2008 NISSAN MAXIMA trunk release

TABLE OF CONTENTS
Intelligent Key System...............................2
Windshield Wiper/Washer Switch .......................2
Headlight and Turn Signal Control .......................3
Steering Wheel Switches for Audio Control/Bluetooth
(if so equipped) ..................................4
Cruise Control ...................................4
Auto Climate Control ...............................5
FM/AM/XM Radio with CD Changer (if so equipped) ...........7
Clock Set/Adjustment ...............................9
Control Panel Display with Navigation System (if so equipped) .......9
Automatic Driver Positioner (if so equipped) .................10
Xtronic Continuously Variable Transmission (CVT) .............11
Vehicle Dynamic Control (VDC) Off Switch .................12
Front-Passenger Air Bag Status Light ....................12
Tire Pressure Monitoring System (TPMS) ..................12
Seat Belt Warning Light and Chime ......................13
Rear Sonar System Off Switch (if so equipped) ...............13
Child Safety Rear Door Lock ..........................13
Fuel-Filler Cap ..................................13
Fuel-Filler Door and Trunk Lid Release Switches ..............14
Trunk Lid Cancel Switch ............................14
Tilt and Telescopic Steering Column (if so equipped) ...........14
Outside Mirror Control Switch .........................14
Moonroof Controls (if so equipped) ......................15
Front Seat Adjustments .............................15
Folding Down the Rear Seats .........................16
Homelink Universal Transceiver (if so equipped) ..............17
Bluetooth Hands-Free Phone System (if so equipped) ..........18
Navigation System (if so equipped) ......................20
This easy-to-use Quick Reference Guide is intended to help you more fully
appreciate some of the unique features and functions of your new vehicle.
However, it is not intended to replace your Owner’s Manual. The Owner’s
Manual contains more detailed information to help you better understand the
important safety warnings, features, operation, and maintenance of your
vehicle.

INTELLIGENT KEY SYSTEM
TheIntelligent KeySystem allowsyoutolock orunlock your
vehicle, open your trunk and start the engine.
NOTE: It is important to make sure the Intelligent Key is with you
(that is, in your pocket or purse) .
 The operating range of the door and trunk lock/unlock func-
tion is approximately 31 in (0.8 m) .
 Locking thevehicle -Push anydoor handle Request
Switch
once.
 Unlocking the vehicle - Push any door handle Request
Switch
once. Thecorresponding doorwillun-
lock. Push the door handle Request Switch
again
within 1 minute; all other doors will unlock.
STARTING THE ENGINE
 Push the ignition knob in.
 Confirm the Intelligent Key warning light is illuminated green.
 Turn the ignition knob to start the engine.
TURNING THE ENGINE OFF
Shift the transmission into P (Park) .
 Turn the ignition knob to the LOCK position.
 An audible warning chime will sound when exiting the vehicle if the ignition knob is not
completely turned to the OFF position.
OPENING THE TRUNK
 To open the trunk, using the request switch, your Intelli-
gent Key must be with you.
 Push therequest/release switch
underthetrunk
handle.
 Pull up and out on the handle to open the trunk.
WINDSHIELD WIPER/WASHER SWITCH
The ignition switchmustbeinthe ON position to
activate the windshield wipers.
 Move thelever tothe following positions tooperate
the windshield wipers:
Intermittent (INT)–Front wipers operate inter-
mittently and can be further adjusted by twisting
the time control ring
.
Low Speed (LO)– Continuous low-speed operation of front wipers.
2

FUEL-FILLER DOOR AND TRUNK LID RELEASE SWITCHES
FUEL-FILLER DOOR RELEASE SWITCH
Thefuel-filler doorrelease islocated onthe driver’s
door.
 To open the fuel-filler door, push the release.
 To lock, close the fuel-filler door securely.
TRUNK LID OPENER
The trunk lid opener lever is located on the driver’s door.
 To open the trunk lid, pull the opener lever out.
 To close the trunk lid, lower and push the trunk lid down securely.
TRUNK LID CANCEL SWITCH
When the cancel switch (located inside the glove box)
is OFF, the trunk lid cannot be opened with the trunk lid
opener (located on the driver’s door) , the trunk request
switch button or the Intelligent Key button.
 It can be opened by using the Emergency Inside Trunk
Release.
TILT AND TELESCOPIC STEERING COLUMN (if so equipped)
POWER TILT OPERATION
Push the switchup or down to adjust the steering
wheel to the desired position.
POWER TELESCOPIC OPERATION
Push the switchforward or backward to adjust the
steering wheel to the desired position.
OUTSIDE MIRROR CONTROL SWITCH
POWER FOLDING MIRRORS (if so equipped)
 Move the switch
to select the left or right mirror.
 Adjust eachmirror tothe desired position usingthe
switch
.
 Push the
OPEN
CLOSEswitchto fold both mirrors inor
out.
14

With power seats (driver’s seat, if so equipped for passenger’s seat):
FORWARD AND BACKWARD  Move thecontrol
forward orbackward
to adjust theseat cushion forwardorback-
ward.
 Pull uponthe control
toraise thedriv-
er’s seat cushion; pressdowntolower the
cushion.
RECLINING
 Push the switch
forward to move the seatback forward; push it back to move the
seatback backward.
LUMBAR SUPPORT (driver’s seat, manual) (if so equipped)
 Your driver’s seat has a lumbar support; adjust it by moving the
manual lever
up or down.
FOLDING DOWN THE REAR SEATS
FROM INSIDE THE VEHICLE
 Press therelease button
tofold down
the center/passenger’s side rear seat.
 Reach through theopening andpullonthe
strap
located behindtheseat tofold
down the driver’s side rear seat.
FROM THE TRUNK
 Pull the strap
located behind the seat to
fold down thecenter/passenger’s siderear
seat.
 Pull on the strap
located behind the seat
to fold down the driver’s side rear seat.
16
