2008 MAZDA MODEL TRIBUTE Owners Manual (in English)

Auxiliary input jack
Your vehicle is equipped with an
Auxiliary Input Jack (AIJ). The
Auxiliary Input Jack provides a way
to connect your portable music
player to the in-vehicle audio
system. This allows the audio from a
portable music player to be played
through the vehicle speakers with
high fidelity. To achieve optimal
performance, please observe the
following instructions when
attaching your portable music
device to the audio system.
Required equipment: 1. Any portable music player designed to be used with headphones
2. An audio extension cable with stereo male 1/8 in. (3.5 mm) connectors at each end
To play your portable music player using the auxiliary input jack: 1. Begin with the vehicle parked and the radio turned off.
2. Ensure that the battery in your portable music player is new or fully charged and that the device is turned off.
3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable
to the AIJ in your vehicle.
4. Turn the radio on, using either a tuned FM station or a CD loaded into the system. Adjust the volume to a comfortable listening level.
5. Turn the portable music player on and adjust the volume to 1/2 the volume.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
25

6. Press AUX on the vehicle radio repeatedly until LINE IN appears in the display.
You should hear audio from your portable music player although it
may be low.
7. Adjust the sound on your portable music player until it reaches the level of the FM station or CD by switching back and forth between
the AUX and FM or CD controls.
Troubleshooting: 1. Do not connect the audio input jack to a line level output. Line level outputs are intended for connection to a home stereo and are not
compatible with the AIJ. The AIJ will only work correctly with
devices that have a headphone output with a volume control.
2. Do not set the portable music player’s volume level higher than is necessary to match the volume of the CD or FM radio in your audio
system as this will cause distortion and will reduce sound quality.
Many portable music players have different output levels, so not all
players should be set at the same levels. Some players will sound
best at full volume and others will need to be set at a lower volume.
3. If the music sounds distorted at lower listening levels, turn the portable music player volume down. If the problems persists, replace
or recharge the batteries in the portable music player.
4. The portable music player must be controlled in the same way manner when it is used with headphones as the AIJ does not provide
control (play, pause, etc.) over the attached portable music player.
5. For safety reasons, connecting or adjusting the settings on your portable music player should not be attempted while the vehicle is
moving. Also, the portable music player should be stored in a secure
location, such as the center console or the glove box, when the
vehicle is in motion. The audio extension cable must be long enough
to allow the portable music player to be safely stored while the
vehicle is in motion.
GENERAL AUDIO INFORMATION
Radio frequencies:
AM and FM frequencies are established by the Federal Communications
Commission (FCC) and the Canadian Radio and Telecommunications
Commission (CRTC). Those frequencies are:
AM: 530, 540–1700, 1710 kHz
FM: 87.7, 87.9–107.7, 107.9 MHz
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
26

Radio reception factors:
There are three factors that can affect radio reception:
• Distance/strength: The further you travel from an FM station, the
weaker the signal and the weaker the reception.
• Terrain: Hills, mountains, tall buildings, power lines, electric fences,
traffic lights and thunderstorms can interfere with your reception.
• Station overload: When you pass a broadcast tower, a stronger signal
may overtake a weaker one and play while the weak station frequency
is displayed.
CD/CD player care
Do:
• Handle discs by their edges only.
(Never touch the playing
surface).
• Inspect discs before playing.
• Clean only with an approved CD
cleaner.
• Wipe discs from the center out.
Don’t:
• Expose discs to direct sunlight or heat sources for extended periods
of time.
• Clean using a circular motion.
CD units are designed to play commercially pressed 4.75 in (12 cm)
audio compact discs only. Due to technical incompatibility, certain
recordable and re-recordable compact discs may not function
correctly when used in Mazda CD players.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
27

Do not use any irregular shaped
CDs or discs with a scratch
protection film attached.
CDs with homemade paper
(adhesive) labels should not be
inserted into the CD player as
the label may peel and cause the
CD to become jammed. It is
recommended that homemade
CDs be identified with
permanent felt tip marker rather
than adhesive labels. Ballpoint pens may damage CDs. Please
contact your authorized dealer for further information.
Audio system warranty and service
Refer to the Warranty Information Booklet for audio system warranty
information. If service is necessary, see your authorized Mazda
dealership.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
28

