2008 NISSAN MAXIMA lock

TABLE OF CONTENTS
Intelligent Key System...............................2
Windshield Wiper/Washer Switch .......................2
Headlight and Turn Signal Control .......................3
Steering Wheel Switches for Audio Control/Bluetooth
(if so equipped) ..................................4
Cruise Control ...................................4
Auto Climate Control ...............................5
FM/AM/XM Radio with CD Changer (if so equipped) ...........7
Clock Set/Adjustment ...............................9
Control Panel Display with Navigation System (if so equipped) .......9
Automatic Driver Positioner (if so equipped) .................10
Xtronic Continuously Variable Transmission (CVT) .............11
Vehicle Dynamic Control (VDC) Off Switch .................12
Front-Passenger Air Bag Status Light ....................12
Tire Pressure Monitoring System (TPMS) ..................12
Seat Belt Warning Light and Chime ......................13
Rear Sonar System Off Switch (if so equipped) ...............13
Child Safety Rear Door Lock ..........................13
Fuel-Filler Cap ..................................13
Fuel-Filler Door and Trunk Lid Release Switches ..............14
Trunk Lid Cancel Switch ............................14
Tilt and Telescopic Steering Column (if so equipped) ...........14
Outside Mirror Control Switch .........................14
Moonroof Controls (if so equipped) ......................15
Front Seat Adjustments .............................15
Folding Down the Rear Seats .........................16
Homelink Universal Transceiver (if so equipped) ..............17
Bluetooth Hands-Free Phone System (if so equipped) ..........18
Navigation System (if so equipped) ......................20
This easy-to-use Quick Reference Guide is intended to help you more fully
appreciate some of the unique features and functions of your new vehicle.
However, it is not intended to replace your Owner’s Manual. The Owner’s
Manual contains more detailed information to help you better understand the
important safety warnings, features, operation, and maintenance of your
vehicle.

INTELLIGENT KEY SYSTEM
TheIntelligent KeySystem allowsyoutolock orunlock your
vehicle, open your trunk and start the engine.
NOTE: It is important to make sure the Intelligent Key is with you
(that is, in your pocket or purse) .
 The operating range of the door and trunk lock/unlock func-
tion is approximately 31 in (0.8 m) .
 Locking thevehicle -Push anydoor handle Request
Switch
once.
 Unlocking the vehicle - Push any door handle Request
Switch
once. Thecorresponding doorwillun-
lock. Push the door handle Request Switch
again
within 1 minute; all other doors will unlock.
STARTING THE ENGINE
 Push the ignition knob in.
 Confirm the Intelligent Key warning light is illuminated green.
 Turn the ignition knob to start the engine.
TURNING THE ENGINE OFF
Shift the transmission into P (Park) .
 Turn the ignition knob to the LOCK position.
 An audible warning chime will sound when exiting the vehicle if the ignition knob is not
completely turned to the OFF position.
OPENING THE TRUNK
 To open the trunk, using the request switch, your Intelli-
gent Key must be with you.
 Push therequest/release switch
underthetrunk
handle.
 Pull up and out on the handle to open the trunk.
WINDSHIELD WIPER/WASHER SWITCH
The ignition switchmustbeinthe ON position to
activate the windshield wipers.
 Move thelever tothe following positions tooperate
the windshield wipers:
Intermittent (INT)–Front wipers operate inter-
mittently and can be further adjusted by twisting
the time control ring
.
Low Speed (LO)– Continuous low-speed operation of front wipers.
2

CLOCK SET/ADJUSTMENT
NON-NAVIGATION SYSTEM ONLY (if so equipped)
Press and hold the CLOCK DISPbutton for more than approximately 1.5 seconds.
 Hour Adjust will appear on the screen and the hours will start flashing.
 Press the SEEKorTUNE button to adjust the hour.
 Press the CLOCK DISP button again. Minute Adjust will appear on the screen and the
minutes will start flashing.
 Press the SEEKorTUNE button to adjust the minutes.
 Press the CLOCK DISP button again. “Clock Is Set” will appear on the screen.
NAVIGATION SYSTEM ONLY (if so equipped)
Press theSETTING button, then select SYSTEM
SETTINGS withthejoystick andpress theEN-
TER button. Nextselect CLOCK andpress the
ENTER button to access the following clock set-
tings:
 Hours –Adjust thetime byincreasing or
decreasing by hour.
 Minutes –Adjust thetime byincreasing or
decreasing by minute.
 Auto Adjust –The time willbereset tothe
GPS time.
 Daylight Saving Time – Turn this item on for daylight savings time application.
 Select Time Zone – Choose the time zone.
CONTROL PANEL DISPLAY WITH NAVIGATION SYSTEM (if so
equipped)
TRIP BUTTON
When the TRIPbutton is pressed, the
following modeswilldisplay onthe
screen:
 Warning messages (ifthere are
any)
 TRIP 1 (Elapsed Time, Driving Dis-
tance, Average Speed)
 TRIP 2 (Elapsed Time, Driving Dis-
tance, Average Speed)
 FUEL ECONOMY (Average Fuel Economy, Distance to Empty)
 MAINTENANCE (Engine Oil, Tire Rotation and Tire Pressure)
 OFF
9

