Page 22 of 123
INSTRUMENTS and CONTROLS
24 -
R e s e t t i n g t h e s e r v i c e i n d i c a t o r
Your PEUGEOT dealer carries out
this operation after each service.
The reset procedure is as follows:
- Switch off the ignition.
- Press and hold button 1.
- Switch on the ignition.
The display begins a 10 second
countdown.
- Keep button 1 pressed for
10 seconds.
The display shows [=0] and the span-
ner disappears. E n g i n e o i l l e v e l i n d i c a t o r
When the ignition is switched on,
the engine oil level is indicated for
approximately 10 seconds, after the
service information.
O i l l e v e l g a u g e f a u l t
Flashing of the six segments indi-
cates a malfunction of the oil level
gauge.
There is a risk of damage to the en-
gine.
Consult a PEUGEOT dealer.
S u r p l u s o f o i l
Flashing of the six squares and dis-
playing of "max" indicate a surplus of
oil which could damage the engine.
I f t h e s u r p l u s o f o i l i s c o n i r m e d b y
a check using the dipstick, contact a
PEUGEOT dealer without delay.
L a c k o f o i l
Flashing of the six segments and dis-
playing of "min" indicate a lack of oil
which could damage the engine.
I f t h e l a c k o f o i l i s c o n i r m e d b y a
check using the dipstick, it is essen-
tial that the level is topped up. T h e l e v e l r e a d o n t h e g a u g e w i l l
o n l y b e c o r r e c t i f t h e v e h i c l e
i s o n l e v e l g r o u n d a n d t h e e n
-
g i n e h a s b e e n o f f f o r m o r e t h a n
1 5 m i n u t e s .
Page 23 of 123
25
INSTRUMENTS and CONTROLS
-
TOTAL DISTANCE
RECORDER
Pressing button 1 alternates bet-
ween:
- the total distance display,
- the trip distance display,
- the speed limiter or cruise control display when one of
these systems is selected with
the engine running.
To reset the trip recorder to zero,
when it is displayed press button
1 until zeros appear.
LIGHTING RHEOSTAT
With the lights on, press the button
to vary the intensity of the lighting of
the instruments and controls. When
the lighting reaches the minimum (or
maximum) setting, release the but-
ton then press it again to increase (or
reduce) the brightness.
As soon as the lighting is of the re-
quired brightness, release the button.
HAZARD WARNING
LIGHTS
Press the button, the direction indica-
t o r s l a s h .
They can operate with the ignition
off.
A u t o m a t i c l i g h t i n g o f h a z a r d
w a r n i n g l i g h t s
When braking in an emergency,
depending on the deceleration, the
hazard warning lights come on auto-
matically. They switch off automati-
c a l l y t h e i r s t t i m e y o u a c c e l e r a t e .
It is also possible to switch them off
by pressing the button.
Page 35 of 123
AUDIO EQUIPMENT
36 -
RADIO RECEPTION
(AERIAL ADJUSTMENT)
Notes on radio reception. Your radio
will be subject to phenomena which
do not affect domestic radio sets.
Both MW/LW and FM reception are
subject to various forms of interfe-
r e n c e , w h i c h a r e n o r e l e c t i o n o n t h e
quality of your equipment but are due
to the nature of the signals and the
way in which they are transmitted.
On MW/LW, interference may be no-
ticed when passing underneath high
voltage power lines, under bridges or
in tunnels. On FM, interference may be the
result of increasing distance from the
t r a n s m i t t e r , d e l e c t i o n o f t h e s i g n a l
by obstacles (mountains, hills, buil-
dings, etc.), or of being in an area not
covered by a transmitter.
Saloon: recommended position for
the front aerial for best reception.
N o p a r t i c u l a r p o s i t i o n f o r t h e i x e d
rear aerial (preset aerial).
