2008 FORD F150 Owners Manual

ENGINE DATA
Engine 4.2L V6 engine 4.6L V8 engine 5.4L V8 engine
Cubic inches 256 281 330
Required fuel87 octane 87 octane 87 octane or
Ethanol (E85)
2
Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8 1-3-7-2-6-5-4-8
Ignition system EDIS Coil on plug Coil on plug
Spark plug gap0.052–0.056 inch
(1.32–1.42mm)0.052–0.056 inch
(1.32–1.42mm)0.040–0.050 inch
(1.02–1.28mm)
1
Compression
ratio9.3:1 9.37:1 9.85:1
1The 5.4L 3V spark plug gap can’t be adjusted.
25.4L 3V FFV engines only.
Engine drivebelt routing
•4.2L V6 Engine
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
385

•4.6L V8 Engine and 5.4L V8 Engine
IDENTIFYING YOUR VEHICLE
Safety Compliance Certification Label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the structure (B-Pillar)
by the trailing edge of the driver’s
door or the edge of the driver’s
door.
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
386

Vehicle identification number (VIN)
The vehicle identification number is
located on the driver side
instrument panel.
Please note that in the graphic,
XXXX is representative of your
vehicle identification number.
The Vehicle Identification Number (VIN) contains the following
information:
1. World manufacturer identifier
2. Brake system / Gross Vehicle
Weight Rating (GVWR) / Restraint
System
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
XXXXXXXXXXXXXXXXX
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
387

TRANSMISSION/TRANSAXLE CODE DESIGNATIONS
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label. The following table tells you
which transmission or transaxle
each code represents.
Description Code
Four-speed automatic (4R75E) Q
Five-speed manual (M5R2) M
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
388

GENUINE FORD ACCESSORIES FOR YOUR VEHICLE
A wide selection of Genuine Ford Accessories are available for your
vehicle through your local Ford or Ford of Canada dealer. These quality
accessories have been specifically engineered to fulfill your automotive
needs; they are custom designed to complement the style and
aerodynamic appearance of your vehicle. In addition, each accessory is
made from high quality materials and meets or exceeds Ford’s rigorous
engineering and safety specifications. Ford Motor Company will repair or
replace any properly dealer-installed Genuine Ford Accessories found to
be defective in factory-supplied materials or workmanship during the
warranty period, as well as any component damaged by the defective
accessories. The accessories will be warranted for whichever provides
you the greatest benefit:
•12 months or 12,000 miles (20,000 km) (whichever occurs first), or
•the remainder of your new vehicle limited warranty.
Contact your dealer for details and a copy of the warranty.
The following is a list of several Genuine Ford Accessories. Not all
accessories are available for all models. For a complete listing of the
accessories that are available for your vehicle, please contact your dealer
or visit our online store at: www.fordaccessoriesstore.com.
Exterior style
Bug shields
Chrome exhaust tips
Deflectors
Running boards
Splash guards
Step bars
Tonneau covers
Wheels
Interior style
Electrochromatic compass/temperature interior mirrors
Floor mats
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Accessories
389

Lifestyle
Ash cup / smoker’s package
Bedliners and bedmats
Cargo organization and management
Towing mirrors
Trailer hitches, wiring harnesses and accessories
Peace of mind
Mobile-Ease™ hands free communication system
Remote start
Vehicle security systems
Wheel locks
For maximum vehicle performance, keep the following information in
mind when adding accessories or equipment to your vehicle:
•When adding accessories, equipment, passengers and luggage to your
vehicle, do not exceed the total weight capacity of the vehicle or of
the front or rear axle (GVWR or GAWR as indicated on the Safety
Compliance Certification label). Consult your authorized dealer for
specific weight information.
•The Federal Communications Commission (FCC) and Canadian Radio
Telecommunications Commission (CRTC) regulate the use of mobile
communications systems — such as two-way radios, telephones and
theft alarms - that are equipped with radio transmitters. Any such
equipment installed in your vehicle should comply with FCC or CRTC
regulations and should be installed only by a qualified service
technician.
•Mobile communications systems may harm the operation of your
vehicle, particularly if they are not properly designed for automotive
use.
•To avoid interference with other vehicle functions, such as anti-lock
braking systems, amateur radio users who install radios and antennas
onto their vehicle should not locate the Amateur Radio Antennas in
the area of the driver’s side hood.
•Electrical or electronic accessories or components that are added to
the vehicle by the authorized dealer or the owner may adversely affect
battery performance and durability.
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Accessories
390

