2008 MERCEDES-BENZ S-Class display

457 Controls in detail
Driving systems
DISTRONIC Plus lever
The DISTRONIC Plus system is operated by
means of the DISTRONIC Plus lever.
1Setting current or higher speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
2Setting current or lower speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
3Canceling DISTRONIC Plus
4Activating DISTRONIC Plus or resum-
ing to last set speed5Setting target distance
Activating DISTRONIC Plus
You can activate DISTRONIC Plus when:


you are driving slower than 20 mph
(30 km/h) and DISTRONIC Plus has
detected a vehicle ahead of you


you are driving above 20 mph
(30 km/h)
If DISTRONIC Plus has not been activated
after pressing the DISTRONIC Plus lever,
you will see the message: “DISTRONIC
PLUS - - - mph” (Canada: “DISTRONIC PLUS
- - - kmh”) in the multifunction display.
Warning!
G
When DISTRONIC Plus is braking, the brake
pedal is retracted (i.e. depressed automati-
cally). The pedals’ range of motion must not
be impeded by any obstacles:

Do not place any objects in the footwell.


Make sure that the floor mats and car-
pets are securely in place.


Do not rest your foot underneath the
brake pedal, as it could otherwise be
trapped.
You could otherwise cause an accident and
injure yourself and others.
Warning!
G
When DISTRONIC Plus is switched on, the
vehicle can be braked. You should therefore
switch off DISTRONIC Plus if the vehicle
must be towed.i
The maximum speed you can set is 120 mph
(Canada: 200 km/h).

458 Controls in detailDriving systemsIn the following cases you cannot activate
DISTRONIC Plus:

up to 2 minutes after starting the en-
gine


if the engine is switched off


if you step on the brake pedal while
driving


the vehicle is secured with the elec-
tronic parking brake


if the gear selector lever is in park
positionP, reverse gearR, or neutral
positionN


if ESP
® is switched off


if the hood is open


if the driver’s door is open and the driv-
er has not fastened his or her seat belt


if the radar sensors are switched off
(page 307).Switching on while driving

Tap DISTRONIC Plus lever up1 or
down2 until desired speed is set.
DISTRONIC Plus is switched on.
or

Pull DISTRONIC Plus lever briefly in di-
rection of arrow4 to call up speed
last set (
page 463).
DISTRONIC Plus is switched on.

Take your foot off the accelerator ped-
al.
Your vehicle adapts its speed to the ve-
hicle ahead, observing the set speed as
a maximum value.
i
Under 20 mph (30 km/h), you can only
switch on DISTRONIC Plus if the vehicle ahead of
you has been detected and is shown on the mul-
tifunction display. If you no longer see the vehi-
cle in front of you on the multifunction display
and if it is no longer detected because it has
changed lanes, for example, DISTRONIC Plus
switches off and you will hear a signal.
i
If you do not completely lift your foot off the
accelerator pedal, the message“DISTRONIC
PLUS Override” appears on the multifunction
display. The distance to a slower-driving vehicle
will not be set. You will drive at the speed you
dictate by pressing the accelerator pedal.

459 Controls in detail
Driving systems
Switching on when approaching a sta-
tionary vehicle
If the vehicle in front of you is stationary,
you can only switch on DISTRONIC Plus if
your vehicle is also at a standstill.
Tap DISTRONIC Plus lever up1 or
down2 until desired speed is set.
DISTRONIC Plus is switched on.
or

Pull DISTRONIC Plus lever briefly in di-
rection of arrow4 to call up speed
last set (
page 463).
DISTRONIC Plus is switched on.Starting off
When the vehicle in front of you starts off:

Remove your foot from the brake
pedal.

