2008 Peugeot Bipper Owner's Manual

Good practice
To change gear easily, always press the
clutch pedal fully.
To prevent the mat from becoming caught
under the pedal:
- ensure that the mat is positioned correctly,
- never fit one mat on top of another.
Avoid leaving your hand on the gear knob as
the force exerted, even if slight, may wear
the internal components of the gearbox over
time.
STEERING WHEEL ADJUSTMENT MANUAL GEARBOX
Reverse gear
Never engage reverse gear before the
vehicle is completely stationary.
The lever should be moved slowly to reduce
the noise on engaging reverse gear.
If your vehicle is fitted with parking
assistance, the system comes into
operation when reverse gear is engaged and
an audible signal is heard. Refer to the "Rear parking assistance"
section of chapter 3.
When the vehicle is stationary, unlock the
steering wheel by pushing the lever down.
Adjust the depth and height of the steering
wheel, then lock by pulling the lever up fully.
42
Gearbox and steering wheel

44
Dimensions

45
2
Dimensions
TECHNICAL DATA
DIMENSIONS
The light van "L1" is the standard model, the "L2 - Worksite Pack" version is a model sold according to country:

Light van (in mm)
L1 L2 (Worksite Pack)
L Overall length 3 864 3 881
H Overall height 1 721 1 742
Height with roof bars 1 782 1 803
A Wheelbase 2 513
B Front overhang 760 777
C Rear overhang 591
D Overall width 2 019
Width (with mirrors folded) 1 816
E Width of front track 1 469 1 464
F Width of rear track 1 465
G Height of load sill 527 544
I Length of interior fl oor 1 523
J Maximum interior load height 1 205
K Maximum interior width (10 cm from the fl oor) 1 473
M Maximum interior width (at the sides) -
N Interior width between wheel arches 1 046

Volume (m
3
) 2.5

46
Dimensions

47
2
Dimensions
TECHNICAL DATA

Combi (in mm)
Standard All-terrain
L Overall length 3 959 3 970
H Overall height 1 721 1 742
Height with roof bars 1 782 1 803
A Wheelbase 2 513
B Front overhang 855 866
C Rear overhang 591
D Overall width 2 019
Width (with mirrors folded) 1 816
E Width of front track 1 464
F Width of rear track 1 465
G Height of load sill 527 544
I Length of interior fl oor (rear bench seat in place) 743
Length of interior fl oor (rear bench seat fully folded) 1 130
J Maximum interior load height (under rear shelf) 592
K Maximum interior width (10 cm from the fl oor) 1 473
M Maximum interior width (at the sides) -
N Interior width between wheel arches 1 046

48
Engines

DIESEL
ENGINE

1.4 HDi 70 bhp

Gearbox Manual Piloted manual
Gears 5
EU standard maximum power (kW) 50
Cubic capacity (cm 3
) 1 399
Bore x stroke (mm) 73.7 x 82
Max power engine speed (rpm) 4 000
EU standard max torque (Nm) 160
Max torque engine speed (rpm) 1 750
Fuel Diesel
Catalytic converter Yes
Engine oil capacity (in litres) 3.8

49
2
Engines
TECHNICAL DATA

PETROL ENGINE

1.4 l 75 bhp

Gearbox Manual
Gears 5
EU standard maximum power (kW) 54
Cubic capacity (cm 3
) 1 360
Bore x stroke (mm) 75 x 77
Max power engine speed (rpm) 5 200
EU standard max torque (Nm) 118
Max torque engine speed (rpm) 2 600
Fuel Unleaded petrol
Engine oil capacity (in litres) 3.0

50
Engines
CONSUMPTION
These consumption values were established in accordance with directive 80/1268/EC. They may vary depending on the style of driving, traffi c
conditions, weather conditions, the load in the vehicle, t he maintenance of the vehicle and the use of the accessories.

Light van
According to directive 80/1268/EC
Engines Gearboxes Model codes Urban driving
mpg (litres/100 km) Inter-urban driving
mpg (litres/100 km)
Mixed driving
mpg (litres/100 km) Emission of CO 2 by
mass (g/km)
1.4 HDi Manual AA8HSC 49.6 (5.7) 74.3 (3.8) 62.8 (4.5)
119
Piloted
manual AA8HSC/P - - - -
1.4 l Manual AAKFVC 32.1 (8.8) 47.9 (5.9) 40. 9 (6.9) 164

Combi
According to directive 80/1268/EC
Engines Gearboxes Model codes Urban driving
mpg (litres/100 km) Inter-urban driving
mpg (litres/100 km) Mixed driving
mpg (litres/100 km) Emission of CO
2
by mass (g/km)
1.4 HDi Manual AJ8HSC
5.93.94.6123
Piloted
manual AJ8HSC/P - - - -
1.4 l Manual AJ8KFVC
8.85.97.0165
Consumption fi gures correct at time of printing.
