2008 MERCEDES-BENZ SL-Class display

161
Navigation
During route guidance
Available soft keys
Route soft key:
Brings you to the route display on the
map.
Mode soft key:
Brings you to the route mode selection
menu (
page 132).
Setting soft key:
Brings you to the audio settings for the
navigation announcements
(
page 133). Displaying the route on the map
In the Info menu (page 160), press
the
Route soft key.
The map will appear. The route ahead
is blue-colored.
The destination is marked with a flag $
on the map, a stopover destination is
marked with a flag showing the letter
S.
Displaying the route list
In the Info menu (page 160), press
the
Route soft key.
The route appears on the map.
Press the List soft key.
The list of the remaining roads/route
sections appears.
The road currently travelled on is at the
top of the list.
Press G or g to scroll through the
list.
Use the
Page V and Page v soft keys
to display the next or previous page.
i
If a stopover destination has been
entered:
The estimated time of arrival and the
remaining distance to the destination
are displayed.
When the stopover destination is
reached, the system calculates the
route to the main destination and
indicates estimated time of arrival and
remaining distance.
i
Depending on the distance to the
destination, it may take some time
before the route display appears. i
Depending on the distance to the
destination, it may take a few moments
before the route list is completed.
The list will only be complete when the
route is completely calculated. This is
indicated by the word
Destination in
front of the last list entry.

163
Navigation
During route guidance
Deleting the active via route
Press
g to select option Delete
Active Via
.
Press E.
The system deletes the via route and
recalculates the route to the
destination. Changing the active via route
Press
g to select option Change
Active Via
.
Press E.
The list for selecting another via route
appears.
Use G or g to select the desired via
route.
Press E.
The system recalculates the route. The detour function blocks a route section
ahead. If possible, the system will
calculate a detour. You can adjust the
length of the route section to be blocked.
Switching on
Activate the soft key display (page 160).
Press the Detour soft key.i
If you enter a new destination, the sys-
tem will automatically delete any active
via route.
Selecting a detour
i
If the system does not allow you to
block a route section, the message
No
Detour Possible
is displayed.
Traffic jams are identified by the driver,
not by the COMAND. The detour
function may also be possible if the
vehicle is traveling on a road that does
not appear on the DVD.
i
If you have already placed a block on a
route section,
Detour appears written
in black. A menu will appear instead of
the map (
page 164).

164 Navigation
During route guidance
You can now enter the length of the route
section to be blocked.
Press the More soft key until the
desired length is set.
Press the Less soft key to reduce the
length of the traffic jam.
Press E.
The system calculates a new route
around the blocked route section. Switching off
Activate the soft key display by
pressing any soft key (
page 160).
Press the Detour soft key.
Press
g to select Delete Detour.
Press E.
The blocked route section is deleted.
The system calculates the new route. Changing the blocked route section
Activate the soft key display
(
page 160).
Press the Detour soft key.
Use
G to select item Reset Detour.
Press E.
You can now change the length of the
route section to be blocked.
Press the More soft key until the
desired length is set.
Press the Less soft key to reduce the
length of the blocked route section.
Press E.
The system calculates a new route
around the blocked route section.
i
The route directly in front of the current
position can be blocked in the range of
0 to 6.2 miles.

165
Navigation
During route guidance
This function allows you to select an
intermediate destination while route
guidance is active. A stopover destination
may be a gas station or a restaurant or any
other place. When the stopover
destination is reached, the system
calculates the route to the main
destination.
Entering a stopover destination
Activate the soft key display
(
page 160).
Press the St-over soft key.
The map is displayed in full view. Available soft keys
 soft key:
Shows a list of Mercedes-Benz Centers
near your location.
 soft key:
Shows a list of filling stations around
you.
 soft key:
Shows a list of parkings and multi-
storey car parks around you.
 soft key:
Shows a list of restaurants around you.
 soft key:
Shows a list of hospitals around you.
More soft key:
If you press this soft key, the
Navigation main menu will appear.
Enter Stopover will appear on the
status bar.
You can now enter an stopover
destination by
selecting one from the destination
memory (
page 172)
typing one in the Destination Entry
menu (
page 137)
selecting one in the Last
destinations
memory
(
page 171)
selecting a POI (page 176)
Stopover function

