2008 MERCEDES-BENZ S-Class Vehicle

313 Control systems
Voice Control telephone
Voice Control telephone
Telephone operation
The Voice Control System gives you the
following capabilities:

Enter a telephone unlock code


Dial a phone number by speaking the
telephone number


Store names and numbers in the
COMAND address book


Dial a phone number by speaking the
name of an COMAND address book en-
try


Delete an address book entry from the
address book


Have the system read out the phone
book of the address book entry by en-
try


Manage and access an automated an-
swering system/voice mail box


Redial names and numbers
Warning!
G
Some jurisdictions prohibit the driver from
using a cellular telephone while driving.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellu-
lar telephone while the vehicle is in motion.
Stop the vehicle in a safe location before
placing or answering a call.
If you nonetheless choose to use the mobile
phone while driving, please use the hands-
free feature and be sure to pay attention to
the traffic situation at all times. Use the mo-
bile phone only when road, weather and traf-
fic conditions permit. Otherwise, you may
not be able to observe traffic conditions and
could endanger yourself and others.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approxima-
tely 14 m) every second.
Warning!
G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.i
Various mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter. For more information about telephone
(
page 539).
i
The roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
(
page 539) to make a call.

320 Control systemsVoice Control navigationImportant notesWarning!
G
For safety reasons, you should only select a
destination when the vehicle is stationary.
While the navigation system provides direc-
tional assistance, the driver must remain fo-
cused on safe driving behavior, especially
attention to traffic and street signs, and
should utilize the system’s audio cues while
driving.
The navigation system does not supply any
information on stop signs, yield signs, traffic
regulations or traffic safety rules. Their ob-
servance always remains in the driver’ per-
sonal responsibility. DVD maps do not cover
all areas nor all routes within an area.
Traffic regulations always have priority over
any route recommendations given.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 13.5 m) every second.
During route guidance, you will not receive
information on:

traffic lights


stop and yield signs


parking or stopping zones


one-way streets


narrow bridges, or


other traffic regulation data.
You should therefore always strictly observe
traffic regulations while driving. Drive care-
fully and always obey traffic laws and road
signs, even if they contradict navigation sys-
tem instructions.
Warning!
G
Please do not use the Voice Control System
in an emergency, as the tone of your voice
may change in a stressful situation. This
could cause a delay in completing your
phone call in a timely manner. This could
distract you in an emergency situation and
cause you to be involved in an accident.
Warning!
G
Navigation announcements are intended to
direct you while driving without diverting
your attention from the road and driving.
Please always use this feature instead of
consulting the map display for directions.
Consulting the symbols or map display for
directions may cause you to divert your at-
tention from driving and increase your risk
of an accident.

340 Control systemsVoice Control command listCommand list
Chapter “Command list” gives you on over-
view of all commands available for use to
control the Voice Control System.
Which commands are available for use is
dependent on the equipment level in your
vehicle.General commandsi
Some functions can be operated using sev-
eral different commands. In the following list,
these commands are grouped in one cell.
Choose your preferred command from those
available.


yes


right


ok


cancel


stop


quit


abort


terminate


no


no thank you


address book


MP3


CD


navigation


route guidance


audio DVD


radio


sat radio


satellite radio


telephone


messages


SMS


vehicle


correction


wrong


incorrect


help


help please


please help


help functions


help devices


help voice control


linguatronic help


general help


help permanent commands

355 Control systems
Voice Control individualization
Voice Control individualization
The individualization is used to adapt the
Voice Control System to your own voice
and to therefore improve speech recogni-
tion. This does not affect the speech rec-
ognition of other users.
Individualization consists of two stages:

Digits


Commands
You can activate individualization in the
COMAND system settings (
page 261).
A dialog and screen displays will guide you
through the individualization process.
The system can be reset to the factory set-
tings at any time.
i
The individualization can only be performed
when the vehicle is stationary.
If you drive off, the individualization will be can-
celed.
After starting the session, the system will guide
you through the individualization by means of
acoustic instructions.
i
You may wish to complete only a portion of
the individualization process.
Completing the digits portion alone may result in
an improved recognition rate.
Individualization can be exited at any time. The
data trained, however, will only be retained if a
given individualization portion is completed and
the data is stored when prompted to do so by the
system.

