2008 FIAT SEDICI oil capacities

193
Refill with Oil and Check for Leaks
❒Pour oil through the filler hole and in-
stall the filler cap.
For the approximate capacity of the oil,
refer to the “Capacities” item in the
“SPECIFICATIONS” section.
❒Start the engine and look carefully for
leaks at the oil filter and drain plug. Run
the engine at various speeds for at least
5 minutes.
❒Stop the engine and wait about 5 min-
utes. Check the oil level again and add
oil if necessary. Check for leaks again.
IMPORTANT
❒When replacing the oil filter, it is rec-
ommended that you use a genuine
Fiat replacement filter. If you use an af-
termarket filter, make sure it is of
equivalent quality and follow the man-
ufacturer’s instructions.
❒Oil leaks from around the oil filter or
drain plug indicate incorrect installation
or gasket damage. If you find any leaks
or are not sure that the filter has been
properly tightened, have the vehicle in-
spected by your Fiat Dealership.Transfer oil (4WD)
Rear differential oil (4WD)
(API GL-5 Hypoid)
GEAR OIL
MANUAL TRANSAXLE OIL/
TRANSFER OIL (4WD)/
REAR DIFFERENTIAL OIL (4WD)
When adding gear oil, use gear oil with the
appropriate viscosity and grade as shown
in the chart below.
We highly recommend you use:
TUTELA XVI SAE 75W-90, API GL3,
FIAT 9.55550-MZ4 Contractual Technical
Reference N° F808.G08, for manual
transaxle gear oil.
Hypoid gear oil TUTELA W90/M -DA SAE
80W-90
API GL 5for transfer oil and rear
differential oil (4WD).
54G095
54G096
Manual transaxle oil (API GL-4)
181-224 Fiat16 New GB 3-09-2008 8:17 Pagina 193

248
2WD
4WD
2WD
4WD
2WD
4WD
2WD
4WD1,135 – 1,185 (2,502 – 2,612)
1,195 – 1,245 (2,634 – 2,745)
1,650 (3,638)
1,670 (3,682)
865 (1,907)
870 (1,918)
850 (1,874)
870 (1,918)1,270 – 1,320 (2,800 – 2,910)
1,330 – 1,380 (2,932 – 3,042)
1,790 (3,946)
1,790 (3,946)
980 (2,160)
980 (2,160)
860 (1,896)
860 (1,896)
WEIGHTS kg (lbs) 1.6 16V1.9 Multijet
Kerb weight (including fuel, spare wheel,
tools and accessories)
Gross vehicle weight (GVWR)
Gross front axle weight (GAWR)
Gross rear axle weight (GAWR)
PERFORMANCE 1.6 16V1.9 Multijet
Top admitted speed after initial vehicle use
Pick-up angle
Racing angle
Rise angle170 km/h
20.3°
31.1°
18.1°180 km/h
20.3°
31.1°
18.1°
2WD
4WD
4WD
4WD7.7 litres (13.6 Imp pt)
50 litres (11.0 Imp gal)
3.9 litres (6.9 Imp pt)
(replacement with oil filter)
2.5 litres (4.4 Imp pt)
2.5 litres (4.4 Imp pt)
0.6 litres (1.1 Imp pt)
0.8 litres (1.4 Imp pt)6.5 litres (11.4 Imp pt)
50 litres (11.0 Imp gal)
4.5 litres (7.9 Imp pt)
(replacement with oil filter)
2.5 litres (4.4 Imp pt)
2.5 litres (4.4 Imp pt)
0.6 litres (1.1 Imp pt)
0.8 litres (1.4 Imp pt)
CAPACITIES (indicative values) 1.6 16V1.9 Multijet
Engine cooling system
(including reservoir tank)
Fuel tank
Engine oil
Gearbox oil
Transfer oil
Rear differential oil
243-248 Fiat16 New GB 3-09-2008 8:42 Pagina 248