166 Navigation
During route guidance
Press a soft key, e.g. .
Press E.
A list of restaurants near your location
is displayed. The arrows left from the entries indicate
the direction of the destination. The
distances indicated are straight line
distances to the destination.
Press
G or g to select a destination
from the list.
Press the Details soft key if required.
Details on the destination are shown.
Name soft key:
Brings you to name input of a stopover
destination (
page 209).
Sort soft key:
Sorts list entries either by increasing
distance or alphabetically.
After you have selected a destination,
press E.
The Start Route Guidance menu will
appear (
page 151).
Press E.
The system calculates the route to the
selected stopover destination. Deleting or replacing a stopover
destination
Activate the soft key display
(
page 160).
Press the St-over soft key.
The menu for deleting or changing a
stopover destination will appear.i
Prior to this, a list may be displayed in
which you can select the desired
category, e.g.
Barbecue/Southern,
pressing G or g .

167
Navigation
During route guidance
Use
g to select Delete Active
Stopover
.
Press E.
The stopover destination last input is
deleted. The system calculates the
route to the main destination.
or
Press G to select Replace Active
Stopover
.
Press E.
The stopover destination is deleted and
you can enter a new stopover
destination (
page 165). The system can save the current position
as a destination in the
Last
Destinations
memory (page 171).
Activate the soft key display
(
page 160).
Press the Memory soft key.
The current location is saved.
Activate the soft key display
(
page 160).
Press the Display soft key.
The Display menu will appear.
You can now use the soft keys to
activate other menus.
Symbol soft key:
Brings you to the symbol display
settings (
page 168).
View soft key:
Brings you to the map orientation
settings (
page 169).
i
If no stopover destination has been
entered, the full view map appears
instead of the menu. You can now
enter a stopover destination
(
page 165).
Saving the current location
i
Such destinations are marked in the
Last destinations memory with _
(
page 171). Information such as date
and time or city and street supplement
the entry (if available). You can save up
to 20 such destinations.
If a destination is to be saved for later
or repeated use, the current location
can be stored in the standard
destination memory (
page 172).
Defining route guidance displays

168 Navigation
During route guidance
GPS soft key:
Brings you to the
Position
Display
menu (page 170).
Setting symbol displays
You can set which POIs are shown as
symbols on the map.
In the Display menu, press the Symbol
soft key.
The available options are displayed.
Press G or g to select an option.
Press E.
The option is activated _.
Default option:
The map shows the default
symbols.
Personal option:
You can determine the symbols
which are displayed. The following
section explains the further
operation.
None option:
No symbols are shown on the map.
i
You will see the symbols only if the map
scale is 0.05 mi/inch, 0.1 mi/inch, 0.2
mi/inch or 0.5 mi/inch (
page 153).

169
Navigation
During route guidance
Setting personal symbol display
After selecting the Personal option,
press the
Change soft key.
The list of available personal symbols is
displayed.
Press G or g to select a list entry.
Press E.
The symbol is activated or deactivated
depending on its previous state. You
may also activate more than one
symbol.
Press the Back soft key to confirm.
The settings are saved.
Setting map view
You can select the follwing map
orientations:
2D North Up
Map is displayed facing north
2D Heading Up
Dynamic map alignment, map is
displayed facing driving direction
pointing up
Bird’s-Eye View
The map is shown in three dimensions
with sky and horizon.
In the Display menu (page 167),
press the
View soft key.
The available options are shown. Changing map view
Press
G or g to select the
deactivated option.
Press E.
The orientation is changed.
Press the Back soft key to confirm.
MeaningSymbol
Selected Q
Unselected q
OptionSymbol
On_
Off -
