2007 Volvo XC70
The seat belts are equipped with tensioners that reduce slack in the bel\
ts. These tensioners are triggered
in situations where the airbags deploy. The front seat belts also includ\
e a tension reducing device which,
in the event of a collision, limits the peak forces exerted by the seat \
belt on the occupant.
Buckling a seat belt
Pull the belt out far enough to insert the latch plate into the receptac\
le until a distinct click is heard. The
seat belt retractor is normally "unlocked" and you can move freely, prov\
ided that the shoulder belt is not
pulled out too far.
The retractor will lock up as follows:
l if the belt is pulled out rapidly
l during braking and acceleration
l if the vehicle is leaning excessively
l when driving in turns
When wearing the seat belt remember:
l The belt should not be twisted or turned.
l The lap section of the belt must be positioned low on the hips (not pre\
ssing against the abdomen).
l Make sure that the shoulder belt is rolled up into its retractor and tha\
t the shoulder and lap belts are
taut.
Unbuckling the seat belt
To remove the seat belt, press the red section on the seat belt receptac\
le. Before exiting the vehicle,
check that the seat belt retracts fully after being unbuckled. If necess\
ary, guide the belt back into the
retractor slot.
Seat belt reminder
The seat belt reminder consists of an audible signal, an indicator light\
above the rearview mirror, and a
symbol in the instrument panel that alert the driver and front seat pass\
enger if their seat belts are not
fastened.
pg. 13 Safety
Seat belts
file:///K|/ownersdocs/2007/2007_XC70/07xc70_01.htm (4 of 38)12/30/2006\
5:51:26 PM

2007 Volvo XC70
2 0 0 7
VOLVO XC70
Instruments and controls

pg. 43 Instruments and controls
Instrument overview
44
Instrument panel
46
Indicator and warning symbols
47
Switches in the center console
52
Steering wheel adjustment
54
Lighting panel
55
Left-side steering wheel lever
57
Right-side steering wheel lever
58
Hazard warning flashers, rear window/sideview mirror
defroster
60
Trip computer
61
Cruise control
62
Parking brake, auxiliary socket/cigarette lighter
64
Power windows
65
Rearview mirror/sideview mirrors
67
Power moonroof (option)
70
pg. 44 Instruments and controls
Instrument overview
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (1 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
33. Moonroof control 70
34. Seat belt reminder
12
35. Rearview mirror
67
36. Lock button, for all doors
114
37. Rear seat power window cut-out button
66
38. Controls, power windows
65
39. Controls, sideview mirrors
69
40. Four-C active chassis system (R-models only)
135
pg. 46 Instruments and controls
Instrument panel
1. Turn signal indicators - right/left
2. Text window
The text window displays information and warning messages.
3. Temperature gauge
The pointer should be approximately midway on the gauge when driving. Do not drive the vehicle if
the warning light is on. The text window will provide you with additional information.
If the engine temperature remains high, check coolant level - see
page 188.
4. Trip odometer
The trip odometers are used for measuring shorter distances. The right-h\
and digit gives tenth of a mile/
kilometer. Press the button for more than 2 seconds to reset. Change bet\
ween trip odometers 1 and 2
using one short press on the button.
5. Odometer
6. Speedometer
7. Warning symbol
8. High beam indicator
9. Tachometer
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (4 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
pg. 60 Instruments and controls
Hazard warning flashers, rear window/sideview mirror defroster
Hazard warning flashers
The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard. To activate
the flashers, press the triangular button in the center dash. Press the \
button again to turn off the flashers.
NOTE: Regulations regarding the use of the hazard warning flasher may vary, d\
epending on where you
live.

Rear window and sideview mirror defroster
Press the switch to start heating the rear window and sideview mirrors t\
o remove ice or condensation.
An LED in the switch will light up.
A timer automatically switches off the heating after approximately 12 mi\
nutes. The LED will go out
correspondingly.
pg. 61 Instruments and controls
Trip computer
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (20 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
Power window on the front passenger's side
The control for the electrically operated window in the front passenger'\
s seat operates that window only.
Power windows in the rear doors
The rear door windows can be operated with the control on each door and \
the switch on the driver's
door. If the LED in the switch for blocking electrically operated window\
s in the rear doors (located in
the driver's door control panel) is on, the rear door windows can only \
be operated from the driver's door.
pg. 67 Instruments and controls
Rearview mirror/sideview mirrors
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (28 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
Rearview mirror
To reduce glare from the headlights of following vehicles, use the contr\
ol to switch between the normal
and night-driving positions.
A. Normal position
B. Night position, reduces glare from following headlights
Autodim function (option)
The autodim function reacts to headlights from following traffic and aut\
omatically reduces glare.
NOTE: This function is automatically switched off when the gear selector is p\
laced in the Reverse
position.
Rearview mirror with compass (option)
The upper left-hand corner of the rearview mirror has an integrated disp\
lay that shows the compass
direction toward which the car is pointing. Eight different directions c\
an be displayed: N, NE, E, SE, S,
SW, W and NW. The display shows your car's orientation with respect to t\
rue north.
If the compass is activated, it will be displayed automatically when the\
ignition is in postilion II or when
the engine is running. The compass can be switched off or on by pressing\
the inset button on the rear
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (29 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
side of the mirror (see the inset illustration). This can be done with\
straightened paper clip or similar
object. The button is recessed approximately 1 in. (2.5 cm) in the mir\
ror.
pg. 68 Instruments and controls
Rearview mirror/sideview mirrors
Magnetic zones
The earth is divided into 15 magnetic zones. The compass is initially se\
t for the zone to which the car
was delivered, and should always be adjusted if the car is driven to a n\
ew magnetic zone. To do so:
- Switch the ignition to position II.
- Press the button on the rear side of the mirror with straightened pape\
r clip or similar object for
approximately 3 seconds until ZONE is displayed. The number of the curre\
nt magnetic zone will also be
displayed.
- Press the button repeatedly until the number for the desired zone (1-\
15) is displayed.
After several seconds, the compass heading will again be displayed, and \
the change of magnetic zones is
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (30 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
complete.
Calibrating the compass
- Stop the car in a large, open area, away from traffic.
- Turn off as many electrical devices in the car as possible to avoid in\
terference with the compass (e.g.
audio system, etc).
- Using a pen or similar object, hold the button (1) depressed for at \
least 6 seconds. "CAL" will be
displayed.
- Drive slowly in a circle at a maximum speed of 5 m.p.h. (8 km/h) unt\
il CAL is no longer displayed.
NOTE: This step can also be done by driving normally until CAL is no longer d\
isplayed. Calibration is
complete.
pg. 69 Instruments and controls
Rearview mirror/sideview mirrors
Power sideview mirrors
The mirror control switches are located on the driver's door armrest.
Driver's side: Press the L switch (an LED in the switch will light up) to activate t\
he adjustment control
and then use this control to adjust the driver's door mirror.
Passenger's door: Press the R switch (an LED in the switch will light up) and then use \
the adjustment
control to adjust the passenger's door mirror.
After you have adjusted the mirror(s), press the L or R switch again (\
the LED will go out) to deactivate
the adjustment control.
