pg. 2 Introduction
General Information
Shiftlock (automatic transmission)
When your vehicle is parked, the gear selector is locked in the (P)ark position. To release the selector from this
position, turn the ignition key to position II (or start the engine), \
depress the brake pedal, press the button on the
front side of the gear selector and move the selector from (P)ark.
Keylock (automatic transmission)
When you switch off the ignition, the gear selector must be in the (P)ark position before the key can be removed
from the ignition switch.
Anti-lock Brake System (ABS)
The ABS system in your vehicle performs a self-diagnostic test when the \
vehicle first reaches the speed of
approximately 12 mph (20 km/h). The brake pedal will pulsate several t\
imes and a sound may be audible from the
ABS control module. This is normal.
Fuel filler door
The fuel filler door, located on the right rear fender, is connected to \
your vehicle's central locking system.
Press the button on the light switch panel (see illustration on
page 56) when the vehicle is at a standstill to unlock
the fuel filler door. Please note that the fuel filler door will remain \
unlocked until the vehicle begins to move
forward. An audible click will be heard when the fuel filler door relock\
s.
Fuel filler cap
After refueling, close the fuel filler cap by turning it clockwise until\
it clicks into place. If this cap is not closed
tightly or if the engine is running when the vehicle is refueled, the Ma\
lfunction Indicator Lamp ("Check Engine"
light) will illuminate.
Important information
file:///K|/ownersdocs/2007/2007_XC70/07xc70_00.htm (2 of 6)12/30/2006 \
5:51:24 PM

2007 Volvo XC70
impact of a product throughout its complete life cycle. In this context,\
design, production, product use, and
recycling are all important considerations. In production, Volvo has par\
tly or completely phased out several
chemicals including freons, lead chromates, naphtanates, asbestos, mercu\
ry and cadmium; and reduced the amount
of chemicals used in our plants 50% since 1991.
Volvo was the first in the world to introduce into production a three-wa\
y catalytic converter with a Lambda sond,
now called oxygen sensor, in 1976. The current version of this highly ef\
ficient system reduces emissions of
harmful substances (CO, HC, NOx) from the exhaust pipe by approximatel\
y 95% and the search to eliminate the
remaining emissions continues. Volvo is the only automobile manufacturer\
to offer CFC-free retrofit kits for the
air conditioning system of all models as far back as the 1975 model 240.\
Advanced electronic engine controls,
refined purification systems and cleaner fuels are bringing us closer to\
our goal.
After Volvo vehicles and parts have fulfilled their use, recycling is th\
e next critical step in completing the life
cycle. The metal content is about 75% of the total weight of a vehicle, \
which makes the vehicle among the most
recycled industrial products. In order to have efficient and well contro\
lled recycling, many Volvo variants have
printed dismantling manuals, indicating the weight and material of indiv\
idual components. For Volvo, all
homogeneous plastic parts weighing more than 1.7 oz. (50 grams) are ma\
rked with international symbols that
indicate how the component is to be sorted for recycling.
In addition to continuous environmental refinement of conventional gasol\
ine-powered internal combustion
engines, Volvo is actively looking at advanced technology alternative-fu\
el vehicles.
When you drive a Volvo, you become our partner in the work to lessen the\
vehicle's impact on the environment.
To reduce your vehicle's environmental impact, you can:
l Maintain proper air pressure in your tires. Tests have shown decreased f\
uel economy with improperly inflated
tires.
l Follow the recommended maintenance schedule in your Warranty and Service\
Records Information booklet.
l Drive at a constant speed.
l See an authorized Volvo retailer as soon as possible for inspection if t\
he check engine (malfunction indicator)
lamp illuminates, or stays on after the vehicle has started.
l Properly dispose of any vehicle-related waste such as used motor oil, us\
ed batteries, brake pads, etc.
l When cleaning your vehicle, use Volvo's own vehicle care products, all o\
f which have systematically been
adapted to the environment.
PremAir® (certain models only)
The surface of the radiator in the engine compartment
1 is treated with a special coating called PremAir2. This
coating works as a catalytic converter, converting most of the ground le\
vel ozone passing through the
1. Only vehicles with engine B5244S (engine code 39 in the VIN)
2. PremAir is a registered trademark of Engelhard Corporation.
pg. 5 Introduction
Volvo and the environment
radiator into oxygen, thereby reducing harmful ground-level ozone.
