2008 INFINITI QX56 belt

THIRD SEATSE-63
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
7. Remove the seat hinge rear bolt (A) and seat belt buckle bolt (B) from the seat assembly.
CAUTION:
Discard the seat belt buckle bolt and use a new bolt for
installation.
8. Disconnect the seat harness.
9. Remove the seat assembly.
INSTALLATION
Installation is in the reverse order of removal.
Power seat cross beamINFOID:0000000001606224
REMOVAL
1. Remove the lower seat mount bolts.
2. Fold the seat cushion up.
3. Remove the harness connectors from the seat control unit.
4. Press the front release tab and remove the seat crontrol unit. Seat hinge rear bolt (A) : 45 N·m (4.6 Kg-m, 33 ft-lb
Seat belt buckle bolt (B) : 48 N·m (4.9 Kg-m, 35 ft-lb
LIIA2325E
ALIIA0096GB
ALIIA0097ZZ
ALIIA0098ZZ
Revision: March 2010
2008 QX56

THIRD SEATSE-67
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
RH Side SeatINFOID:0000000001606225
REMOVAL
1. Remove the storage bin. Refer to INT-19, "Removal and Installation".
2. Remove the lower base trim covers.
3. Remove front link nuts (A) and RH hinge front bolt (B).
4. Remove push pin (2) and release elastic band (3) from seat frame (1).
•⇐ : Vehicle front
5. Partially lift seatback upright, then remove seat belt buckle (2) from between hinge cover (1) and seat cushion side facing (3).
•⇐ : Vehicle front
6. Retract the seat into the cargo floor position.
7. Remove the rear bolts from the seat assembly.
8. Disconnect the seat harness.
9. Remove the seat assembly.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2326E
LHIA0105E
LHIA0106E
LIIA2327E
Revision: March 2010 2008 QX56

SE-76
< DISASSEMBLY AND ASSEMBLY >
SECOND SEAT
Second row center
WIIA1014E
1. Seatback pad2. Armrest finisher 3. Headrest
4. Seat belt retractor cover 5. Seat belt bezel 6. RH headrest guide locking
7. LH headrest guide free 8. Seatback board 9. Seat bracket cover
10. Armrest pivot bracket cover 11. Seatback frame 12. Seat cushion frame
13. Latch assembly 14. Lower rear pivot bracket support 15. Outer hinge cover
16. Center seat base assembly 17. Link and pivot bracket apron 18. Seat cushion pad
19. Seat cushion trim cover 20. Cushion stop bumper 21. Inner lever cover
Revision: March 2010 2008 QX56

SE-80
< DISASSEMBLY AND ASSEMBLY >
THIRD SEAT
1. LH third seat assembly2. Seatback assembly 3. Seatback trim cover
4. Seat cushion assembly 5. Seat cushion pad 6. Seat cushion trim cover
7. Flex mat springs 8. Flex mat 9. Front link covers
10. RH hinge cover 11. Seat cushion frame 12. LH hinge cover
13. Seatback frame assembly 14. Seatback cable assembly 15. Release handle bezel
16. Seatback board 17. Seatback pad 18. Headrest holder, locking
19. Headrest holder, free 20. Headrest 21. Seat belt buckle bolt
Revision: March 2010 2008 QX56

SE-82
< DISASSEMBLY AND ASSEMBLY >
THIRD SEAT
LH Side Seat
INFOID:0000000001606229
DISASSEMBLY AND ASSEMBLY
CAUTION:
Discard the seat belt buckle bolt and use a new bolt for installation.
Revision: March 2010 2008 QX56

SE-84
< DISASSEMBLY AND ASSEMBLY >
THIRD SEAT
CAUTION:
Discard the seat belt buckle bolt and use a new bolt for installation.
7. Seatback cushion 8. Seatback trim cover 9. Seat cushion
10. Seat cushion trim cover 11. Front link covers 12. Flex mat
13. Flex mat springs 14. Seat cushion frame assembly 15. Seat motor/hinge assembly
16. Control module/cross beam assem- bly 17. LH hinge cover
18. Side link cover
19. RH hinge cover 20. Seat belt buckle bolt
Revision: March 2010 2008 QX56

SE-86
< DISASSEMBLY AND ASSEMBLY >
THIRD SEAT
LH Side Seat
INFOID:0000000001606232
DISASSEMBLY AND ASSEMBLY
CAUTION:
Discard the seat belt buckle bolt and use a new bolt for installation.
Revision: March 2010 2008 QX56
