Page 5 of 123
FAMILIARISATION
8 -
SITTING COMFORTABLY
Front seat adjustment
1. F o r w a r d s - b a c k w a r d s a d j u s t m e n t .
2. Head restraint height and angle
adjustment.
3. Access to rear seats
(3-door). 4.
Height adjustment.
5. Seat back angle adjustment.
6. Heated seats control
(according to country). N e v e r d r i v e w i t h t h e h e a d
restraints removed.
: 46
Page 7 of 123
FAMILIARISATION
10 -
SITTING COMFORTABLY
Front seat belts adjustment
2. Height adjustment.
: 86 Steering wheel adjustment
1.
Unlocking.
2. Height adjustment.
3. Locking.
: 70
1. Fastening.
Page 46 of 123
47
COMFORT
-
FRONT SEATS It is impossible to access the
rear seats if the front seat is in
the reclining position.
B. Pull one of the two handles and
push forwards to fold the seat
back. The seat does not move
forward.
On repositioning, the seat back
returns to its initial angle.
Never drive with the head
r e s t r a i n t s r e m o v e d ; t h e y
must be in place and cor-
rectly adjusted. Rear head restraints, "comma"
type
These have a high position for when
they are in use and a low position for
when they are stored. They are re-
movable.
To lower the head restraints, press
the lug.
To remove them, pull upwards as far
as the stop, then press the release
control.
1 - F o r w a r d s - b a c k w a r d s
adjustment
Lift the control and slide the seat to-
wards the front or the rear.
2 - Head restraint height and angle adjustment
To raise the restraint, pull it up-
wards.
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e
upper edge of the head restraint is
l e v e l w i t h t h e t o p o f t h e h e a d .
The head restraint has a frame with
notches, which prevent the head res-
traint dropping down (this is a safety
device in the event of an impact).
To lower the head restraint, it is ne
cessary to push simultaneously:
- the button located on the left guide at the base of the head
restraint,
- the head restraint downwards.
To remove the head restraint, press
the lug.
The angle of the head restraint can
also be adjusted. 3 - Access to rear seats
(3 door), A or B according to
version
A. Pull one of the two handles
and push forwards to fold the
seat back and move the seat
forwards.
On repositioning, the seat returns to its initial position.
No person nor object must prevent the seat from returning
t o i t s i n i t i a l p o s i t i o n ; r e t u r n i n g t o
this position is necessary for it to
be locked. 4 - Seat height adjustment
Pull the handle upwards.
Remove your weight from the seat to
raise, or press on the seat to lower.
5 - Seat back angle adjustment
Push the handle towards the rear.
6 -
H e a t e d s e a t s s w i t c h
Press the switch. The temperature is
controlled automatically.
Press the switch again to stop opera-
tion.
Page 47 of 123
47
COMFORT
-
FRONT SEATS It is impossible to access the
rear seats if the front seat is in
the reclining position.
B. Pull one of the two handles and
push forwards to fold the seat
back. The seat does not move
forward.
On repositioning, the seat back
returns to its initial angle.
Never drive with the head
r e s t r a i n t s r e m o v e d ; t h e y
must be in place and cor-
rectly adjusted. Rear head restraints, "comma"
type
These have a high position for when
they are in use and a low position for
when they are stored. They are re-
movable.
To lower the head restraints, press
the lug.
To remove them, pull upwards as far
as the stop, then press the release
control.
1 - F o r w a r d s - b a c k w a r d s
adjustment
Lift the control and slide the seat to-
wards the front or the rear.
2 - Head restraint height and angle adjustment
To raise the restraint, pull it up-
wards.
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e
upper edge of the head restraint is
l e v e l w i t h t h e t o p o f t h e h e a d .
The head restraint has a frame with
notches, which prevent the head res-
traint dropping down (this is a safety
device in the event of an impact).
To lower the head restraint, it is ne
cessary to push simultaneously:
- the button located on the left guide at the base of the head
restraint,
- the head restraint downwards.
To remove the head restraint, press
the lug.
The angle of the head restraint can
also be adjusted. 3 - Access to rear seats
(3 door), A or B according to
version
A. Pull one of the two handles
and push forwards to fold the
seat back and move the seat
forwards.
On repositioning, the seat returns to its initial position.
No person nor object must prevent the seat from returning
t o i t s i n i t i a l p o s i t i o n ; r e t u r n i n g t o
this position is necessary for it to
be locked. 4 - Seat height adjustment
Pull the handle upwards.
Remove your weight from the seat to
raise, or press on the seat to lower.
5 - Seat back angle adjustment
Push the handle towards the rear.
6 -
H e a t e d s e a t s s w i t c h
Press the switch. The temperature is
controlled automatically.
Press the switch again to stop opera-
tion.
Page 74 of 123
LAYOUT
70 -
HEADLAMP ADJUSTMENT
Depending on the load in your vehi-
cle, it is recommended that the head-
lamp beam is adjusted.
0. 1 or 2 people in the front
seats.
-. 3 people.
1. 5 people.
2. 5 people + maximum
authorised load.
3. Driver + maximum
authorised load.
Initial setting is position 0.
STEERING WHEEL HEIGHT
ADJUSTMENT
When stationary, lower the handle to
unlock the steering wheel.
Adjust to the desired height and
lift the handle to lock the steering
wheel.
HORN
Press one of the spokes of
the steering wheel.
