Page 2 of 103
5FAMILIARISATION-
1. Driver's air bag
Horn
2. Lights and direction indicators
stalk
3. Passenger air bag disarming
switch
4. Rear electric windows disarming
switch
5. Lighting rheostat for instrument
panel
6. Windscreen wiper/windscreen
wash stalk
7. Audio equipment remote control
8. Hazard warning lights switch/
central locking button
9. Multifunction display
10. Windscreen demisting vents
11. Side window demisting vents
12. Adjustable side vent
13. Passenger air bag
14. Adjustable centre vents
15. Glove box
16. Audio equipment
17. Control for heating, ventilation,
air conditioning and heated rear
screen and mirrors
18. Front ashtray
19. Gear lever
20. Lighter
21. Electric mirror controls
22. Rear electric window controls
23. Front electric window controls
24. Handbrake
25. Bonnet release
26. Steering lock
27. Fuse box
28. Storage compartment
29. Steering wheel height
adjustment control
30. Headlamp height adjustment
Page 6 of 103
9FAMILIARISATION-
ELECTRIC WINDOWS
3. Rear left electric window
ELECTRIC MIRRORS
Turn knob 5 to the right or to the left
to select the corresponding mirror.
Move knob 5 in all four directions to
adjust.
64
1. Driver's electric window
Manual operation : press or pull the
switch gently. The window stops as
soon as the switch is released.
2. Passenger's electric window 4. Rear right electric window
63
Automatic operation : press or pull
t h e s w i t c h fi r m l y . O n e t o u c h c o m -
pletely opens or closes the window.
Automatic opening and closing only
operate when the engine is running.
Page 11 of 103
FAMILIARISATION14 -
HEATING/AIR CONDITIONING
N° Symbol Function 1
Setting the air
distribution.
2
Air intake control.
3
Temperature
adjustment.
4
Demisting the rear
screen and mirrors.
5
A i r fl o w a d j u s t m e n t .
6
Air conditioning
control.
36
40
Page 12 of 103
15FAMILIARISATION-
42
AUTOMATIC AIR CONDITIONING
N° Symbol Function
1
A i r fl o w a d j u s t m e n t .
2
Setting the air
distribution.
3
Air intake control.
4
Air conditioning
control.
5
Demisting the rear
screen and mirrors.
6
Switching off.
7
Temperature
adjustment.
8
Automatic comfort
programme.
9
Automatic visibility
programme.
Page 37 of 103
COMFORT38 -
DE-ICING AND DEMISTING
When the engine is running,
p r e s s i n g t h i s b u t t o n d e - i c e s
the rear screen and exterior
mirrors.
It switches off automati-
cally, after approximately twelve
minutes * , to prevent an excessive
consumption of current. Pressing the
b u t t o n a g a i n r e s t a r t s o p e r a t i o n f o r
twelve minutes.
I t i s p o s s i b l e t o s t o p t h e o p e r a t i o n o f
t h e d e - i c i n g b e f o r e i t i s s w i t c h e d o f f
a u t o m a t i c a l l y b y p r e s s i n g t h e b u t t o n
again. Manual demisting *
T o q u i c k l y d e m i s t t h e w i n d s c r e e n a n d
side windows:
- switch on the air conditioning,
- place the temperature and air
fl o w c o n t r o l s i n t h e m a x i m u m
position,
- close the central vents,
- place the exterior air intake con- trol on the left, in the "Exterior
Air" position. Automatic demisting,
visibility programme *
In some cases, the AUTO programme
m a y n o t b e s u f fi c i e n t t o d e m i s t t h e
windscreen and side windows (hu-
midity, several passengers, ice...).
* According to version or country. Select the
"visibility" de-
m i s t i n g p r o g r a m m e b y p r e s s -
i n g t h i s b u t t o n t o c l e a r t h e
w i n d o w s q u i c k l y .
To exit from this programme
and return to the AUTO programme,
press the AUTO b u t t o n .
Switch off the de-icing as
soon as you consider this
necessary as low current
consumption reduces fuel
consumption.
De-icing the rear screen and
mirrors
Page 66 of 103
64 - M a n u a l i n t e r i o r m i r r o r
The interior mirror has two positions:
- day (normal),
- night (anti-dazzle).
To change from one to the other,
push or pull the lever on the lower
edge of the mirror. M a n u a l e x t e r i o r m i r r o r s
Move the lever in all four directions
to adjust.
When the vehicle is parked, the ex-
terior mirrors can be folded back
manually.
E L E C T R I C E X T E R I O R M I R R O R S
Turn knob
1 to the right or to the left
to select the corresponding mirror.
Move knob 1 in all four directions to
adjust.
The exterior mirror on the
driver’s side is convex
in order to eliminate the
"blind spot".
Furthermore, objects observed in
the driver’s and passenger’s mir-
rors are in reality closer than they
appear.
This must be taken into account to
judge correctly the distance of ve-
hicles approaching from behind.