ENTRY/EXIT FUNCTION
The driver’s seat and steering column automatically move to allow the driver to get into and
out of the driver’s seat more easily. The driver’s seat slides backward and the steering column
moves up when:  The driver’s doorisopened, theignition switchisin the LOCK position andtheshift
selector lever is in the P (Park) position.
The driver’s seat and steering column return to the previous position when:
 The driver’s door is closed and the ignition switch is pushed.
XTRONIC CONTINUOUSLY VARIABLE TRANSMISSION (CVT)
The Xtronic CVTdoes notproduce agear
change sensation liketraditional automatic
transmissions.
 The transmission in your vehicle requires a spe-
cial fluid available onlyatyour NISSAN dealer.
No other fluid will meet the exact requirements of
the Xtronic CVT.
MANUAL SHIFT MODE
 When theshift selector leverisshifted fromD
(Drive) to the manual shift gate, the transmission
enters the manual shift mode.
 In the manual shift mode, shift range is displayed
on the position indicator in the meter.
 When shifting up, move the shift selector lever to
the + (up) side. (Shifts to higher range.)
 When shifting down, move the shift selector lever to the - (down) side. (Shifts to lower
range.)
 In manual shift mode, the transmission automatically shifts down to M1 (first) before the
vehicle comes to a stop. When accelerating again, it is necessary to shift to the desired
range.
 When canceling the manual shift mode, return the shift selector lever to the D (Drive)
position. The transmission returns to the normal driving mode.
11

SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light
illuminates whenevertheignition keyisturned tothe ON or
START position andremains illuminated untilthedriver’s seat
belt is fastened. At the same time, the chime sounds for approxi-
mately 6seconds unlessthedriver’s seatbeltissecurely fas-
tened.
 The seat beltwarning lightmayalso illuminate ifthe front pas-
senger’s seatbeltisnot fastened whenthefront passenger’s
seat is occupied. For 7 seconds after the ignition switch is in the ON position, the system
does not activate the warning light for the front passenger.
REAR SONAR SYSTEM OFF SWITCH (if so equipped)
When backing up, this system will beep to alert you to obstacles within 6
ft (1.8 m) of the rear bumper. The system beeps faster as the vehicle gets
closer to the obstacle. A continuous tone sounds when an obstacle is less
than 10 in (25 cm) away from the bumper. Turn the system off by pushing
the rear sonar system OFFswitch. Push the switch again to enable the
system. Thesystem willautomatically resetthenext time theignition
switch is turned on.
CHILD SAFETY REAR DOOR LOCK
Child safety locks help prevent the rear doors from
being opened accidentally, especially when small
children areinthe vehicle. Thechild safety lock
levers arelocated onthe edge ofthe rear doors.
When the lever is in the LOCK position, the door
can only be opened from the outside.
FUEL-FILLER CAP
 To tighten, turn the fuel-filler cap clockwise until ratcheting
clicks are heard. If the cap is not fully tightened, the service
engine soon light may illuminate.
 If
light illuminates becausefuelcap isloose or
missing, tighten or install the cap. The
should turn
off after a few driving trips.
13

FUEL-FILLER DOOR AND TRUNK LID RELEASE SWITCHES
FUEL-FILLER DOOR RELEASE SWITCH
Thefuel-filler doorrelease islocated onthe driver’s
door.
 To open the fuel-filler door, push the release.
 To lock, close the fuel-filler door securely.
TRUNK LID OPENER
The trunk lid opener lever is located on the driver’s door.
 To open the trunk lid, pull the opener lever out.
 To close the trunk lid, lower and push the trunk lid down securely.
TRUNK LID CANCEL SWITCH
When the cancel switch (located inside the glove box)
is OFF, the trunk lid cannot be opened with the trunk lid
opener (located on the driver’s door) , the trunk request
switch button or the Intelligent Key button.
 It can be opened by using the Emergency Inside Trunk
Release.
TILT AND TELESCOPIC STEERING COLUMN (if so equipped)
POWER TILT OPERATION
Push the switchup or down to adjust the steering
wheel to the desired position.
POWER TELESCOPIC OPERATION
Push the switchforward or backward to adjust the
steering wheel to the desired position.
OUTSIDE MIRROR CONTROL SWITCH
POWER FOLDING MIRRORS (if so equipped)
 Move the switch
to select the left or right mirror.
 Adjust eachmirror tothe desired position usingthe
switch
.
 Push the
OPEN
CLOSEswitchto fold both mirrors inor
out.
14

REVERSE TILT-DOWN FEATURE (if so equipped)
Thereverse tilt-down featurewillturn theselected outsidemirrorsurface downward to
provide better rear visibility close to the vehicle.
 Turn the outside mirror control switch to the left or right position
when the ignition
switch is in the ON position.
 Move the shift selector lever to R (Reverse) . The selected mirror will turn downward.
The selected mirror surface will return to its original position when any of the following have
occurred:
 The shift selector lever is moved to any position other than R (Reverse) .
 The outside mirror control switch is set to the neutral position.
 The ignition switch is turned to the OFF position.
MOONROOF CONTROLS (if so equipped)
The ignition switch must be in the ON position to operate
the moonroof controls.
TILTING THE MOONROOF
 To tiltthe moonroof up,push thetiltswitch tothe
UP
position. If the roof is open, it will automati-
cally close and then tilt up.
 To tilt the moonroof down, push the tilt switch to the
DOWN
position.
SLIDING THE MOONROOF
 To open the roof, slide the switch to the OPENposition. If the roof is tilted up, it will
automatically tilt down and then open.
 To close the roof, slide the switch to the CLOSE
position.
 The position of the sliding roof lid can be chosen by the position of the sliding switch.
 Tofully open orclose theroof, move theswitch completely tothe OPEN orCLOSE
position.
FRONT SEAT ADJUSTMENTS
With manual seats (passenger’s seat if so equipped):
FORWARD AND BACKWARD
 Pull up on the lever under the front of the seat and slide forward or backward. Release the
lever to lock the seat in position.
RECLINING
 Lift the lever on the side of the seat to adjust your seatback forward or backward; release
the lever when you have found a comfortable angle and the seat belt fits properly.
15