Pull DISTRONIC Plus lever briefly in di-
rection of arrow4.
or

Briefly step on the accelerator pedal.
Your vehicle starts off and adapts its speed
to the vehicle in front of you.Driving
If no vehicle is driving ahead of you,
DISTRONIC Plus functions like the cruise
control (
page 446).
When DISTRONIC Plus detects that the ve-
hicle in front of you is driving more slowly,
it brakes the vehicle in order to keep the
distance specified by you.
When DISTRONIC Plus detects that the ve-
hicle in front of you is driving faster, the ve-
hicle accelerates up to the set speed.
i
It is helpful to switch on the DISTRONIC Plus
display in the instrument cluster (
page 455)
since you can only switch on DISTRONIC Plus un-
d e r a s p e e d o f 2 0 m p h ( 3 0 k m / h ) w h e n a v e h i c l e
has been detected in front of you.
i
You can adjust the set speed using the
DISTRONIC Plus lever and the target distance
using the distance setting switch on the
DISTRONIC Plus lever (
page 464).
i
If DISTRONIC Plus is switched off,
PRE-SAFE
® Brake* (
page 77) will warn of an
impending collision if this function has been ac-
tivated with the instrument cluster control sys-
tem (
page 303).
Warning!
G
When you step on the brake pedal, you
switch off DISTRONIC Plus except when the
vehicle is at a standstill. DISTRONIC Plus will
no longer brake your vehicle. You are always
responsible for maintaining a distance from
other vehicles, observing road speeds and
braking well in advance.

461 Controls in detail
Driving systems
Setting a higher speed
You can increase the set speed in two
stages.Adjustment in 1 mph (Canada: 1 km/h)
increments

Briefly lift the DISTRONIC Plus lever to
the resistance point in direction of
arrow1 (
page 457).

Release the DISTRONIC Plus lever.
The vehicle speed increases in incre-
ments of 1 mph (Canada: 1 km/h).Adjustment in 5 mph
(Canada: 10 km/h) increments

Briefly lift the DISTRONIC Plus lever
past the resistance point in direction of
arrow1 (
page 457).

Release the DISTRONIC Plus lever.
i
If you do not take your foot off of the accel-
erator completely, the following message
“DISTRONIC PLUS Override” will appear in the
multifunction display.
The distance to a slower moving vehicle in front
of you will not be set. Your vehicle speed will
then be determined only by the accelerator ped-
al position.Warning!
G
If you increase the set speed, keep in mind
that it may take a brief moment until the ve-
hicle has reached the set speed.
Increase the set speed to a value that the
prevailing road conditions and legal speed
limits permit. Otherwise, sudden and unex-
pected acceleration of the vehicle could
cause an accident and/or serious injury to
you and others.
i
The set speed value is increased in 1 mph
(Canada: 1 km/h) increments each time you lift
the DISTRONIC Plus lever to the resistance
point.
Warning!
G
You can increase the vehicle speed in 5 mph
(Canada: 10 km/h) increments. When using
this feature, keep in mind that it may take a
brief moment until the vehicle has reached
the set speed.
Increase the vehicle speed to a value that
the prevailing road conditions permit. Other-
wise, sudden and unexpected acceleration
of the vehicle could cause an accident
and/or serious injury to you and others.i
The set value is increased in 5 mph
(Canada: 10 km/h) increments each time you
lift the DISTRONIC Plus lever past the resistance
point.


464 Controls in detailDriving systems

you set the automatic transmission to
park positionP, reverse gearR, or neu-
tral positionN while driving


the radar sensors are switched off
(page 307)


the vehicle rolls backward
The segments in the multifunction display
go out, an acoustic signal sounds, and the
message “DISTRONIC PLUS Off” appears in
the multifunction display for approximately
5 seconds.
If the vehicle has been stopped by
DISTRONIC Plus and a malfunction occurs
in the system, the message “Brake Immedi-
ately” will appear on the multifunction dis-
play. Step on the brake immediately to
prevent the vehicle from rolling.
DISTRONIC Plus is then switched off and
the message disappears.Setting the following distance in
DISTRONIC Plus
You can set the specified following dis-
tance for DISTRONIC Plus by varying the
time setting between 1.0 and 2.0 seconds.
Using this time setting and the current set
speed of your vehicle, DISTRONIC Plus cal-
culates and sets the required following dis-
tance to the vehicle ahead. The set
distance will be shown in the multifunction
display.
Warning!
G
DISTRONIC Plus switches off and releases
the brakes when the vehicle decelerates be-
low the minimum speed of 20 mph
(30 km/h) by operation of the system un-
less DISTRONIC Plus detects a vehicle di-
rectly ahead of you. At that time the driver
must apply the brakes in order to reduce ve-
hicle speed further or bring it to a stop.!
Setting the automatic transmission toN
while driving cancels the DISTRONIC Plus. How-
ever, the automatic transmission should not be
set toN while driving except to coast when the
vehicle is in danger of skidding (e.g. on icy
roads).
i
Depressing the accelerator pedal does not
deactivate DISTRONIC Plus. After brief accelera-
tion (e.g. for passing), DISTRONIC Plus will re-
sume the last speed set.
Warning!
G
It is up to the driver to exercise discretion to
select the appropriate setting given road
conditions, traffic, driver’s preferred driving
style and applicable laws and driving recom-
mendations for safe following distance.

