SUSPENSIONS
1.2 1.4 - 1.4 16V- 1.4 T-JET - 1.3 Multijet - 1.6 Multijet
Front
Rear twisting axle with interconnected wheels
BRAKES
1.2 1.4 - 1.4 16V- 1.4 T-JET1.3 Multijet 1.6 Multijet
Service brakes:
– front
– rear
Parking brake
IMPORTANT Water, ice and antifreeze salt on roads may deposit on the brake discs thus reducing braking efficiency
at first braking.
independent, Mc Pherson
type with anti-roll bar
rack and pinion with electric power steeringcontrolled by hand lever, it works on rear brakesdrum or disc (where provided) disc (self-ventilating for versions where provided)
STEERING
1.2 1.4 1.4 16V1.3 Multijet 1.3 Multijet 1.6 Multijet1.4 T-JET 75HP 90HP 120HP
Type
Minimum steering
cycle m 10,9Mc Pherson independent wheels
209-229 Punto GDX GB 6-08-2008 10:11 Pagina 216

217
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
UNDERSTANDING TYRE
MARKING fig. 4
Example: 175/65 R 15 84T
175 = Nominal width (S, distance be-
tween sidewalls in mm).
65 = Percentage height/width ratio
(H/ S).
R = Radial tyre.
15 = Rim diameter in inches (Ø).
84 = Load rating (capacity).
T = Maximum speed rating.
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims. Tubeless tyres
with radial carcass. The homologated tyres
are listed in the Log book.
IMPORTANT In the event of discrepan-
cies between the information provided on
this “Owner handbook” and the “Log
book”, consider the specifications shown
in the log book only.
Attaining to the prescribed size, to ensure
safety of the car in movement, it must be
fitted with tyres of the same make and
type on all wheels.
IMPORTANT Do not use inner tubes
with Tubeless tyres.
fig. 4F0M0169m
SPARE WHEEL
Pressed steel rim. Tubeless tyre.
WHEEL GEOMETRY
Front wheel toe-in: 1 ± 1 mm
Rear wheel toe-in: 1.7 ± 2 mm
The values refer to the car in running or-
der.
209-229 Punto GDX GB 6-08-2008 10:11 Pagina 217

UNDERSTANDING RIM
MARKING fig. 4
Example: 6J x 15 ET43
6 = rim width in inches 1.
J = rim drop centre outline (side
projection where the tyre bead
rests) 2.
15 = rim nominal diameter in inches
(corresponds to diameter of the
tyre to be mounted) 3= Ø.
ET43 = wheel camber angle (distance be-
tween the disc/rim supporting
plane and the wheel rim centre
line). Load rating (capacity)
70= 335 kg 81= 462 kg
71= 345 kg 82= 475 kg
72= 355 kg 83= 487 kg
73= 365 kg 84= 500 kg
74= 375 kg 85= 515 kg
75= 387 kg 86= 530 kg
76= 400 kg 87= 545 kg
77= 412 kg 88= 560 kg
78= 425 kg 89= 580 kg
79= 437 kg 90= 600 kg
80= 450 kg 91= 615 kg
218
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
Maximum speed rating
Q = up to 160 km/h.
R = up to 170 km/h.
S = up to 180 km/h.
T = up to 190 km/h.
U = up to 200 km/h.
H = up to 210 km/h.
V = up to 240 km/h.
Maximum speed rating
for snow tyres
QM + S= up to 160 km/h.
TM + S= up to 190 km/h.
HM + S= up to 210 km/h.
209-229 Punto GDX GB 6-08-2008 10:11 Pagina 218

219
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
175/65 R15 84T (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
175/65 R15 84T (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
175/65 R15 84T (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
185/65 R15 88T (M+S)
195/55 R16 87H (M+S)
185/65 R15 88H (M+S)
195/55 R16 87H (M+S) 175/65 R15 84T
185/65 R15 88T
195/55 R16 87H
175/65 R15 84T
185/65 R15 88T
195/55 R16 87H
185/65 R15 88T
195/55 R16 87H
205/45 R17 88V
185/65 R15 88H
195/55 R16 87H
205/45 R17 88V
175/65 R15 84T
185/65 R15 88T
195/55 R16 87H
205/45 R17 88V
185/65 R15 88T
195/55 R16 87H
205/45 R17 88V
185/65 R15 88H
195/55 R16 87H
205/45 R17 88V6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 15'' - ET 43175/65 R15 84T
185/65 R15 88T
175/65 R15 84T
185/65 R15 88T
185/65 R15 88T
185/65 R15 88H
175/65 R15 84T
185/65 R15 88T
185/65 R15 88
185/65 R15 88H 6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 16'' - ET 45
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 16'' - ET 45
6J X 15'' - ET 43
6J X 16'' - ET 45
6,5J X 17'' - ET 46
6J X 15'' - ET 43
6J X 16'' - ET 45
6,5J X 17'' - ET 46
6J X 15'' - ET 43
6J X 15'' - ET 43
6J X 16'' - ET 45
6J X 17'' - ET 46
6J X 15'' - ET 43
6J X 16'' - ET 45
6,5J X 17'' - ET 46
6J X 15'' - ET 43
6J X 16'' - ET 45
6,5J X 17'' - ET 46
Version Rims (*) Tyres Spare wheel (ç)Standard tyre Snow tyre Rim (*) Tyre
1.2
1.4
1.4 16V
1.4 T-JET
1.3 Multijet 75 HP
1.3 Multijet 90 HP
1.6 Multijet 120 HP
(*) Spacing of studs 100 mm and studs M12 x 1.5 use only wheels specified for this car.
(ç) Depending on the trim level, the spare wheel has a 175/65 R15 84T tyre and a 6Jx15”- ET43 rim. In that case the 175/65
R15 84T has the same specifications as the spare wheel: the text and the warnings in the “Chaging a wheel” paragraph there-
fore refer to the 175/65 R15 84T tyre.
