2007 VOLVO XC70 ECO mode

2007 Volvo XC70
impact of a product throughout its complete life cycle. In this context,\
design, production, product use, and
recycling are all important considerations. In production, Volvo has par\
tly or completely phased out several
chemicals including freons, lead chromates, naphtanates, asbestos, mercu\
ry and cadmium; and reduced the amount
of chemicals used in our plants 50% since 1991.
Volvo was the first in the world to introduce into production a three-wa\
y catalytic converter with a Lambda sond,
now called oxygen sensor, in 1976. The current version of this highly ef\
ficient system reduces emissions of
harmful substances (CO, HC, NOx) from the exhaust pipe by approximatel\
y 95% and the search to eliminate the
remaining emissions continues. Volvo is the only automobile manufacturer\
to offer CFC-free retrofit kits for the
air conditioning system of all models as far back as the 1975 model 240.\
Advanced electronic engine controls,
refined purification systems and cleaner fuels are bringing us closer to\
our goal.
After Volvo vehicles and parts have fulfilled their use, recycling is th\
e next critical step in completing the life
cycle. The metal content is about 75% of the total weight of a vehicle, \
which makes the vehicle among the most
recycled industrial products. In order to have efficient and well contro\
lled recycling, many Volvo variants have
printed dismantling manuals, indicating the weight and material of indiv\
idual components. For Volvo, all
homogeneous plastic parts weighing more than 1.7 oz. (50 grams) are ma\
rked with international symbols that
indicate how the component is to be sorted for recycling.
In addition to continuous environmental refinement of conventional gasol\
ine-powered internal combustion
engines, Volvo is actively looking at advanced technology alternative-fu\
el vehicles.
When you drive a Volvo, you become our partner in the work to lessen the\
vehicle's impact on the environment.
To reduce your vehicle's environmental impact, you can:
l Maintain proper air pressure in your tires. Tests have shown decreased f\
uel economy with improperly inflated
tires.
l Follow the recommended maintenance schedule in your Warranty and Service\
Records Information booklet.
l Drive at a constant speed.
l See an authorized Volvo retailer as soon as possible for inspection if t\
he check engine (malfunction indicator)
lamp illuminates, or stays on after the vehicle has started.
l Properly dispose of any vehicle-related waste such as used motor oil, us\
ed batteries, brake pads, etc.
l When cleaning your vehicle, use Volvo's own vehicle care products, all o\
f which have systematically been
adapted to the environment.
PremAir® (certain models only)
The surface of the radiator in the engine compartment
1 is treated with a special coating called PremAir2. This
coating works as a catalytic converter, converting most of the ground le\
vel ozone passing through the
1. Only vehicles with engine B5244S (engine code 39 in the VIN)
2. PremAir is a registered trademark of Engelhard Corporation.
pg. 5 Introduction
Volvo and the environment
radiator into oxygen, thereby reducing harmful ground-level ozone.
NOTE: If a PremAir-coated radiator needs to be replaced, it should be replace\
d with another radiator with this
file:///K|/ownersdocs/2007/2007_XC70/07xc70_00.htm (4 of 6)12/30/2006 \
5:51:24 PM