A
Accessory delay ........................111
Air cleaner filter .......377–378, 380
Air conditioning ....................85, 87
Airbag supplemental
restraint system ................183–184
and child safety seats ............186
description ..............................184
disposal ....................................188
driver airbag ....................184, 187
indicator light .........................188
operation .........................184, 187
passenger airbag .............184, 187
Ambulance packages ....................7
Antifreeze
(see Engine coolant) ................351
Anti-lock brake system
(see Brakes) ..............................265
Anti-theft system ......................155
arming the system ..................156
Armrests ....................................159
Audio system
(see Radio) ................23, 27, 29, 36
Automatic transmission
driving an automatic
overdrive .................................272
fluid, adding ............................372
fluid, checking ........................372
fluid, refill capacities ..............381
fluid, specification ..................381
Auxiliary input jack (Line in) ....44
Axle
lubricant specifications ..........381
refill capacities ........................381
traction lok ..............................268B
Battery .......................................349
acid, treating emergencies .....349
jumping a disabled battery ....315
maintenance-free ....................349
replacement, specifications ...380
servicing ..................................349
Belt-Minder.............................178
deactivating/activating the
Belt-Minder...........................181
Booster seats .............................193
Brakes ........................................264
anti-lock ...................................265
anti-lock brake system (ABS)
warning light ...........................265
fluid, checking and adding ....371
fluid, refill capacities ..............381
fluid, specifications .................381
lubricant specifications ..........381
parking ....................................266
shift interlock ..................269–270
Bulbs ............................................97
C
Capacities for refilling fluids ....381
Cargo cage .................................136
Cargo management system ......137
Cell phone use ..............................8
Changing a tire .........................307
Child safety restraints ..............192
child safety belts ....................192
Child safety seats ......................196
attaching with tether
straps .......................................203
in front seat ....................197, 200
in rear seat ..............197, 200, 203
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Index
391

Child safety seats - booster
seats ...........................................193
Cleaning your vehicle
engine compartment ..............331
instrument panel ............333–334
interior .....................................335
plastic parts ............................332
safety belts ..............................335
washing ....................................329
waxing .....................................330
wheels ......................................330
wiper blades ............................333
Climate control (see
Air conditioning or
Heating) ...........................81, 85, 87
Clock adjust
6-CD in dash .............................38
AM/FM Stereo ...........................28
AM/FM/CD .................................31
Clutch
fluid ..........................................371
operation while driving ..........275
recommended shift speeds ....276
Compass, electronic ..........123, 125
calibration ...............................125
set zone adjustment .......125–126
Console ......................................104
overhead ..........................104–105
Controls
power seat ...............................160
steering column ......................117
Coolant
checking and adding ..............351
refill capacities ................355, 381
specifications ..........................381
Cruise control
(see Speed control) ..................115
Customer Assistance ................296Ford Extended Service
Plan ..........................................325
Getting assistance outside
the U.S. and Canada ..............326
Getting roadside assistance ...296
Getting the service
you need .................................321
Ordering additional
owner’s literature ...................327
Utilizing the Mediation/
Arbitration Program ...............325
D
Daytime running lamps
(see Lamps) ................................92
Dipstick
automatic transmission
fluid ..........................................372
engine oil .................................345
Driveline universal joint
and slip yoke .............................377
Driving under special
conditions ..................275, 287, 290
sand .........................................289
snow and ice ...........................291
through water .................289, 292
DVD system .................................51
E
Electronic message center .......125
Emergencies, roadside
jump-starting ..........................315
Emergency Flashers .................298
Emission control system ..........368
Engine ........................................385
cleaning ...................................331
coolant .....................................351
fail-safe cooling .......................356
2008 F-150(f12)
Owners Guide (post-2002-fmt)
USA(fus)
Index
392