MANUAL HEATING AND AIR CONDITIONING SYSTEM 1.
Fan speed adjustment: Controls the volume of air circulated in
the vehicle.
2.
RRear defroster: Press to activate/deactivate the rear window
defroster. Refer to Rear window defroster later in this chapter for
more information.
3.
Defrost: Distributes outside air through the windshield
defroster vents and demister vents. Can be used to clear the
windshield of fog and thin ice. The system will automatically provide
outside air to reduce window fogging. Press this button again to
return to the previous air flow selection.
4.
: Distributes air through the windshield defroster vents,
demister vents, floor vents and rear seat floor vents. The system will
automatically provide outside air to reduce window fogging.
5.
Power: Press to activate/deactivate the climate control system.
When the system is off, outside air is shut out.
6.
: Distributes air through the instrument panel vents.
7.
: Distributes air through the instrument panel vents, demister
vents, floor vents and rear seat floor vents.
8.
: Distributes air through the demister vents, floor vents and rear
seat floor vents.
9. Temperature control: Controls the temperature of the airflow in
the vehicle.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Climate Controls
29

10.Passenger heated seat control (if equipped):Press to
activate/deactivate the passenger heated seat. See Heated seatsin
the Seating and Safety Restraints chapter.
11.
Recirculated air: Press to activate/deactivate air
recirculation in the vehicle. Recirculated air may reduce the amount
of time needed to cool down the interior of the vehicle and may also
help reduce undesired odors from reaching the interior of the
vehicle. Recirculated air engages automatically when MAX A/C is
selected or can be engaged manually in any airflow mode
except
(defrost). Recirculated air may turn off automatically in
all airflow modes except MAX A/C. When the ignition switch is
turned off and back on, the climate system will return to the
recirculated air mode only if the A/C button LED is illuminated and
the air distribution selection is either(panel) or(panel/floor).
12. MAX A/C: Distributes recirculated air through the instrument panel
vents to cool the vehicle. This re-cooling of the interior air is more
economical and efficient. Recirculated air may also help reduce
undesirable odors from entering the vehicle. Press the MAX A/C
button again for normal A/C operation.
13. A/C: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency.
Engages automatically in MAX A/C,
(defrost) and
(floor/defrost).
14.
Driver heated seat control (if equipped): Press to
activate/deactivate the driver heated seat. See Heated seatsin the
Seating and Safety Restraints chapter.
Outside temperature (if equipped): The outside temperature will
appear in the display and is labeled EXT TEMP.
Operating tips
• To reduce fog build up on the windshield during humid weather,
select
(defrost) or(floor/defrost).
• To reduce humidity build up inside the vehicle, do not drive with the
system off or with
(recirculated air) engaged and A/C off.
• Do not put objects under the front seats that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves from the air intake area at the base of
the windshield.
• To improve the A/C cool down, drive with the windows slightly open
for 2-3 minutes after start up or until the vehicle has been “aired out.”
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Climate Controls
30

For maximum cooling performance in MAX A/C mode: 1. Select MAX A/C.
2. Move temperature control selector to the coolest setting.
3. Set the fan to the highest speed initially, then adjust to maintain comfort.
To aid in side window defogging/demisting in cold weather:
1. Select
.
2. Select A/C.
3. Adjust the temperature control to maintain comfort.
4. Set the fan speed to the highest setting.
5. Direct the outer instrument panel vents towards the side windows.
To increase airflow to the outer instrument panel vents, close the vents
located in the middle of the instrument panel.
WARNING: Do not place objects on top of the instrument panel
as these objects may become projectiles in a collision or sudden
stop.
REAR WINDOW DEFROSTER
R
The rear defroster control is located on the climate control panel and
works to clear the rear window of fog and thin ice.
The engine must be running to operate the rear window defroster.
Press
Rto turn the rear window defroster on. An indicator light on
the button will illuminate when active. The rear window defroster turns
off automatically after a predetermined amount of time, if a low battery
condition is detected or when the ignition is turned to the 1 (LOCK) or
2 (ACC) position. To manually turn off the rear window defroster at any
time, press the control again.
If your vehicle is equipped with both rear defroster and heated mirrors,
the same button will activate both. Refer to Heated outside mirrorsin
the Driver Controls chapter.
Do not use razor blades or other sharp objects to clean the inside
of the rear window or to remove decals from the inside or the
rear window. This may cause damage to the heated grid lines and
will not be covered by your warranty.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Climate Controls
31

HEADLAMP CONTROL
Rotate the headlamp control to the
first position
to turn on the
parking lamps. Rotate to the second
position
to turn on the
headlamps.
Foglamp control (if equipped)
The headlamp control also operates
the foglamps. The foglamps can be
turned on when the headlamp
control is in the
,or
positions and the high beams are
not turned on.
Pull headlamp control towards you
to turn foglamps on. The foglamp
indicator light
will illuminate.
High beams
After turning the headlamps on,
push the lever toward the
instrument panel to activate. Pull
the lever towards you to deactivate.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Lights