2007 Volvo XC70
33. Moonroof control 70
34. Seat belt reminder
12
35. Rearview mirror
67
36. Lock button, for all doors
114
37. Rear seat power window cut-out button
66
38. Controls, power windows
65
39. Controls, sideview mirrors
69
40. Four-C active chassis system (R-models only)
135
pg. 46 Instruments and controls
Instrument panel
1. Turn signal indicators - right/left
2. Text window
The text window displays information and warning messages.
3. Temperature gauge
The pointer should be approximately midway on the gauge when driving. Do not drive the vehicle if
the warning light is on. The text window will provide you with additional information.
If the engine temperature remains high, check coolant level - see
page 188.
4. Trip odometer
The trip odometers are used for measuring shorter distances. The right-h\
and digit gives tenth of a mile/
kilometer. Press the button for more than 2 seconds to reset. Change bet\
ween trip odometers 1 and 2
using one short press on the button.
5. Odometer
6. Speedometer
7. Warning symbol
8. High beam indicator
9. Tachometer
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (4 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
Indicates engine speed in thousands of revolutions per minute (rpm). D\
o not drive for long with the
needle in the red section. The engine has an built-in function preventin\
g excessively high engine speeds.
When this function operates, you may discern some pulsation, which in th\
at case is quite normal.
10. Gear and driving mode indicator
The currently selected driving mode is displayed here. If you use the op\
tional Geartronic function on the
automatic transmission, the currently selected gear will be displayed.
11. Ambient temperature gauge
This display indicates the air temperature outside your vehicle. A "snow\
flake" symbol in the text
window is displayed when the temperature is in the range of 23 - 36 °\
F (-5 - +2 °C).
Please note that this symbol does not indicate a fault with your vehicle\
. At low speeds or when the
vehicle is not moving, the temperature readings may be slightly higher t\
han the actual ambient
temperature.
12. Clock/set button
Turn the button to set the clock.
13. Fuel gauge
The fuel tank holds approximately:
Front wheel drive, non-turbo models - 18.5 US gal. (70 liters)
All turbo models - 18 US gal. (68 liters)
When the warning light in the gauge comes on, there are approximately 1.\
8 US gal. (8 liters) of fuel
remaining in the tank.
14. Indicator and warning symbols
pg. 47 Instruments and controls
Indicator and warning symbols
The indicator and warning symbols light up when you turn the ignition ke\
y to the driving position
(position II) before starting. This shows that the symbols are functio\
ning. When the engine starts, all
symbols go out. If the engine is not started within 5 seconds, all symbo\
ls except CHECK ENGINE and
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (5 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
go out. Certain symbols may not have their functions illustrated, depen\
ding on the vehicle's
equipment. The symbol for the parking brake goes out when the parking br\
ake is released.
Warning symbol
in center of the instrument panel
This symbol shines as a red or yellow light depending on the severity of\
the discovered fault.
Red symbol - Stop the vehicle as soon as possible in a suitable location and read \
the message shown in
the text window. The symbol and accompanying text will remain on until t\
he fault has been corrected.
Yellow symbol - Follow the instructions shown in the text window. The text can be era\
sed by pressing
the READ button (see
page 50), or will disappear automatically after two minutes.
When the message "TIME FOR REGULAR SERVICE" is displayed, the text can b\
e erased and the
yellow symbol light can be turned off by pressing the READ button. The t\
ext will disappear and the
symbol light will go out automatically after two minutes.
Seat belt reminder
This symbol lights up to indicate that the driver has not fastened his/h\
er seat belt.
Supplemental Restraint System SRS
If this light comes on while the vehicle is being driven, or remains on \
for longer than approximately 10
seconds after the vehicle has been started, the SRS system's diagnostic \
functions have detected a fault in
a seat belt lock or tensioner, a front airbag, side impact airbag, and/o\
r an inflatable curtain. Have the
system(s) inspected by a trained and qualified Volvo service technicia\
n as soon as possible.
pg. 48 Instruments and controls
Indicator and warning symbols
BRAKE Brake failure warning light If the light comes on while driving or brak\
ing, stop immediately,
open the hood and check the brake fluid level in the reservoir. See
page 189 for reservoir position and
page 193 for instructions.
Canadian models are equipped with this warning light
If the BRAKE and ABS warning lights come on at the same time, this could\
indicate a fault in the
brake system.
- Stop the vehicle in a suitable place and switch off the engine.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (6 of 35)12/30/2006\
5:51:30 PM

2007 Volvo XC70
The headlights and parking lights will illuminate and remain on for 301, 60 or 90 seconds. The time
interval can be changed by an authorized Volvo retailer.
1. Factory setting
pg. 58 Instruments and controls
Right-side steering wheel lever
Windshield wipers
Windshield wipers off
If the lever is in the 0 position and you move it upwards, the wipers wi\
ll sweep one stroke at a time for
as long as you hold the lever up.
Intermittent wiper function
With the lever in this position, you can set the wiper interval by twist\
ing the control ring 1 upward to
increase wiper speed or downward to decrease the speed.
Headlight wiper/washer (certain models)
When the lever is pulled to wash the windshield, high pressure jets moun\
ted in the bumper will spray the
headlights.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (17 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
Trip computer
The trip computer stores information gathered from several systems in yo\
ur vehicle and has four menus
that can be displayed in the text window.
l Driving distance on current fuel reserve
l Average fuel consumption
l Current fuel consumption
l Average speed
l Current speed in mph (Canadian models only)
l STC/DSTC (see page 125 for detailed information)
NOTE: Warning messages from the vehicle's monitoring systems will override th\
e trip computer
function. If a warning message is displayed in the text window while you\
are using the trip computer,
you must acknowledge the message by pressing button A. Press button A ag\
ain to return to the trip
computer function.
Trip computer controls and functions
The four
1 trip computer functions can be accessed by twisting control B one step \
at a time in either
direction. Twisting a fifth
2 time returns you to the original function. The trip computer can be res\
et
(current data will be erased from system memory) by pressing RESET (b\
utton C).
1. Driving distance on current fuel reserve
This function shows the approximate distance that can be driven on the f\
uel remaining in the tank. This
calculation is based on average fuel consumption during the last 20 mile\
s (30 km) of driving and the
amount of fuel remaining in the tank when the reading was taken. When th\
e driving distance on current
fuel reserve is less than 12 miles (20 km), "----" will be displayed i\
n the text window.
2. Average fuel consumption
This value indicates fuel consumption since the last time the trip compu\
ter was reset (by pressing
RESET, button C). When the engine is switched off, information on fuel \
consumption is stored and
remains in system memory until the RESET (button C) is pressed again.
3. Current fuel consumption
This value indicates the current fuel consumption, based on readings tak\
en once per second. When the
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (21 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
Heated front seats (option)
- Press the switch once for maximum seat heating. Both LEDs in the switc\
h will be lit.
- Press the switch a second time for comfort heating. One LED in the swi\
tch will be lit.
- Press the switch a third time to turn the heating off completely. The \
LED will go off.
The seat heating for the passenger seat should be switched off when the \
seat is not occupied.