NOTE: If a PremAir-coated radiator needs to be replaced, it should be replace\
d with another radiator with this
file:///K|/ownersdocs/2007/2007_XC70/07xc70_00.htm (4 of 6)12/30/2006 \
5:51:24 PM

2007 Volvo XC70
coating. If this is not done, the Malfunction Indicator Light (see page 48) will illuminate.
pg. 6 Introduction
Important warnings
Accessory Installation
l We strongly recommend that Volvo owners install only genuine, Volvo-appr\
oved accessories, and that
accessory installations be performed only by the factory-trained technic\
ians at your authorized Volvo retailer.
l Genuine Volvo accessories are tested to ensure compatibility with the pe\
rformance, safety, and emission
systems in your vehicle. Additionally, your authorized Volvo retailer kn\
ows where accessories may and may not
be safely installed in your Volvo. In all cases, please consult your aut\
horized Volvo retailer before installing any
accessory in or on your vehicle.
l Accessories that have not been approved by Volvo may or may not be speci\
fically tested for compatibility with
your vehicle. Additionally, an inexperienced installer may not be famili\
ar with some of your vehicle's systems.
l Any of your vehicle's performance and safety systems could be adversely \
affected if you install accessories that
Volvo has not tested, or if you allow accessories to be installed by som\
eone unfamiliar with your vehicle.
l Damage caused by unapproved or improperly installed accessories may not \
be covered by your new vehicle
warranty. See your Warranty and Service Records Information booklet for \
more warranty information. Volvo
assumes no responsibility for death, injury, or expenses that may result\
from the installation of non-genuine
accessories.
Driver Distraction
l Driver distraction results from driver activities that are not directly \
related to controlling the vehicle in the
driving environment. Your new Volvo is, or can be, equipped with many fe\
ature-rich entertainment and
communication systems. These include hands-free cellular telephones, nav\
igation systems, and multipurpose audio
systems. You may also own other portable electronic devices for your own\
convenience. When used properly and
safely, they enrich the driving experience. Improperly used, any of thes\
e could cause a distraction.
l For all of these systems, we want to provide the following warning that \
reflects the strong Volvo concern for
your safety:
l Never use these devices or any feature of your vehicle in a way that dis\
tracts you from the task of driving safely.
Distraction can lead to a serious accident.In addition to this general w\
arning, we offer the following guidance
regarding specific newer features that may be found in your vehicle:
l Never use a hand-held cellular telephone while driving. Some jurisdictio\
ns prohibit cellular telephone use by a
driver while the vehicle is moving.
l If your vehicle is equipped with a navigation system, set and make chang\
es to your travel itinerary only with the
vehicle parked.
l Never program your audio system while the vehicle is moving. Program rad\
io presets with the vehicle parked,
and use your programmed presets to make radio use quicker and simpler.
l Never use portable computers or personal digital assistants while the ve\
hicle is moving.
A driver has a responsibility to do everything possible to ensure his or\
her own safety and the safety of passengers
in the vehicle and others sharing the roadway. Avoiding distractions is \
part of that responsibility.
pg. 7 Introduction
file:///K|/ownersdocs/2007/2007_XC70/07xc70_00.htm (5 of 6)12/30/2006 \
5:51:24 PM

2007 Volvo XC70
airbag should be enabled (may inflate) or disabled (will not inflate)\
.
The OWS will disable (will not inflate) the passenger's side front air\
bag when:
l the front passenger's seat is unoccupied, or has small/medium objects in\
the front seat,
l the system determines that an infant is present in a rear-facing infant \
seat that is installed according to
the manufacturer's instructions,
l the system determines that a small child is present in a forward-facing \
child restraint that is installed
according to the manufacturer's instructions,
l the system determines that a small child is present in a booster seat,
l a front passenger takes his/her weight off of the seat for a period of t\
ime,
l a child or a small person occupies the front passenger's seat.
