph) 250 km / h (155 mph)
0 –100 km / h (0 – 62 mph)8.1 secs/8.5 secs 6.6 secs/6.8 secs
Flexibility (80 –120 km / h)9.9 secs/10.2 secs 8.6 secs/8.8 secs
(50 –75 mph) in fifth gear
Fuel consumption/emissions*/**Manual/ Tiptronic S Manual/ Tiptronic S
Urban18.5 (15.3)/ 22.1 (12.8)/
in l / 100 km (mpg)18.3 (15.4) 20.2 (14.0)
Extra urban9.8 (28.8)/ 10.8 (26.2)/
in l / 100 km (mpg)9.9 (28.5) 10.1 (28.0)
Combined 12.9 (21.9)/ 14.9 (19.0)/
in l / 100 km (mpg)12.9 (21.9) 13.7 (20.6)
CO2emissions in g /km310/310 358/329
Dimensions
Length4,798 mm 4,798 mm
Width (incl. mirrors)1,928 mm (2,200 mm) 1,928 mm (2,200 mm)
Height1,699 mm 1,699 mm
Wheelbase2,855 mm 2,855 mm
Luggage compartment540 litres 540 litres
volume (VDA), with
rear seats folded (VDA)1,770 litres 1,770 litres
Tank capacity/reserve100 litres/12 litres 100 litres/12 litres
Cayenne GTS Cayenne Turbo
Manual/ Tiptronic S Tiptronic S
253 km / h (157 mph)/ 275 km / h (171 mph)
251 km / h (156 mph)
6.1 secs/6.5 secs 5.1 secs
6.6 secs/7.8 secs 5.5 secs
Manual/ Tiptronic S Tiptronic S
22.6 (12.5)/ 22.5 (12.6)
20.6 (13.7)
10.9 (25.9)/ 10.5 (26.9)
10.2 (27.7)
15.1 (18.7)/ 14.9 (19.0)
13.9 (20.3)
361/332 358
4,795 mm 4,795 mm
1,957 mm (2,200 mm) 1,928 mm (2,200 mm)
1,675 mm 1,696 mm
2,855 mm 2,855 mm
540 litres 540 litres
1,749 litres 1,770 litres
100 litres/12 litres 100 litres/12 litres
* All Porsche models are compatible with an ethanol fuel content of up to 10 %.
** Emissions were recorded in accordance with Directive 80/1268/ EC on standard vehicles as valid at the time of publication.
The respective figures were not recorded on individual vehicles and do not constitute part of the offer.
This data is provided solely
for the purposes of comparison between the respective models. For more information, pleasecontact your Porsche Centre.

· 189 · · 188 ·
Technical data
* At DIN unladen weight, ground clearance at axle centre, Cayenne Turbo with air suspension.Some of the vehicles featured in this catalogue are fitted with optional equipment available at extra cost. While everyeffort is made to ensure that all information is correct when going to print, we are constantly seeking to improve our products and therefore reserve the right to alter specifications without notice. Errors and omissions excepted.
Cayenne Cayenne S
Off-road capability
Wading depth
500 mm 500 mm
(steel-sprung suspension) (steel-sprung suspension)
Approach angle*28.6° 28.6°
(steel-sprung suspension) (steel-sprung suspension)
Departure angle*22.8° 22.8°
(steel-sprung suspension) (steel-sprung suspension)
Ramp breakover angle*20.4° 20.4°
(steel-sprung suspension) (steel-sprung suspension)
Lockable differentials (standard)Centre, electronically variable Centre, electronically variable
Max. ground clearance*
High Level II
High Level I
Normal Level 218 mm 218 mm
Low Level I
Low Level II
Loading Level
Cayenne GTS Cayenne Turbo
476 mm 555 mm
(steel-sprung suspension) (air suspension at High Level II)
25.6° 28.5° Normal Level
(steel-sprung suspension) (air suspension)
31.8° High Level II
21.1° 22.3° Normal Level
(steel-sprung suspension) (air suspension)
25.4° High Level II
18.2° 20.0° Normal Level
(steel-sprung suspension) (air suspension)
24.7° High Level II
Centre, electronically variable Centre, electronically variable
271 mm
241 mm
194 mm 215 mm
191 m m
181 m m
161 m m

Index
N
Navigation 132
O
Off-road capability 82
Off-road Technology
package 88
On-board computer 132
P
Panoramic roof system 128
ParkAssist 124
Payload 184
Performance 42, 182
Personalisation 148
Porsche Active Suspension
Management (PASM) 76
Porsche Ceramic
Composite Brake (PCCB) 96
Porsche Communication
Management (PCM) 132
Porsche Drive-off
Assistant
62, 85
Porsche Dynamic
Chassis Control (PDCC) 80
Porsche Entry & Drive 126
Porsche Hill Control (PHC)86
T
Technical data 182
Tiptronic S 64
Touchscreen 132
Towbar systems 147, 158
Transfer gearbox 66
Transmission 64, 66
Turbochargers 55
TV tuner 134
Tyre Pressure
Monitoring (TPM) 75
U
Universal audio interface 135
USB port 135
V
Variable valve timing 52
VarioCam Plus 53
Vehicle tracking system 126
Voice control 134
W
Water-repellent side windows12 3
Wheel articulation 81, 86
Wheels 75, 160, 161
Wiper system 124
A
Acoustics 108
Air conditioning 122
Air suspension 78, 189
Airbags 102
Alloy engine 48
All-wheel drive 66
Anti-slip regulation 66
Anti-theft protection 126
Audio systems 130, 136
Automatic brake differential 66
Automatic tailgate 144
Axle concept 72
B
Bluetooth®13 4
Bodyshell 100
BOSE
®
Surround Sound System 136
Brakes 94
C
CD autochanger 131
CD radio 130
Centre differential 66
Ceramic brakes 96
Chassis 68 Child seats 119
Colours 150
Comfort lighting package 127
Cooling system 49
Cruise control 126
D
Direct fuel injection (DFI) 50
DVD autochanger 131
E
Electronic engine management57
Electronic logbook 134
Emissions 106
Engine braking support 86
Engines V6/V8/ Turbo 42 – 45
Exhaust system 60
F
Factory collection 174
G
GPS navigation system 132
GSM telephone 134
H
Hands-free telephony 134 Headlights 92
Heat-insulating glass 123
HomeLink
®
(garage-door opener) 164
I
Ignition system 59
Intake manifold 54
Interior 114, 151
Interior lighting 120
iPod
®13 5
L
Lighting 92
Loading options 142
Lubrication 49
Luggage compartment 140
M
Manual gearbox 62
Materials 110
Mobile phone 134
Mobile phone preparation 130
Monochrome black
exterior package 152
MP3 135
Multifunction
steering wheel 114, 164
· 191 · · 190 ·
Index
Porsche Hill Holder 65, 85
Porsche Stability
Management (PSM) 98
Porsche Traction
Management (PTM) 66
Powerkit Cayenne Turbo 46
Privacy glass 123
R
Recycling 110
Reversing camera 125
Roof transport systems 146
S
Safety 90
Seats 116, 118
Servicing 61, 110
Servotronic 74
Slide/tilt sunroof 127
Sport button 51
SportDesign package 152
Steering 74
Storage compartments 120
