2008 INFINITI QX56 Ignition switch removal

PWC-16
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch LH or RH.
3. Check continuity between rear power window switch LH or RHconnector D203 (LH), D303 (RH) terminals 1, 7 and ground.
OK or NG
OK >> GO TO 3
NG >> Repair or replace harness.
3. CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Refer to PWC-16, "
REAR POWER WINDOW SWITCH : Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace rear power window switch. Refer to PWC-117, "
Removal and Installation".
REAR POWER WINDOW SWITCH : Component InspectionINFOID:0000000001735660
COMPONENT INSPECTION
1.CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Is the inspection result normal?
YES >> Rear power window switch is OK.
NO >> Replace rear power window switch. Refer to PWC-117, "
Removal and Installation".
1 - Ground : Continuity should exist.
7 - Ground : Continuity should exist.
LIIA2044E
Terminal Power window switch condition Continuity
25 UP
Ye s
14
14
NEUTRAL
15
24 DOWN
15
ALKIA0289ZZ
Revision: March 2010 2008 QX56

POWER WINDOW MOTORPWC-17
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW MOTOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001735661
Door glass moves UP/DOWN by receiving the signal from power window main switch.
DRIVER SIDE : Componen t Function CheckINFOID:0000000001735662
1. CHECK POWER WINDOW MOTOR CIRCUIT
Does front power window motor LH operate with operating main power window and door lock/unlock switch?
Is the inspection result normal?
YES >> Front power window motor LH is OK.
NO >> Refer to PWC-17, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diag nosis ProcedureINFOID:0000000001735663
Front Power Window Motor LH Circuit Check
1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL
1. Disconnect front power window motor LH.
2. Turn ignition switch ON.
3. Check voltage between front power window motor LH connector and ground.
Is the measurement value within the specification?
YES >> GO TO 2
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-115, "
Removal and
Installation".
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch and front power window motor LH.
3. Check continuity between main power window and door lock/ unlock switch connector (A) and front power window motor con-
nector LH (B).
4. Check continuity between main power window and door lock/unlock switch connector (A) and ground.
Te r m i n a l Main power win-
dow and door lock/ unlock switch con- dition Voltage (V)
(Approx.)
(+)
(–)
Power window
motor LH con-
nector Te r m i n a l
D9 2
Ground UP Battery voltage
DOWN 0
1 UP
0
DOWN Battery voltage
ALKIA1302ZZ
Main power window
and door lock/unlock switch connector Te r m i n a lFront power win-
dow motor LH con- nector Terminal Continuity
D7 (A) 8
D9 (B) 2
Ye s
11 1
ALKIA1019ZZ
Revision: March 2010 2008 QX56

POWER WINDOW MOTORPWC-19
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
1. Disconnect front power window motor RH.
2. Turn ignition switch ON.
3. Check voltage between front power window motor RH connector and ground.
Is the measurement value within the specification?
YES >> GO TO 2
NO >> Replace power window and door lock/unlock switch RH. Refer to PWC-116, "
Removal and Instal-
lation".
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between power window and door lock/unlock switch RH connector (A) and front power window motor RH con-
nector (B).
4. Check continuity between power window and door lock/unlock switch RH connector (A) and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK FRONT POWER WINDOW MOTOR RH
Check front power window motor RH.
Refer to PWC-19, "
PASSENGER SIDE : Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace front power window motor RH. Refer to GW-9, "
Removal and Installation".
PASSENGER SIDE : Component InspectionINFOID:0000000001735668
COMPONENT INSPECTION
1. CHECK FRONT POWER WINDOW MOTOR RH
Does motor operate by connecting the battery voltage directly to front power window motor RH?
Te r m i n a l Front power
window motor RH condition Voltage (V)
(Approx.)
(+)
(–)
Front power window
motor RH connector Te r m i n a l
D104 2
Ground UP Battery voltage
DOWN 0
1 UP
0
DOWN Battery voltage
ALKIA1302ZZ
Power window and door lock/unlock
switch RH connector Te r m i n a l
Front power window
motor RH connector
Terminal Continuity
D105 (A) 8
D104 (B) 2
Ye s
91
Power window and door
lock/unlock switch RH con- nector Terminal
Ground Continuity
D105 (A) 8
No
9
ALKIA1020ZZ
Revision: March 2010 2008 QX56

