2008 CADILLAC ESCALADE ESV Owners Manual

A. Air Outlets. See Outlet Adjustment on page 3-31 .
B. Turn Signal/Multifunction Lever. See Turn
Signal/Multifunction Lever on page 3-7 .
C. Instrument Panel Cluster. See Instrument Panel
Cluster on page 3-34 .
D. Hazard Warning Flasher Button. See Hazard
Warning Flashers on page 3-6 .
E. Shift Lever and Range Selection Mode. See
Automatic Transmission Operation on page 2-30 .
F. Tow/Haul Selector Button. See Tow/Haul Mode
on page 2-34 .
G. Driver Information Center Controls. See Driver
Information Center (DIC) on page 3-48 .
H. Analog Clock. See Analog Clock on page 3-25 .
I. Audio System. See Audio System(s) on page 3-70 .
J. StabiliTrak ®
Button. See StabiliTrak ®
System on
page 4-6 . Rear Park Aid Disable Button. See
Ultrasonic Rear Parking Assist (URPA) on
page 2-48 .
K. Tilt Wheel Lever. See Tilt Wheel on page 3-6 . L. Exterior Lamps Control. See Exterior Lamps on
page 3-16 .
M. Dome Lamp Override Button. See Dome Lamp
Override on page 3-22 . Instrument Panel Brightness
Control. See Instrument Panel Brightness on
page 3-21 . Fog Lamp Button. See Fog Lamps on
page 3-21 .
N. Cruise Control Buttons. See Cruise Control on
page 3-13 .
O. Horn. See Horn on page 3-6 .
P. Audio Steering Wheel Controls. See Audio Steering
Wheel Controls on page 3-106 .
Q. Dual Automatic Climate Controls. See Dual
Automatic Climate Control System on page 3-26 .
R. Pedal Adjust Button. See Adjustable Throttle
and Brake Pedal on page 2-28 . Heated Windshield
Washer Fluid Button. See Windshield Washer
on page 3-11 . Power Running Boards Disable Button
(If Equipped). See Power Running Boards on
page 2-17 .
S. Glove Box. See Glove Box on page 2-60 .
3-5

Hazard Warning Flashers The hazard warning ashers warn others. They also let
police know you have a problem.
The hazard warning
asher button is located on
top of the steering
column.
Press the button to make the front and rear turn signal
lamps ash on and off. Press the button again to
turn the ashers off.
The hazard warning ashers work no matter what
ignition position the key is in, and even if the key is not
in the ignition.
When the hazard warning ashers are on, your vehicle’s
turn signals will not work.
Other Warning Devices If you carry reective triangles, you can set them up at
the side of the road about 300 feet (100 m) behind
your vehicle. Horn To sound the horn, press the center pad on the steering
wheel.
Tilt Wheel Your vehicle has a tilt wheel, that lets you adjust the
steering wheel before driving. Raising it to the highest
level gives more room to exit and enter your vehicle.
The tilt steering wheel lever is located on the lower left
side of the column.
3-6

To tilt the wheel, hold the steering wheel and pull the
lever. Then move the steering wheel to a comfortable
position and release the lever to lock the wheel in place.
Heated Steering Wheel Your vehicle may have a heated steering wheel.
The button with this
symbol is located on the
left side of the steering
wheel.
Press the button to turn the heated steering wheel on or
off. A light on the button will display when the feature
is turned on.
The steering wheel will take about three minutes to start
heating. Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:

G Turn and Lane Change Signals. See Turn and
Lane-Change Signals on page 3-8 .

53 Headlamp High/Low-Beam Changer. See
Headlamp High/Low-Beam Changer on page 3-9 .

N Windshield Wipers. See Windshield Wipers on
page 3-9 .

L Windshield Washer. See Windshield Washer
on page 3-11 .
3-7

5 Rear Wiper Delay. See Rear Window
Wiper/Washer on page 3-12 .

Z Rear Wiper. See Rear Window Wiper/Washer
on page 3-12 .

= Rear Wiper Wash. See Rear Window
Wiper/Washer on page 3-12 .
Turn and Lane-Change Signals The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is nished, the lever will return
automatically.
To signal a lane change, raise or lower the lever for
less than one second until the arrow starts to ash. This
will cause the turn signals to automatically ash three
times. It will ash six times if tow-haul mode is
active. Holding the turn signal lever for more than one
second will cause the turn signals to ash until you
release the lever. The lever will return by itself when it
is released. An arrow on the instrument
panel cluster will ash in
the direction of the
turn or lane change.
As you signal a turn or a lane change, if the arrows
ash more quickly than normal, a signal bulb may
be burned out and other drivers will not see your turn
signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when you
signal a turn, check for burned-out bulbs and a blown
fuse. See Fuses and Circuit Breakers on page 5-108 .
Turn Signal On Chime If your turn signal is left on for more than 3/4 of a mile
(1.2 km), a chime will sound at each ash of the
turn signal and the message TURN SIGNAL ON will
also appear in the Driver Information Control (DIC). To
turn the chime and message off, move the turn
signal lever to the off position.
3-8