A/C - ON/OFF
Press the switch to turn the air conditioning on or off. The "ON" or "OF\
F" LED will light up to indicate if the
system is switched on or off. Other functions will still be regulated au\
tomatically (if the AUTO switch is on).
l The air conditioning functions only at temperatures above 32 °F (0 °\
C).
l While the Defroster function is selected, the air conditioning is tempor\
arily activated to dehumidify the air, even
if you have manually switched the air conditioning off. This will only f\
unction if the blower is not switched off.

Recirculation
Press this switch to engage the recirculation function (air in the pass\
enger compartment recirculates - no fresh air
enters the compartment). The LED in the switch will light up to indicat\
e that the function is engaged.
l Use this function if the outside air is contaminated with exhaust gases,\
smoke, etc or to heat/cool the vehicle
quickly.
l Recirculation should not be used for more than 15 minutes. If your windo\
ws begin to fog or mist, make sure that
the recirculation function is switched off.
l Selecting Defroster automatically switches recirculation off.
l Timer mode activation: (vehicles with the Interior Air Quality system h\
ave no timer mode) Press and hold the
recirculation button for at least 3 seconds to activate a recirculation \
timer mode. The amber LED in the recirculation
button will flash 5 times to show that the timer mode is being activated\
. In timer mode, each time the recirculation
button is pressed, the climate control system will recirculate the air i\
n the passenger compartment for 5- 12 minutes,
depending on the outside air temperature, and then revert back to fresh \
air.
l Timer mode deactivation: Press and hold the recirculation button for 3 s\
econds. The amber LED in the
recirculation button will illuminate steadily for 5 seconds to show a re\
turn to "normal" mode.
l In normal mode, when the recirculation button is pressed, the climate co\
ntrol
pg. 79 Climate
Electronic climate control, ECC
file:///K|/ownersdocs/2007/2007_XC70/07xc70_03.htm (6 of 11)12/30/2006\
5:51:31 PM

2007 Volvo XC70
system will recirculate the air in the passenger compartment until the r\
ecirculation button is pressed again.
l Timer mode memory: If the vehicle is turned off while timer mode is acti\
ve, timer mode will still be active when
the vehicle is restarted.

Interior air quality sensor (option)
Some vehicles are equipped with a multi-filter and air quality sensor. T\
he filter separates gases and particles,
thereby reducing the amounts of odors and contaminants entering the vehi\
cle. The air quality sensor detects
increased levels of contaminants in the outside air. When the air qualit\
y sensor detects contaminated outside air, the
air intake closes and the air inside the passenger compartment is recirc\
ulated, i.e. no outside air enters the vehicle.
The filter also cleans recirculated passenger compartment air.
When the ECC system is in the AUTO mode, the green LED will be on
.
Operation
Press
to operate the air quality sensor (normal setting).
or:
Select one of the following three functions by pressing
1, 2 or 3 times. 1. The AUT LED lights. The air
quality sensor is now activated.
2. No LED lights. Recirculation is not activated unless needed to cool t\
he passenger compartment in a warm climate.
3. The MAN LED lights. Recirculation is now activated.
Keep in mind the following:
l Make it a rule to have the air quality sensor activated at all times.
l Recirculation is limited in cold climates to avoid fogging.
l If window fogging occurs, you should deactivate the air quality sensor. \
l If fogging occurs, use the defroster functions for the windshield, side \
windows and rear window. See page 77.
l The filter should be changed at the intervals recommended in the service\
schedule. However, if the vehicle is
used in a severely contaminated environment, it may be necessary to chan\
ge the filter more frequently.
pg. 80 Climate
Manual climate control with air conditioning, A/C
file:///K|/ownersdocs/2007/2007_XC70/07xc70_03.htm (7 of 11)12/30/2006\
5:51:31 PM