257
Battery .......................................210-245
Before driving.................................. 9
Bodywork care................................ 233
Brake fluid ............................................ 202
Brake system ....................................... 159
Brakes
– Brake fluid ..................................... 202
– Brake pedal .............................131-203
– Brake system ................................ 246
– Parking brake lever ...............130-204
– Vacuum brake ............................... 160
Bulbs
– Replacement ................................. 217
– Type ................................................ 245
Can holder .......................................... 142
Capacities ......................................10-248
Catalytic converter ............................ 165
Child-proof locks ................................ 22
Children
– Child-proof locks ......................... 22
– Child restraint systems ............... 37
– Installation with Isofix
type anchorages ........................... 42
– Installation with lap-shoulder
seat belts ........................................ 42
Cigar lighter ......................................... 90Clock ..................................................... 98
Clutch .............................................131-205
CO
2emissions .................................... 241
Cup holder ........................................... 142
Daily inspection checklist ................ 150
Dimensions .......................................... 247
Dipped beam headlights .................... 63
– Bulb replacement ......................... 219
Doors
– Central door locking
system ........................................13-19
– Child-proof locks ......................... 22
– Dead lock ...................................... 14
– Keyless Start ................................. 15
– Opening/closing ............................ 12
Drive belt (servicing) ......................... 189
Driving tips....................................... 167
– Driving on hills ............................. 168
– Driving on slippery roads ........... 169
– Highway driving ............................ 168
Emergency service....................... 225
Engine
– Air cleaner ..................................... 198
– Engine coolant .............................. 195
– Engine oil and filter ...................... 189
– If the engine is flooded ............... 230
ABS ...................................................... 160
Air bags ................................................. 47
– Front ............................................... 48
– How the system works .............. 52
– Servicing ......................................... 54
– Side ................................................. 50
Air cleaner ........................................... 198
Air conditioning ...........................99-224
Ashtray ................................................. 90
Assist grips ........................................... 140
Audio systems
– Antenna ...................................112-147
– Anti-theft system ......................... 121
– Cautions on handling .................. 110
– CD Changer ................................. 118
– CD player ...................................... 116
– Error display messages ............... 125
– General .......................................... 112
– Radio .............................................. 113
– RDS (Radio Data System) .......... 115
– Steering wheel controls ............. 126
– System ............................................ 109
– Troubleshooting .......................... 123
Automatic heating and air
conditioning system ......................... 104
– Maintenance ...........................109-224
I I
N N
D D
E E
X X
14
257-264 Fiat16 New GB 3-09-2008 8:25 Pagina 257

258
– Fuel filter........................................... 201
– Fuel filler cap ................................... 132
– Fuel gauge ........................................ 84
– Improving fuel economy .............. 166
– Instantaneous fuel
consumption (gauge) ......................... 92
Fuel filler cap .......................................... 132
Fuel gauge ............................................... 84
Fuses ........................................................ 212
Gear oil
– Changing .................................193-248
– Level check .................................... 194
– Specifications.................................. 193
General information.................... 239
Glove box ............................................ 91
Hazard warning lights ....................... 85
Hazard warning lights ........................ 85
Head restraints ................................... 30
Headlight levelling switch .................. 87
Headlights
– Bulb replacement ......................... 220
– Headlight levelling switch ........... 87
Heated rear window .......................... 88
Heating and air conditioning
system .........................................99-224
Heating system .............................99-104
Horn ...................................................... 68
Identification data .............................. 230
Ignition switch ..................................... 58
Information display ......................91-94
– Illumination cancel switch .......... 89
Inspection and maintenance.... 181
– Maintenance schedule ................. 183
– Severe driving conditions ........... 188
Instrument cluster .............................. 71
– Meter illumination
(control) ..................................82-87
Instrument panel........................... 69
Interior lights ................................138-219
Isofix type child restraint system
(installation)........................................ 42
Jack ......................................................... 144
Jacking instructions.............................. 226
Jump starting instructions.................. 227
Keys ....................................................... 11
– Battery replacement..................... 20
– Keyless Entry................................. 18
Luggage compartment
– Capacity/volume .......................... 247
– Extension (folding rear seats)..... 134
– Luggage compartment cover ..... 146
– Luggage compartment light ....... 146
– Luggage restraint loops .............. 145
– Rear door opening ...................... 23
Luggage compartment light .............. 146 – If the engine overheats ............... 230
– If the starter does not operate .. 229
– Jump starting ................................. 227
– Serial number ............................... 240
– Spark plugs .................................... 199
– Starting ........................................... 165
– Technical specifications .............. 244
– Temperature gauge ..................... 84
Engine coolant ..................................... 195
Engine coolant temperature gauge .. 84
Engine hood ......................................... 140
Engine oil consumption ..................... 152
Engine oil
– Changing .................................191-248
– Level check .................................... 190
– Specifications ................................ 189
Engine oil filter (change) .................... 191
ESP (Electronic Stability Program) ... 161
Exhaust gas ........................................... 150
External lights ...............................63-219
Eyeglasses holder ................................ 142
Fiat CODE (Immobilizer system) .... 11
Frame hooks .......................................... 143
Front fog lights ....................................... 89
Fuel
– Capacities/refuelling ...............10-248
– Consumption .................................. 241
257-264 Fiat16 New GB 3-09-2008 8:25 Pagina 258

