Page 209 of 440

REMOTE START
If your vehicle has remote start, this feature allows the
remote start to be turned off or on. The remote start
feature allows you to start the engine from outside of the
vehicle using the Remote Keyless Entry (RKE)
transmitter. SeeRemote Vehicle Start on page 2-8for
more information.
Press the option button until REMOTE START appears
on the DIC display. Press the set/reset button to
scroll through the following settings:
OFF:The remote start feature will be disabled.
ON (default):The remote start feature will be enabled.
To select a setting and move on to the next feature,
press the option button while the desired setting
is displayed on the DIC.
Personalization Menu Items
The following are personalization features that allow you
to program setting for up to two drivers:
PERSONALIZE KEY
This feature allows you to personalize a key to be
recognized as key 1 or 2. A personalized key allows you
to program personalization features to a preferred
setting to correspond to key 1 or 2. If you are using a
key that has already been personalized, this screen will
not display.
Press the option button until PERSONALIZE KEY
appears on the DIC display. Press the set/reset button
to scroll through the following settings:
NO (default):The key will not be personalized.
YES:The key will be personalized.
To select a setting and move on to the next feature,
press the option button while the desired setting
is displayed on the DIC.
3-81
Page 210 of 440

REPLACE KEY
This screen displays only if YES was selected for
the PERSONALIZE KEY feature, keys 1 and 2 have
already been personalized, and the current key being
used is not key 1 or 2. This feature allows you to program
a key to be recognized as key 1 or 2 in the event that the
previously programmed key needs to be replaced.
1:The key will be programmed to be recognized
as key 1.
2:The key will be programmed to be recognized
as key 2.
CANCEL (default):The key will not be programmed.
RADIO STATIONS PERSONALIZED
This screen displays only if YES was selected for the
PERSONALIZE KEY feature. This feature allows you to
set the radio station presets to be recognized for the
key, 1 or 2, that is being used. You may notice a change
to the radio after this message displays. After this
message displays, any change to the presets will be
recognized for key 1 or 2 and will be maintained by
the radio.
AUTO DOOR UNLOCK
This feature allows automatic door unlocking to be
turned off, used for the driver’s door only, or for all of
the doors.
Press the option button until AUTO DOOR UNLOCK
appears on the DIC display. Press the set/reset button to
scroll through the following settings:
OFF:None of the doors will unlock when the vehicle is
shifted into PARK (P) or the key is taken out of the
ignition.
DRIVER:Only the driver’s door will unlock when the
vehicle is shifted into PARK (P) or the key is taken out of
the ignition.
ALL (default):All of the doors will unlock when the
vehicle is shifted into PARK (P) or the key is taken out
of the ignition.
To select a setting and move on to the next feature,
press the option button while the desired setting
is displayed on the DIC.
3-82
Page 211 of 440

AUTO UNLOCK ON
This feature displays only if DRIVER or ALL was
selected for the AUTO DOOR UNLOCK feature. This
feature allows the selection of when the vehicle’s doors
will unlock.
Press the option button until AUTO UNLOCK ON
appears on the DIC display. Press the set/reset button
to scroll through the following settings:
KEY-OUT:The door(s) will unlock when the key is
taken out of the ignition.
PARK (default):The door(s) will unlock when the
vehicle is shifted into PARK (P).
To select a setting and move on to the next feature,
press the option button while the desired setting
is displayed on the DIC.
FOB UNLOCK ON 1ST PRESS
This feature allows the selection of which doors will
unlock on the rst press of the unlock button on
the Remote Keyless Entry (RKE) transmitter. See
Remote Keyless Entry (RKE) System Operation
on page 2-5for more information.Press the option button until FOB UNLOCK ON 1ST
PRESS appears on the DIC display. Press the set/reset
button to scroll through the following settings:
DRIVER (default):The driver’s door will unlock on the
rst press of the unlock button on the RKE transmitter.
ALL:All of the doors will unlock on the rst press of the
unlock button on the RKE transmitter.
To select a setting, press the option button while the
desired setting is displayed on the DIC. The DIC
will then display PRESS UNLOCK SWITCH ON KEY
FOB. Press the unlock button on the RKE transmitter
and the setting will be saved for that RKE transmitter.
After programming the last option, the message
PERSONAL OPTIONS SAVED appears on the DIC
display for a few seconds, then the display returns to the
PERSONAL PROGRAM main screen.
Exiting the Personal Program Menu
The personal program menu will be exited when any of
the following occurs:
The vehicle is shifted out of PARK (P).
The vehicle is no longer in ON/RUN.
The end of the personal program menu is reached.
3-83
Page 212 of 440

Audio System(s)
Determine which radio your vehicle has and then read
the pages following to familiarize yourself with its
features.
{CAUTION:
This system provides you with far greater
access to audio stations and song listings.
Giving extended attention to entertainment
tasks while driving can cause a crash and you
or others can be injured or killed. Always keep
your eyes on the road and your mind on the
drive — avoid engaging in extended searching
while driving.Keeping your mind on the drive is important for safe
driving. SeeDefensive Driving on page 4-2. Here
are some ways in which you can help avoid distraction
while driving.
While your vehicle is parked:
Familiarize yourself with all of its controls.
Familiarize yourself with its operation.
Set up your audio system by presetting your
favorite radio stations, setting the tone, and
adjusting the speakers. Then, when driving
conditions permit, you can tune to your favorite
radio stations using the presets and steering wheel
controls if the vehicle has them.
3-84
Page 213 of 440