PWC-20
< COMPONENT DIAGNOSIS >
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Front power window motor RH is OK.
NO >> Replace front power window motor RH. Refer to GW-9, "
Removal and Installation".
REAR LH
REAR LH : DescriptionINFOID:0000000001735669
Door glass moves UP/DOWN by receiving the signal from power window main switch or rear power window
switch LH.
REAR LH : Componen t Function CheckINFOID:0000000001735670
1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT
Does rear power window motor LH operate with main power window and door lock/unlock switch or rear
power window switch LH?
Is the inspection result normal?
YES >> Rear power window motor LH is OK.
NO >> Refer to PWC-20, "
REAR LH : Diagnosis Procedure"
REAR LH : Diagnosis ProcedureINFOID:0000000001735671
Power Window Motor Circuit Check
1. CHECK REAR POWER WINDOW SWITCH LH OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between rear power window switch LH connector D203 terminals 4, 5 and ground.
OK or NG
OK >> Replace rear power window switch LH. Refer to PWC-117, "Removal and Installation".
NG >> GO TO 2
2. CHECK REAR POWER WINDOW SWITCH LH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch LH and rear power win- dow control unit LH.
3. Check continuity between rear power window switch LH connec- tor D203 terminals 4, 5 and rear power window control unit LH
connector D209 terminals 9, 10.
OK or NG
Te r m i n a l Motor condition
(+) (–)
12 D OW N
21 U P
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
D203 4
Ground Closing
0
Opening Battery voltage
5 Closing Battery voltage
Opening 0
LIIA2365E
4 - 9 : Continuity should exist.
5 - 10 : Continuity should exist.
LIIA1379E
Revision: March 2010 2008 QX56

POWER WINDOW MOTORPWC-21
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
OK >> GO TO 3
NG >> Repair or replace harness.
3. CHECK REAR POWER WINDOW MOTOR LH
Check rear power window motor LH.
Refer to PWC-21, "
REAR LH : Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace rear power window motor LH. Refer to GW-13, "
Removal and Installation".
REAR LH : Component InspectionINFOID:0000000001735672
COMPONENT INSPECTION
1. CHECK REAR POWER WINDOW MOTOR LH
Does motor operate by connecting the battery voltage directly to rear power window motor LH?
Is the inspection result normal?
YES >> Rear power window motor LH is OK.
NO >> Replace rear power window motor LH. Refer to GW-13, "
Removal and Installation".
REAR RH
REAR RH : DescriptionINFOID:0000000001735673
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
rear power window switch RH.
REAR RH : Component Function CheckINFOID:0000000001735674
1. CHECK REAR POWER WINDOW MOTOR RH CIRCUIT
Does rear power window motor RH operate with operat ing main power window and door lock/unlock switch or
rear power window switch RH?
Is the inspection result normal?
YES >> Rear power window motor RH is OK.
NO >> Refer to PWC-21, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000001735675
Rear Power Window Mo tor RH Circuit Check
1. CHECK REAR POWER WINDOW SWITCH RH OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between rear power window switch RH connector D303 terminals 4, 5 and ground.
Te r m i n a l Motor condition
(+) (–)
21 D OW N
12 U P
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
D303 4
Ground Closing
0
Opening Battery voltage
5 Closing Battery voltage
Opening 0
LIIA2365E
Revision: March 2010 2008 QX56

