2008 Acura RL Owner's Manual

If you decide that a child can saf ely
ride up f ront, be sure to:Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly.
Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat. Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.52
17
Protecting L arger Children
Physical Size
Maturity
When Can a L arger Child Sit in
Front
54
\f—\f—
y\fy
(\fy\f\fy
2008 RL

This could result
in serious neck injuries during a
crash. Devices intended to
improve a child’s comf ort or
reposition the shoulder part of a
seat belt can make the belt less
ef f ective and increase the chance
of serious injury in a crash.
This could
cause very serious injuries during
a crash. It also increases the
chance that the child will slide
under the belt in a crash and be
injured.
If they do, they
could be very seriously injured in a
crash.
Do not let a child wear a seat belt
across t he neck. Do not put any accessories on a
seat belt.
Do not let a child put the shoulder part of a seat belt behind t he backor under t he arm.
T wo children should never use thesame seat belt .
Additional Saf ety Precautions
Protecting L arger Children
Driver and Passenger Saf ety
55
\f—\f—
y\f\fy
(\fy\f\f\fy
2008 RL

Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
Have the exhaust system inspected
f or leaks whenever:
With the trunk open, airf low can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
trunk open, open all the windows and
set the climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconfined area, adjust the climate
control system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
1.
2.
3.
4.
Carbon Monoxide Hazard
56
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
\f—\f—
y\f\fy
(\fy\f\f
y
2008 RL

CONT INUED
These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.
U.S. modelsCanadian models U.S. models only
Saf ety L abels
Driver and Passenger Saf ety
57
HOOD
DASHBOARD
RADIATOR CAP
\f—\f—
y\f
y
(\fy\f\fy
2008 RL

U.S. modelsCanadian models U.S. models Canadian models
Saf ety L abels
58
DOORJAMBS
SUN VISORS
\f—\f—
y\fy
(\fy\f\fy
2008 RL

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .60
............................
Instrument Panel .61
..........
Instrument Panel Indicators .62
.............................................
Gauges .70
...................
Temperature Gauge .70
..................................
Fuel Gauge .70
.............
Multi-Inf ormation Display .71
Controls Near the Steering
.........................................
Wheel .136
Windshield Wipers and .....................................
Washers .137
.......
Turn Signals and Headlights .140
.................................
Fog Lights .142
.........
Daytime Running Lights .142
Automatic Lighting Off
...................................
Feature .142
Adaptive Front Lighting System
..........................................
(AFS) .143
...............
Hazard Warning Button .145
......
Instrument Panel Brightness .145
...............
Rear Window Def ogger .146
......
Steering Wheel Adjustments .147
.............................
Keys and Locks .149
......................
Immobilizer System .150
..............................
Ignition Switch .151
....................................
Door Locks .152 ..............................................
Trunk .153
......
Emergency Trunk Opener .154
................
Childproof Door Locks .154
...............................................
Seats .155
...........................................
Mirrors .159
Driving Position Memory
........................................
System .160
................
Keyless Access System .163
..................................
Seat Heaters .178
Seat Heaters and Seat
.................................
Ventilation .179
............................
Power Windows .181
.......................................
Moonroof .184
...............................
Parking Brake .187
.........
Interior Convenience Items .188
..................................
Glove Box .189
.....................
Beverage Holders .190
.............
Console Compartment .191
..................................
Sun Visors .192
........
Accessory Power Sockets .192
...........................
Rear Ashtrays .193
..................
Front Door Pockets .193
..............
Power Rear Sunshade .194
..............
Integrated Sunshades .195
...............................
Interior Lights .196
Instruments and Controls
Inst rument s and Cont rols
59
\f—\f—
y\f
y
(\fy\f\fy
2008 RL

ÎÎ
Î
Î
Control L ocations
60
AUDIO SYSTEM
POWER WINDOW
SWITCHES INSTRUMENT PANEL
INDICATORS
GAUGES
CLIMATE CONTROL
SYSTEM
TRUNK RELEASE BUTTON HOOD RELEASE LEVER
DRIVING POSITION
MEMORY SYSTEM
FUEL FILL DOOR RELEASE
BUTTON
POWER DOOR LOCK
MASTER SWITCH
MOONROOF SWITCH MIRROR CONTROL
AUTO BUTTON
AUTOMATIC
TRANSMISSION
ACCESSORY POWER
SOCKETS
(P.62)
(P.70)
INTERFACE DIAL
1: 2: CEILING CONSOLE
(P.160)
(P.152) (P.181)
(P.194)(P.153) (P.192)
COMPASS SYSTEM
(P.199) (P.207) (P.198)
RL models (P.184)
(P.157) (P.329) (P.331) (P.349)
(P.242)
(P.158)
HOMELINK
BUTTONS
POWER REAR
SUNSHADE BUTTON
REAR HEAD RESTRAINT
TILT BUTTON (P.295)
1
2
——
yy
(yy
2008 RL

ÎÎ
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.If equipped.
:
Instrument Panel
Inst rument s and Cont rols
61
SEAT BELT REMINDER
INDICATOR
CHARGING SYSTEM
INDICATOR
KEYLESS ACCESS
SYSTEM INDICATOR
LOW OIL PRESSURE
INDICATOR
MALFUNCTION INDICATOR
LAMP
LOW FUEL INDICATORCRUISE MAIN INDICATOR
ELECTRONICALLY
CONTROLLED
POWER STEERING
SYSTEM (ECPS)
INDICATOR
LIGHTS ON INDICATOR
FOG LIGHT INDICATOR
MULTI-INFORMATION
DISPLAY
MESSAGE INDICATOR
SECURITY SYSTEM
INDICATOR
(P.64)
(P.68)
(P.68)
(P.69)
(P.71)
(P.66)(P.21,62)(P.68)
ANTI-LOCK BRAKE
SYSTEM (ABS)
INDICATOR
(P.34,63)
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) INDICATOR
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
VSA
ACTIVATION
INDICATOR
HIGH BEAM
INDICATOR
COLLISION MITIGATION
BRAKE SYSTEM (CMBS)
INDICATOR ADAPTIVE CRUISE CONTROL (ACC)
INDICATOR
ADAPTIVE FRONT LIGHTING
SYSTEM (AFS) INDICATOR (P.69,143)
(P.69) SIDE AIRBAG OFF
INDICATOR
(P.35,63)
(P.62,447)
(P.65)
(P.62,448) (P.62,447) (P.64,359)
(P.66,280)
(P.65) (P.65,377)
(P.377)
IMMOBILIZER SYSTEM
INDICATOR
PARKING BRAKE
AND BRAKE SYSTEM
INDICATOR (P.63,449)(P.64)
SH-AWD INDICATOR (P.66)
LOW TIRE PRESSURE/TPMS INDICATOR
(P.67,371) (P.65)/
\f—\f—
y\fy
(\fy\f\fy
2008 RL
