N A/C Air Filter Ð If Equipped ............383
N Power Steering .......................385
N Front Suspension .....................385
N Steering Linkage ......................386
N Body Lubrication .....................386
N Windshield Wiper Blades ................386
N Windshield Washers ...................387
N Exhaust System ......................387
N Cooling System .......................388
N Hoses And Vacuum/Vapor Harnesses .......394
N Fuel System .........................394
N Brake System ........................394
N Automatic Transaxle ...................397 N Front And Rear Wheel Bearings ...........400
N Appearance Care And Protection From
Corrosion ...........................400
N Cleaning Center Console Cupholders .......405
m Fuses Ð Totally Integrated Power Module
(TIPM) ..............................406
m Vehicle Storage ........................411
m Replacement Bulbs ......................411
m Bulb Replacement ......................412
N Headlight Bulb Replacement .............412
N Fog Lights ..........................415
N Taillights, Rear Turn Signals And Backup Lights Ð
Replacement .........................416
N License Plate Light Ð Rear ..............418366 MAINTAINING YOUR VEHICLE

NOTE: For lighted switches, see your authorized dealer
for replacement instructions.
LIGHTS BULBS Ð Outside Bulb No.
Low Beam Headlight ..................... 9006
High Beam Headlight ..................... 9005
Front Park/Turn Signal/Side Marker Light . . . 3157AK
Front Fog Light ..................... 9145//H10
Center High Mounted Stop Light
(CHMSL) ........................ W16W (921)
Rear Tail/Stop ......................... 3157K
Decklid Tail Light ....................... T3.25
Rear Turn Signal ...................... 3157AK
Backup Light .......................... 3157K
License Light ........................... 168 BULB REPLACEMENT
Headlight Bulb Replacement
1. Raise the hood and locate the connector behind the
headlamp.
Headlight412 MAINTAINING YOUR VEHICLE

Fog Lights
1. Access to the lights through the lower fascia cutout is
limited.
2. We recommend you access the lights by turning the
steering wheel to allow access and remove the inner
fender shield. 3. Rotate bulb and connector 1
¤ 4
turn counterclockwise.
4. Pull bulb off of connector and replace with a new one.
CAUTION!Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Fog Light and Connector MAINTAINING YOUR VEHICLE 415
7

Engine Oil ........................... 326
Fuel Requirements .................. 324,326
Maintenance ....................... 324,327
Replacement Parts ..................... 327
Starting ............................. 327
Flooded Engine Starting ................... 263
Floor Console .......................... 156
Fluid Capacities ......................... 420
Fluid Leaks ............................. 80
Fluid Level Checks
Automatic Transaxle ................. 397,398
Brake ............................ 396,424
Cooling System ....................... 389
Engine Oil ........................... 374
Power Steering ..................... 385,424
Fluids ................................ 422
Fluids, Lubricants and Genuine Parts .......... 422
Fog Lights ....................... 132,176,415
Folding Rear Seat ..................... 126,127 Freeing A Stuck Vehicle ................... 361
Front Wheel Bearings ..................... 400
Fuel ................................. 319
Adding ............................. 328
Additives ............................ 322
Clean Air ............................ 320
Ethanol ............................. 321
Filler Cap (Gas Cap) ................. 170,328
Filler Door (Gas Cap) ................... 170
Gasoline ............................ 319
Gauge .............................. 170
Hoses .............................. 394
Light ............................... 171
Materials Added ....................... 322
Methanol ............................ 321
Octane Rating ...................... 319,422
Requirements ...................... 319,420
Tank Capacity ........................ 420
Fuel, Flexible ............. See Flexible Fuel Vehicles450 INDEX

Keyless Entry System (Sedan) ................ 21
Keys ................................. 12
Knee Bolster .......................... 51,53
Lane Change and Turn Signals ........... 176,416
Lap/Shoulder Belts ....................... 42
LATCH (Lower Anchors and Tether for CHildren) .. 73
Latches
Hood ............................... 127
Lead Free Gasoline ...................... 319
Life of Tires ............................ 306
Light Bulbs ............................ 411
Lights .............................. 80,129
Airbag ........................ 52,65,79,171
Back-Up ............................. 416
Brake Warning ........................ 179
Bulb Replacement ...................... 412
Center Mounted Stop ................... 418
Daytime Running ...................... 132 Dimmer Switch, Headlight ............... 130
Electronic Stability Program (ESP) Indicator . . . 284
Engine Temperature Warning .............. 172
Fog .......................... 132,176,415
Headlight Switch ...................... 130
Headlights ........................... 130
Headlights On With Wipers ............... 137
High Beam Indicator .................... 179
Illuminated Entry ....................... 20
Instrument Cluster ..................... 130
Interior ............................. 129
License ............................. 418
Lights On Reminder .................... 132
Low Fuel ............................ 171
Malfunction Indicator (Check Engine) ........ 178
Map Reading ......................... 129
Oil Pressure .......................... 171
Passing ............................. 131
Seat Belt Reminder ..................... 171 INDEX 453