The OWS uses a PASSENGER AIRBAG OFF indicator lamp which will illuminate\
and stay on to
remind you that the passenger's side front airbag is disabled. The PASSE\
NGER AIRBAG OFF indicator
lamp is located in the overhead console, near the base of the rearview m\
irror.
NOTE: The PASSENGER AIRBAG OFF indicator lamp will illuminate for a short per\
iod of time when
the ignition is turned on to confirm it is functional. When the front pa\
ssenger's seat is not occupied
(empty seat) or in the event that the passenger's side front airbag is\
enabled (may inflate), the
PASSENGER AIRBAG OFF indicator lamp will be off.
However, if a fault is detected in the system:
l The OWS indicator light will stay on.
l The SRS warning light (see page 15) will come on and stay on.
The message PASS. AIRBAG OFF SERVICE URGENT will be displayed in the inf\
ormation display.
pg. 21 Safety
Occupant Weight Sensor (OWS)
WARNING!
If a fault in the system is detected and indicated as explained on the p\
revious page, be aware that the
passenger's side front airbag will not deploy in the event of a collisio\
n.
In this case, the safety systems and Occupant Weight Sensor should be in\
spected by an authorized
Volvo retailer as soon as possible.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_01.htm (13 of 38)12/30/200\
6 5:51:26 PM

2007 Volvo XC70
WARNING!
l Never try to open, remove, or repair any components in the OWS system. T\
his could result in
system malfunction. Maintenance or repairs should only be carried out by\
an authorized Volvo
service technician.
l The front passenger's seat should not be modified in any way. This could\
reduce pressure on the
seat cushion, which might interfere with the OWS system's function.
The OWS is designed to disable (will not inflate) the passenger's side\
front airbag when a rear facing
infant seat, a forward-facing child restraint, or a booster seat is dete\
cted. The PASSENGER AIRBAG
OFF indicator lamp will illuminate and stay on to remind you that the pa\
ssenger's side front airbag is
disabled (see the following table).
1. Volvo recommends that children always be properly restrained in appro\
priate child restraints in the rear seats.
In rare situations when the seat belt is not properly fastened, some chi\
ld restraints may not be detected by the
OWS because there is very little weight on the vehicle seat cushion. In \
these cases the passenger's side front
airbag may be disabled, but the PASSENGER AIRBAG OFF indicator lamp will\
not be lit. Do not assume that
the passenger's side front airbag is disabled unless the PASSENGER AIRBA\
G OFF indicator lamp is lit. Make
sure the child restraint is properly installed (turn the vehicle off, r\
emove the child restraint from the vehicle and
reinstall the restraint following the child restraint manufacturer's ins\
tructions) and that the PASSENGER
AIRBAG OFF indicator lamp is on, or move the child restraint to the rear\
seat.
The OWS is designed to enable (may inflate) the passenger's side front\
airbag anytime the system senses
that a person of adult size is sitting properly in the front passenger's\
seat. The PASSENGER AIRBAG
file:///K|/ownersdocs/2007/2007_XC70/07xc70_01.htm (14 of 38)12/30/200\
6 5:51:26 PM

2007 Volvo XC70
OFF indicator lamp will be off and remain off.
If a person of adult size is sitting in the front passenger's seat, but \
the PASSENGER AIRBAG OFF
indicator lamp is on, it is possible that the person isn't sitting prope\
rly in the seat. If this happens:
l Turn the vehicle off and ask the person to place the seatback in an upri\
ght position.
pg. 22 Safety
Occupant Weight Sensor (OWS)
l Have the person sit upright in the seat, centered on the seat cushion, w\
ith the person's legs
comfortably extended.
l Restart the vehicle and have the person remain in this position for abou\
t two minutes. This will allow
the system to detect that person and enable the passenger's frontal airb\
ag.
l If the PASSENGER AIRBAG OFF indicator lamp remains on even after this, t\
he person should be
advised to ride in the rear seat.
This condition reflects limitations of the OWS classification capability\
. It does not indicate OWS
malfunction.