466 Controls in detailDriving systemsThe most likely cause for a malfunctioning
system is a dirty sensor (located behind
the hood grille), especially at times of snow
and ice or heavy rain. In such a case,
DISTRONIC Plus will switch off, and the
message:
“DISTRONIC PLUS
Currently Unavailable
See Oper. Manual”
appears in the multifunction display.
For cleaning and care of the
DISTRONIC Plus sensor, see “Cleaning the
DISTRONIC Plus*/ PRE-SAFE
® Brake*
system sensors (USA only)” (page 619).Another cause might be that the radar sen-
sors have been manually switched off in
the instrument cluster control system.
Please verify that the radar sensors are
switched on (
page 307).Turns and bends
In turns or bends, DISTRONIC Plus may not
detect a moving vehicle in front, or it may
detect one too soon. This may cause your
vehicle to brake late or unexpectedly.
Warning!
G
DISTRONIC Plus should not be used in
snowy or icy road conditions.
i
If the message:
“DISTRONIC PLUS
Currently Unavailable
See Oper. Manual”
disappears during driving and the last speed
stored flashes for approximately 5 seconds, the
dirt (e.g. slush) has dissolved; DISTRONIC Plus is
again available.

469 Controls in detail
Driving systems
Vehicle level control with Airmatic
Your vehicle automatically adjusts its ride
height to:

increase vehicle safety


reduce fuel consumption
The vehicle chassis ride height is raised or
lowered according to the selected level
setting and to the vehicle speed:


W it h inc re a sing s pe ed, ri de hei ght is re -
duced by up to approximately 0.8 in
(20 mm).


With decreasing speed, the ride height
is again raised to the selected vehicle
level.The following vehicle level settings can be
selected when the vehicle is stationary:
Select the “Raised” level setting only when
required by current driving conditions.
Otherwise:


Fuel consumption may increase.


Handling may be impaired.1Vehicle level control switch
2Indicator lamp

Start the engine.

Briefly press switch1 to change from
one level setting to the other.
The message:
“Vehicle Rising”
appears in the multifunction display
when changing from normal level to
raised level.
The indicator lamp2 is then lit. The
display switches off when the vehicle is
raised.
Warning!
G
To help avoid personal injury, keep hands
and feet away from wheel housing area, and
stay away from under the vehicle when low-
ering the vehicle chassis.
i
These height adjustments are so small that
you may not notice any change.
LevelNormal
For driving on normal roads.
The indicator lamp is off.
Raised
For driving on rough roads or
with snow chains. The indica-
tor lamp is on.


481 Controls in detail
Driving systems

Switching off Park Assist system:
Press button 1.
Indicator lamp 2 comes on.

Switching on Park Assist system:
Press button 1 again.
Indicator lamp 2 goes out.
Advanced Parking Guidance*
Advanced Parking Guidance is an electron-
ic parking aid equipped with radar sensors
that scan the area on both sides of vehicle.
When suitable parking space is found it is
shown in the display and you receive steer-
ing instructions for parking in that space.
i
The Park Assist system is automatically
switched on when the ignition (
page 370) and
radar sensors are switched on (page 307).
Warning!
G
Advanced Parking Guidance is only an aid
and may display parking spaces that are not
suitable e.g. due to parking regulations, un-
suitable road/ground surfaces, driveways,
entrances/exits, etc.
Advanced Parking Guidance only shows a
representation of the parking space in the
instrument cluster display as parking space
is first initially measured when driving past.
Subsequent changes to the parking space
are not taken into account, e.g. if the posi-
tion of the vehicle parked in front of or be-
hind the space changes or objects in the
parking space are moved. Moving objects
are not shown, e.g. pedestrians or vehicles
driving past. Advanced Parking Guidance
does not relieve you of the responsibility to
pay attention. If you only rely on Advanced
Parking Guidance, you may cause an acci-
dent and injure yourself and others.
You are always responsible for safety and
must continue to pay attention to your im-
mediate surroundings when parking and
maneuvering.