Headlamp High/Low-Beam Changer 53 (Headlamp High/Low Beam Changer): To
change the headlamps from low to high beam, push the
lever toward the instrument panel. To return to
low-beam headlamps, pull the multifunction lever toward
you. Then release it.
When the high beams are
on, this indicator light on
the instrument panel
cluster will also be on.
Windshield Wipers Clear ice and snow from the wiper blades before using
them. If they are frozen to the windshield, gently
loosen or thaw them. Damaged wiper blades may not
clear the windshield well, making it harder to see
and drive safely. If the blades do become damaged,
install new blades or blade inserts. For more information,
see Windshield Wiper Blade Replacement on page 5-54 . Heavy snow or ice can overload the wiper motor. A
circuit breaker will stop the motor until it cools down.
Clear away snow or ice to prevent an overload.
Turn the band with the wiper symbol to control the
windshield wipers.
8 (Mist): Turn the band to mist for a single wiping
cycle. Hold it there until the wipers start. Then let
go. The wipers stop after one wipe. Hold the band on
mist longer, for more wipe cycles.
9 (Off): To stop the wipers, move the band to off.
6 (Delay): Turn the band to adjust the delay time. The
delay between wiping cycles becomes shorter as
the band is moved to the top of the lever. This can be
very useful in light rain or snow.
6 (Low Speed): Turn the band away from you to
the rst solid band past the delay settings, for steady
wiping at low speed.
? (High Speed): Turn the band further, to the
second solid band past the delay settings, for
high-speed wiping.
3-9

Rainsense™ II Wipers Your vehicle has Rainsense™ II windshield wipers.
These wipers automatically turn on when a sensor,
mounted next to the inside rearview mirror, detects
moisture on the windshield. When active, these wipers
are able to detect moisture on the windshield and
automatically turn on the wipers.
To turn on the Rainsense™ feature, the wipers must be
set to one of the ve delay settings. Each of the ve
settings adjusts the sensitivity of the rain sensor.
Since different drivers have different setting preferences,
it is recommended that the mid-range setting, position
three, be used initially. For more wipes, select the higher
settings; for fewer wipes, select the lower settings located
closer to the off position on the multifunction lever. The rain sensor will automatically control the frequency
of the wipes from off to high speed according to the
weather conditions. The wipers can be left in a
Rainsense™ mode even when it is not raining.
When Rainsense™ II is active, the headlamps will turn
on automatically after approximately eight wipes.
The headlamps will turn off if the wiper switch is set to a
delay position, and there have been no wipes for
approximately three minutes, or if the wiper switch is
turned to the off position. If it is dark outside, the
headlamps will remain on.
Notice: Going through an automatic car wash with
the wipers on can damage them. Turn the wipers
off when going through an automatic car wash.
3-10

Windshield Washer
{ CAUTION: In freezing weather, do not use your washer
until the windshield is warmed. Otherwise the
washer uid can form ice on the windshield,
blocking your vision.
L (Washer Fluid): There is a paddle marked with the
windshield washer symbol at the top of the multifunction
lever. To spray washer uid on the windshield, push
the paddle. The wipers will clear the window and then
either stop or return to your preset speed. Heated Windshield Washer The heated windshield washer uid system may be
used to help clear ice, snow, tree sap, or bugs from your
windshield.
The button is located in
the switchbank under the
climate controls.
Push the heated washer uid button while the ignition is
turned on to activate the heated windshield washer
uid system. The indicator light will ash. This activation
will initiate four heated wash/wipe cycles. The rst
heated wash/wipe cycle may take up to 40 seconds to
occur, depending on outside temperature. After the
rst wash/wipe cycle, it may take up to 20 seconds for
each of the remaining cycles to begin. Press the
button again to turn off the heated windshield washer
uid system or it will automatically turn off after four
wash/wipe cycles have been completed.
When the heated windshield washer uid system is
activated under certain outside temperature conditions,
steam may ow out of the washer nozzles for a short
period of time before washer uid is sprayed. This is a
normal condition.
3-11

Rear Window Wiper/Washer
{ CAUTION: In freezing weather, do not use your washer
until the windshield is warmed. Otherwise the
washer uid can form ice on the windshield,
blocking your vision.
The rear wiper control is located on the turn
signal/multifunction lever.
To turn the rear wiper on, slide the lever to a wiper
position.
9 (Off): To turn the wiper off, slide the lever to this
setting.
5 (Rear Wiper Delay): To turn on the rear wiper
delay, slide the lever to this setting. Z (Rear Wiper): To turn on the rear wiper, slide the
lever to this setting.
= (Rear Wiper Wash): To turn on the rear wiper
wash, push the button on the end of the turn
signal/multifunction lever to spray washer uid on the
rear window. The wipers will clear the rear window and
either stop or return to your preset speed. For more
washer cycles, press and hold the button.
The rear window wiper/washer will not operate if the
liftgate or liftglass is open or ajar. If the liftgate or
liftglass is opened while the rear wiper is on, the wiper
will return to the parked position and stop.
3-12
