2007 Volvo C70
169 07 Wheels and tires
Changing a wheel
Positioning the jack1
There are two jack attachment points on each side of the car.
6. Position the jack correctly in the attachment (see illustration abov\
e) and crank while simultaneously
guiding the base of the jack to the ground. The base of the jack must be\
flat on a level, firm, non-slippery
surface.
7. Before raising the car, check that the jack is still correctly positi\
oned in the attachment.
1Not included on models equipped with the tire sealing system.
WARNING
l The jack must correctly engage the jack attachment.
l Be sure the jack is on a firm, level, non-slippery surface.
l Never allow any part of your body to be extended under a car supported b\
y a jack.
l Use the jack intended for the car when changing a tire. For any other jo\
b, use stands to support the
car.
l Apply the parking brake and put the gear selector in the Park (P) position.
l Block the wheels standing on the ground, use rigid wooden blocks or larg\
e stones.
l The jack should be kept well-greased.
Removing the wheel
