2008 Lexus ES350 display

5
When trouble arises
373
5-2. Steps to take in an emergency
ES350_U_(L/O_0708)
If a warning message is displayed
Stop the vehicle immediately.The following warnings indicate the possibility of damage to the vehicle
that may lead to an accident. Immediately stop the vehicle in a safe place
and contact your Lexus dealer.
Warning messageDetails
(Flashing)
Indicates an abnormal engine oil pressure. A buzzer also sounds.
If a warning is shown on the multi-information display, stay calm and per-
form the following actions:
Master warning light
The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
Multi-information display
If any of the warning message turns on again after performing the fol-
lowing actions, contact your Lexus dealer.

5
When trouble arises
375
5-2. Steps to take in an emergency
ES350_U_(L/O_0708)
Warning messageDetails
(If equipped)
Indicates intuitive parking assist malfunction.A buzzer also sounds.
The malfunctioning assist-sensor is shown flashing on
the display.
(Flashing)
(Flashing)
(If equipped)
Indicates a malfunction in the radar cruise control
system. A buzzer also sounds.
Stop the vehicle in a safe place. Switch the “ENGINE
START STOP” switch to OFF and then to IGNITION
ON mode again to reset the cruise control system.
Indicates a malfunction in the TRAC and VSC sys-
tems.

380
5-2. Steps to take in an emergency
ES350_U_(L/O_0708)
Warning messageDetailsCorrection procedure
(Flashing and then con-tinuously on)
(Flashing)
(If equipped)
Indicates that the radar
cruise control system is
unable to judge vehicle-
to-vehicle distance
because the windshield
wipers are set at high
speed operation mode. A buzzer also sounds.
Turn them off or set them
to either the intermittent
or the slow mode.
(Flashing)
(If equipped)
Indicates that your vehi-
cle is nearing the vehicle
ahead (in radar cruise
mode). A buzzer also sounds.
Slow the vehicle by apply-
ing the brakes.
■Changing the engine oil (USA only)
Make sure to reset the oil change system. ( →P. 303)
■Warning light display in radar cruise mode
In the following cases, the warning light may not be displayed even if vehicle-to-
vehicle distance closes.
●When your vehicle and the vehicle ahead are traveling at the same speed or the
vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed

382
5-2. Steps to take in an emergency
ES350_U_(L/O_0708)
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
Once3 times
(Flashing)
Indicates that the
driver’s door has
been opened or
closed with the
shift lever in P, the
“ENGINE START
STOP” switch in
any mode other
than OFF and the
electronic key
outside of the
detection area.
Tu r n t h e
“ENGINE START
STOP” switch
OFF or confirm
the location of the
electronic key.
Con-
tinuousCon-
tinuous
(Displayed alternately)
(Flashing)
Indicates that the
driver’s door has
been opened or
closed with the
shift lever out of in
P, the “ENGINE
S TA R T S TO P ”
switch in any
mode other than
OFF and the elec-
tronic key outside
of the detection
area.
• Shift the shift lever to P.
• Confirm the
location of the
electronic key.
Once
(Flashing)
Indicates that the
key battery is low.Replace the bat-
t e r y. ( →P. 3 3 2 )

436
6-2. Customization
ES350_U_(L/O_0708)
Moon roof
(standard
type)
(
→P. 63)
Linked mechanical key
operationON
(Open and close)OFF
Open only
Close only
Linked operation of com-
ponents when mechanical
key is used
Slide onlyTilt only
Wireless remote control
linked operationON
(Open only)OFF
Linked operation of com-
ponents when wireless
remote control used
Slide onlyTilt only
Linked entry functionONOFF
Automatic
light control
system
(
→P. 1 3 2 )
Light sensor sensitivityLevel 3Level 1 to 5
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
0 seconds
60 seconds
90 seconds
Lights
(
→P. 1 3 2 )
Daytime running light sys-
tem (USA only)ONOFF
Intuitive park-
ing assist
(
→P. 151)
Back sensor operation
display and buzzerONOFF
Buzzer volumeLevel 3Level 1 to 5
Distance which a sensor
detects4.5 ft. (150 cm)1.8 ft. (60 cm)
ItemFunctionDefault settingCustomized setting

437
6-2. Customization
6
Vehicle specifications
ES350_U_(L/O_0708)
Multi-information display (→P. 1 2 8 )
Illumination
(
→P. 2 4 7 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedONOFF
Operation after the
“ENGINE START STOP”
switch turned OFF
ONOFF
Front foot well lightingONOFF
Outer foot lightONOFF
Seat belt
reminder
(
→P. 364)
Vehicle speed linked seat
belt reminder buzzerONOFF
CountryAvailable languages
CanadaEnglish and French
ItemFunctionDefault settingCustomized
setting

442
ES350_U_(L/O_0708)
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONSMEANING
A /CAir Conditioning
ABSAnti-Lock Brake System
AFSAdaptive Front lighting System
AI-SHIFTArtificial Intelligence Shift
ALRAutomatic Locking Retractor
CRSChild Restraint System
DISPDisplay
ECUElectronic Control Unit
EDREvent data recorder
ELREmergency Locking Retractor
G AW RGross Axle Weight Ratings
GVWRGross Vehicle Weight Rating
HIHigh
I/MEmission inspection and maintenance
INTIntermittent
LEDLight Emitting Diode
LOLow
MMTMethylcyclopentadienyl Manganese Tricarbonyl
MTBEMethyl Tertiary Butyl Ether
OBDOn Board Diagnostics
PCSPre-Collision System
SRSSupplemental Restraint System
TINTire Identification Number
TPMSTire Pressure Warning System
TRACTraction Control

446
Alphabetical index
ES350_U_(L/O_0708)
DisplayDynamic radar crui se control ....... 142
Trip information .................................... 129
Warning message............................. 373
Do-it-yourself maintenance ............. 294
Door courtesy lights Door courtesy lights..........................247
Wattage.................................................... 417
Doors Door glasses ........................................... 60
Door lock................................. 22, 34, 37
Side mirrors ............................................. 58
Driver's seat belt reminder light ..... 364
Driving Break-in tips ...........................................107
Correct posture .................................... 75
Procedures ............................................ 106
Winter driving tips............................... 167
Driving position memory ...................... 44
Electronic key If the electronic key does not
operate properly ............................398
Emergency, in case of
If the electronic key does not operate properly ............................398
If the engine will not start ............... 394
If the shift lever cannot be shifted from P ...................................396
If the vehicle has discharged
battery ................................................. 400
If the warning buzzer sounds ...... 362
If the warning light turns on .......... 362 If the warning message is
displayed .............................................373
If you have a flat tire ........................ 384
If you lose your keys .........................397
If you think something is wrong .................................................. 358
If your vehicle becomes stuck .... 405
If your vehicle needs to be towed ................................................... 352
If your vehicle overheats................ 403
Engine Compartment ....................................... 301
Engine switch .......................................... 114
Hood ....................................................... 298
How to start the engine ..................... 114
Identification number ...................... 409
If the engine will not start ............... 394
Ignition switch ......................................... 114
Overheating ........................................ 403
Engine compartment cover ............. 302
Engine coolant Capacity .................................................. 412
Checking............................................... 307
Preparing and checking
before winter...................................... 167
Engine coolant temperature
gauge ....................................................... 122
Engine immobilizer system ................. 70
Engine oil Capacity .................................................... 411
Checking............................................... 303
Preparing and checking
before winter...................................... 167
Engine oil maintenance data ........... 306
Event data recorder ............................ 360
E