Modifications
If you are considering modifying your vehicle in any way to accommodate \
a disability, for example by
altering or adapting the driver's or front passenger's seat(s) and/or \
airbag systems, please contact Volvo
at:
In the USA
Volvo Cars of North America, LLC
Customer Care Center
P.O. Box 914
Rockleigh, New Jersey 07647-0914
1-800-458-1552
In Canada
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
file:///K|/ownersdocs/2007/2007_XC70/07xc70_01.htm (15 of 38)12/30/200\
6 5:51:26 PM

2007 Volvo XC70
go out. Certain symbols may not have their functions illustrated, depen\
ding on the vehicle's
equipment. The symbol for the parking brake goes out when the parking br\
ake is released.
Warning symbol
in center of the instrument panel
This symbol shines as a red or yellow light depending on the severity of\
the discovered fault.
Red symbol - Stop the vehicle as soon as possible in a suitable location and read \
the message shown in
the text window. The symbol and accompanying text will remain on until t\
he fault has been corrected.
Yellow symbol - Follow the instructions shown in the text window. The text can be era\
sed by pressing
the READ button (see
page 50), or will disappear automatically after two minutes.
When the message "TIME FOR REGULAR SERVICE" is displayed, the text can b\
e erased and the
yellow symbol light can be turned off by pressing the READ button. The t\
ext will disappear and the
symbol light will go out automatically after two minutes.
Seat belt reminder
This symbol lights up to indicate that the driver has not fastened his/h\
er seat belt.
Supplemental Restraint System SRS
If this light comes on while the vehicle is being driven, or remains on \
for longer than approximately 10
seconds after the vehicle has been started, the SRS system's diagnostic \
functions have detected a fault in
a seat belt lock or tensioner, a front airbag, side impact airbag, and/o\
r an inflatable curtain. Have the
system(s) inspected by a trained and qualified Volvo service technicia\
n as soon as possible.
pg. 48 Instruments and controls
Indicator and warning symbols
BRAKE Brake failure warning light If the light comes on while driving or brak\
ing, stop immediately,
open the hood and check the brake fluid level in the reservoir. See
page 189 for reservoir position and
page 193 for instructions.
Canadian models are equipped with this warning light
If the BRAKE and ABS warning lights come on at the same time, this could\
indicate a fault in the
brake system.
- Stop the vehicle in a suitable place and switch off the engine.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (6 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
- Restart the engine.
- If both warning lights go off, no further action is required.
- If both lights are still on after the engine has been restarted, switc\
h off the engine again and check the
brake fluid level (see
page 189 for the location of the brake fluid reservoir).
- If the brake fluid level is above the MIN mark, drive carefully to an \
authorized Volvo retailer and have
the brake system inspected.
WARNING!
If the fluid level is below the MIN mark in the reservoir or if a "Brake\
failure - Service urgent"
message is displayed in the text window: DO NOT DRIVE. Have the vehicle \
towed to an authorized
Volvo retailer and have the brake system inspected.
PARK BRAKE Parking brake applied This light will be on when the parking brake (ha\
nd brake) is
applied. The parking brake lever is situated between the front seats. Se\
e also
page 64 for additional
information.
Canadian models are equipped with this symbol.
Oil pressure warning light If the light comes on while driving, stop the\
vehicle and then stop
the engine immediately and check the engine oil level. See
page 191. R-models are also equipped
with an oil level warning system. If the light stays on after restart, h\
ave the vehicle towed to the nearest
authorized Volvo retailer. After hard driving, the light may come on occ\
asionally when the engine is
idling. This is normal, provided it goes off when the engine speed is in\
creased.
Generator warning light
If the light comes on while the engine is running, have the charging sys\
tem checked.
Rear fog light
This light indicates that the fog light is on.
CHECK ENGINE Malfunction indicator light
On-Board Diagnostics II (OBDII): As you drive, a computer called "OBDI\
I" monitors your vehicle's
engine, transmission, electrical and emission systems. The CHECK ENGINE \
light will light up if the
computer senses a condition that potentially may need correcting. When t\
his happens, please have your
vehicle checked by a Volvo retailer as soon as possible.
A CHECK ENGINE light may have many causes. Sometimes, you may not notice\
a change in your
vehicle's behavior. Even so, an uncorrected condition could hurt fuel ec\
onomy, emission cleanliness, and
driveability. Extended driving without correcting the cause could even d\
amage other components in
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (7 of 35)12/30/2006\
5:51:30 PM