358 Controls in detailLocking and unlockingSmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks,
when set to factory settings (
page 359):


the doors


the trunk


the fuel filler flap
SmartKey with remote control1‹ Lock button
2ŠOpening button for trunk
(
page 511)
3Mechanical key locking tab
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 66)
!
To prevent possible malfunction, avoid ex-
posing the SmartKey to high levels of electro-
magnetic radiation.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal inju-
ry.Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
or trunk lid opening when closing a door or
the trunk. Be especially careful when small
children are around.
Before closing doors, make sure there is no
possibility of someone getting caught in a
door during closing.

359 Controls in detail
Locking and unlocking
Factory setting
Global unlocking: Press buttonŒ.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
You can also open and close the door win-
dows and tilt/sliding sunroof, or the tilt/ sliding
panel* using the SmartKey (
page 412).
!
If you cannot lock or unlock the vehicle with
the SmartKey, then either the batteries in the
SmartKey are discharged, the SmartKey is mal-
functioning or the vehicle batteries are drained.


Check the batteries in the SmartKey and re-
place them if necessary (
page 712).


Use the mechanical key to unlock the driv-
er’s door (
page 708) and the trunk
(
page 709).


Use the mechanical key to lock the driver’s
door (
page 709) and the trunk
(
page 517).


Have the vehicle batteries and their connec-
tions checked (
page 729).
If the SmartKey is malfunctioning, contact Road-
side Assistance or an authorized Mercedes-Benz
Center.
i
Your vehicle may be equipped with an
acoustic lock and unlock confirmation signal fea-
ture. If your vehicle is equipped with this feature
and the feature is activated, an acoustic signal
will sound when the vehicle is locked or unlocked
using the SmartKey.
To determine whether or not your vehicle is
equipped with this feature, contact an autho-
rized Mercedes-Benz Center. If equipped and
you wish to activate or deactivate the feature, or
adjust its signal volume, also contact an autho-
rized Mercedes-Benz Center.

360 Controls in detailLocking and unlockingThe vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:

neither a door nor the trunk is opened


the SmartKey is not inserted in the
starter switch


the central locking/unlocking switch is
not activated

Global locking: Press button‹.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that press-
ing buttonŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 358)
flashes twice.
The SmartKey will then function as fol-
lows:

Unlocking driver’s door and fuel fill-
er flap: Press buttonΠonce.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 359).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.

Global unlocking: Press buttonŒ
twice.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.

Global locking: Press button‹.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.

361 Controls in detail
Locking and unlocking

Restoring to factory setting: Press
and hold buttonsŒ and‹ si-
multaneously for about 5 seconds until
battery check lamp5 (
page 358)
flashes twice.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you grasp an outside
door handle.
With the KEYLESS-GO function, you can
lock and unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey in the starter switch.The SmartKey with KEYLESS-GO centrally
locks and unlocks, when set to factory set-
tings (
page 364):


the doors


the trunk


the fuel filler flap
SmartKey with KEYLESS-GO1‹ Lock button
2ŠOpening button for trunk
(
page 511)
3Locking tab for mechanical key
4ΠUnlock button
5Battery check lamp
6ÂPanic button (
page 66)
i
When any outside door handle other than
the driver’s outside door handle is grasped, the
vehicle is centrally unlocked.
!
To prevent possible malfunction, avoid ex-
posing the SmartKey with KEYLESS-GO to high
levels of electromagnetic radiation.
Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
Children could start the vehicle with a valid
SmartKey with KEYLESS-GO left in the vehi-
cle or with the KEYLESS-GO button on the
starter switch, or could release the electron-
ic parking brake, thereby putting them-
selves and others in danger. Switch off the
engine and take the SmartKey with
KEYLESS-GO with you even if you are only
leaving the vehicle for a short while.