Notice:Before adding any sound equipment to
your vehicle, such as an audio system, CD player,
CB radio, mobile telephone, or two-way radio, make
sure that it can be added by checking with your
dealer/retailer. Also, check federal rules covering
mobile radio and telephone units. If sound
equipment can be added, it is very important to do
it properly. Added sound equipment may interfere
with the operation of your vehicle’s engine, radio, or
other systems, and even damage them. Your
vehicle’s systems may interfere with the operation
of sound equipment that has been added.
Notice:The chime signals related to safety belts,
parking brake, and other functions of your vehicle
operate through the radio/entertainment system.
If that equipment is replaced or additional equipment
is added to your vehicle, the chimes may not
work. Make sure that replacement or additional
equipment is compatible with your vehicle before
installing it. SeeAccessories and Modifications
on page 5-3.Your vehicle may have a feature called Retained
Accessory Power (RAP). With RAP, the audio system
can be played even after the ignition is turned off.
SeeRetained Accessory Power (RAP) on page 2-25for
more information.
Setting the Clock
Press and hold H until the correct hour and AM or PM
displays. Press and hold M until the correct minute
displays. The time can be set with the ignition on or off.
3-85
Page 214 of 440
Radio(s)
Your vehicle has one of these radios as its audio
system. Radio with CD (MP3) shown, Radio with CD similar
Radio with Six-Disc CD
3-86
Page 215 of 440

Playing the Radio
P
(Power):Press to turn the system on and off.
v(Volume):Turn to increase or to decrease the
volume.
DISP (Display):Press to switch the display between
the radio station frequency and time of day. While
the ignition is off, press this button to display the time.
If your vehicle’s radio has XM™ (if equipped), press
the DISP button while in XM™ mode to retrieve
four different categories of information related to the
current song or channel: Artist, Song Title, Category or
PTY, Channel Number/Channel Name.
To change the default on the display, press the DISP
button until the desired display appears, then hold
this button for two seconds. The radio beeps once and
the selected display becomes the default.
SCV (Speed Compensated Volume):If your vehicle’s
radio has Speed Compensated Volume (SCV), the
audio system adjusts automatically to make up for road
and wind noise while driving.Set the volume at the desired level. Press this button to
select LOW, MEDIUM, or HIGH. Depending on the
radio, the selection may be SPEED VOL MIN (volume
minimum), SPEED VOL MED (volume medium), or
SPEED VOL MAX (volume maximum). Each higher
setting allows for more volume compensation at faster
vehicle speeds. Then while driving, SCV increases
the volume, as necessary, to overcome noise at any
speed. The volume level should always sound the same
to you as you drive. NONE displays if the radio cannot
determine the vehicle speed. To turn SCV off, press this
button until OFF or SPEED VOL OFF displays.
Finding a Station
BAND:Press to switch between FM1, FM2, AM, or
XM1™ or XM2™ (if equipped).
e(Tune):Turn to select radio stations.
oSEEKp:Press and release the arrows to go to
the previous or the next station and stay there.
To scan stations, press and hold either arrow for more
than two seconds. SCAN or SCN displays and the
radio beeps once. The radio goes to a station, plays for
a few seconds, and then goes to the next station.
Press either arrow again or one of the pushbuttons to
stop scanning presets.
3-87
Page 216 of 440

To scan preset stations, press and hold either arrow for
more than four seconds. PSCAN or PSC displays
and the radio beeps twice. The radio goes to a preset
station, plays for a few seconds, then goes to the
next preset station. Press either arrow again or one of
the pushbuttons to stop scanning presets.
The radio seeks and scans stations only with a strong
signal that are in the selected band.
SCAN:Press until SC displays. The radio goes to a
station, plays for a few seconds, and then goes to
the next station. Press again to stop scanning stations.
The radio scans stations only with a strong signal
that are in the selected band.
INFO (Information) (XM™ Satellite Radio Service
Only):Your vehicle’s radio may have an INFO button.
If the current station on the radio has a message,
the information symbol displays. Press to see the
message. If the entire message is not displayed, parts
of the message appears every three seconds. To
manually scroll through the message, press and release
the INFO button.
When a message is not available from a station, NO
INFO displays.Setting Preset Stations
Up to 30 stations (six FM1, six FM2, six AM, six XM1™
and six XM2™ (if equipped)) can be programmed on
the six numbered pushbuttons.
To program either radio:
1. Turn the radio on.
2. Press BAND to select FM1, FM2, AM, or XM1™ or
XM2™ (if equipped).
3. Tune to the desired station.
4. Press EQ to select the equalization.
5. Press and hold one of the six numbered
pushbuttons until the radio beeps once. When that
numbered pushbutton is pressed again, the
station and equalization that were stored, returns.
6. Repeat the steps for each pushbutton.
Setting the Tone (Bass/Treble)
e
(Bass/Treble):Press and release until BASS or
TREBLE displays. Turn this knob to increase or to
decrease the bass or treble.
Press and hold to adjust the bass and treble to the
middle position. The radio beeps once.
3-88