PWC-22
< COMPONENT DIAGNOSIS >
POWER WINDOW MOTOR
OK or NG
OK >> Replace rear power window switch RH. Refer to PWC-117, "Removal and Installation".
NG >> GO TO 2
2. CHECK REAR POWER WINDOW SWITCH RH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch RH and rear power win- dow control unit RH.
3. Check continuity between rear power window switch RH con- nector D303 terminals 4, 5 and rear power window control unit
RH connector D309 terminals 9, 10.
OK or NG
OK >> GO TO 3
NG >> Repair or replace harness.
3. CHECK REAR POWER WINDOW MOTOR RH
Check rear power window motor RH.
Refer to PWC-22, "
REAR RH : Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace rear power window motor RH. Refer to GW-13, "
Removal and Installation".
REAR RH : Component InspectionINFOID:0000000001735676
COMPONENT INSPECTION
1. CHECK REAR POWER WINDOW MOTOR RH
Does motor operate by connecting the battery voltage directly to rear power window motor RH?
Is the inspection result normal?
YES >> Rear power window motor RH is OK.
NO >> Replace rear power window motor RH. Refer to GW-13, "
Removal and Installation".
4 - 9
: Continuity should exist.
5 - 10 : Continuity should exist.
LIIA1379E
Te r m i n a l
Motor condition
(+) (–)
21 D OW N
12 U P
Revision: March 2010 2008 QX56

PWC-24
< COMPONENT DIAGNOSIS >
ENCODER
1. Turn ignition switch ON.
2. Check voltage between front power window motor LH connectorand ground.
Is the measurement value within the specification?
YES >> GO TO 4
NO >> GO TO 3
3. CHECK HARNESS CONTINUITY 1
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch and front power window motor LH.
3. Check continuity between main power window and door lock/ unlock switch connector (A) and front power window motor LH
connector (B).
4. Check continuity between main power window and door lock/unlock switch connector (A) and ground.
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to PWC-115, "Removal and
Installation".
NO >> Repair or replace harness.
4. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor LH.
3. Check continuity between front power window motor LH connec- tor and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 5
5. CHECK HARNESS CONTINUITY 2
Te r m i n a l Voltage (V)(Approx.)
(+)
(–)
Front power win-
dow motor LH con- nector Te r m i n a l
D9 4Ground 10
WIIA0513E
Main power window
and door lock/unlock switch connector Te r m i n a l
Front power window
motor LH connector Terminal Continuity
D7 (A) 15 D9 (B) 4 Yes
Main power window and door lock/unlock switch connector Te r m i n a l
Ground Continuity
D7 (A) 15 No
ALKIA1021ZZ
Front power window motor
LH connector Terminal
Ground Continuity
D9 6 Yes
LIIA0923E
Revision: March 2010 2008 QX56

ENCODERPWC-27
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to PWC-116, "Removal and Instal-
lation".
NO >> Repair or replace harness.
4. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH.
3. Check continuity between front power window motor RH con- nector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 5
5. CHECK HARNESS CONTINUITY 2
1. Disconnect power window and door lock/unlock switch RH.
2. Check continuity between power window and door lock/unlock switch RH connector and front power window motor RH connec-
tor.
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to PWC-116, "
Removal and Installation".
NO >> Repair or replace harness.
6. CHECK HARNESS CONTINUITY 3
1. Disconnect power window and door lock/unlock switch RH.
2. Check continuity between power window and door lock/unlock switch RH connector (A) and front power window motor RH con-
nector (B).
3. Check continuity between power window and door lock/unlock switch RH connector (A) and ground.
Power window and door lock/
unlock switch RH connector Te r m i n a l
GroundContinuity
D105 (A) 4 No
Front power window motor RH
connector Terminal
GroundContinuity
D104 6 Yes
LIIA0923E
Power window and door
lock/unlock switch RH connector Te r m i n a l
Front power window
motor RH connector Terminal Continuity
D105 3D104 6 Yes
LIIA1264E
Power window and
door lock/unlock
switch RH connector Te r m i n a l
Front power window
motor RH connector Terminal Continuity
D105 (A) 12
D104 (B) 3
Ye s
15 5
ALKIA1024ZZ
Revision: March 2010 2008 QX56