259
– Switch ............................................. 66
Rear window wiper
– Blades.............................................. 223
– Control .......................................... 66
Recirculated air.............................102-105
Refuelling/Capacities.....................10-248
Roof rails or roof rack anchors ....... 147
Running-in ............................................ 165
Seat back pocket................................ 145
Seat belts
– Height adjuster ............................. 36
– Pretensioners ............................... 45
– Seat belt hangers .......................... 36
– Seat belt inspection ..................... 37
– Seat belt reminder (S.B.R.) ........ 35
– Use .................................................. 33
– Warnings ....................................... 31
Seats
– Folding rear seats ......................... 145
– Front (adjustment) ...................... 29
– Front seat heater ......................... 139
– Seat back pocket .......................... 145
Service station guide .......................... 3
Snow chains ......................................... 169
Spare tire .......................................144-208
Spark plugs ....................................199-245
Speedometer........................................ 81
Spot light................................................ 138Starting the engine............................... 152
Steering...........................................204-246
Steering column controls.......... 57
Steering wheel
– Adjustment .............................67-204
– Audio controls........................68-126
Sun visors ............................................. 137
Supplement...................................... 249
Suspensions .......................................... 246
Symbols ................................................. 4
Tachometer ........................................ 83
Tailgate .................................................. 23
Technical specifications.............. 243
Theft deterrent light .......................... 93
Thermometer ...................................... 92
Tools ..................................................... 144
Towing the vehicle
– Frame hooks ................................. 135
– Instructions ............................177-229
Trailer towing ...................................... 172
Trailer hitch ......................................... 172
Transaxle
– Gear oil .......................................... 194
– Gear oil change .....................194-248
– Gearshift lever .............................. 132
– Using the transaxle ...................... 156
Transmission ........................................ 246
Trip meter ........................................... 81 Luggage restraint loops ..................... 145
Main beam headlights........................ 63
– Bulb replacement ......................... 220
Manual heating and air
conditioning system.......................... 100
– Maintenance............................104-224
Mirrors
– Defroster ....................................... 88
– Electric mirrors ............................ 28
– Inside rearview mirror ............... 27
– Outside rearview mirror ........... 27
MP3/WMA Player................................ 120
Odometer ........................................... 81
– Illumination cancel switch .......... 89
Operating your vehicle............... 149
Original spare parts ........................... 2
Other controls
and equipment............................. 129
Parking brake lever ........................... 130
Parking lights ........................................ 63
Pedals .................................................... 131
Performance ........................................ 248
Pretensioners for seat belts ............. 45
Radio antenna...............................112-147
Rear door.............................................. 23
Rear fog light......................................... 64
Rear window washer
257-264 Fiat16 New GB 3-09-2008 8:25 Pagina 259
