2007 TOYOTA CAMRY HYBRID sensor

’07Camry hybrid_U (L/O 0610)
123
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Manually twist the knob to the position 2
to turn on the headlights if they are need-
ed immediately when entering a dark tun-
nel, parking structure, etc.
When the tail lights/headlights are turned
on, the brightness of the instrument clus-
ter will be reduced slightly unless the in-
strument panel light control knob is turned
fully clockwise.
However, the brightness of the instrument
cluster will not be reduced in daytime
even when the tail lights/headlights are
turned on.
The automatic light control sensor is on
the top of the instrument panel.
Do not place anything on the instrument
panel, and/or do not affix anything on the
windshield to block this sensor.
If you feel that the automatic light control
comes into operation too early or too late,
have the sensor adjusted by your Toyota
dealer.Automatic light cut off system
Position 1 or position 3 with the tail
lights on—
The lights automatically turn off when the
driver ’s door is opened after the “POWER”
switch is turned off.
Position 2 or position 3 with the head-
lights on—
The lights automatically turn off after 30
seconds when any of the doors or trunk
lid is opened and closed after the
“POWER” switch is turned off.
The lights can be turned off immediately
by pushing the lock switch on the elec-
tronic key with all the doors locked and
the trunk lid closed.
The time period before the lights turn off
can be changed. For details, ask your
Toyota dealer.
If any of the doors or trunk lid is left
open, the lights automatically turn off after
20 minutes.
To turn on the lights again, set the
“POWER” switch at ON or actuate the
headlight switch. If you are going to park
for over one week, make sure the knob is
in the “OFF” position.

’07Camry hybrid_U (L/O 0610)
136
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
1. Outside temperature (“OUTSIDE TEMP”)
The outside temperature display indi-
cates the outside air temperature.
The displayed temperature ranges from
− 40 C ( −40 F) up to 50 C (122 F).
If an abnormality exists in the connection
of the outside air temperature sensor, “ −−”
or “E” will appear on the display. If “ −−”
or “E” appears on the display, contact
your Toyota dealer.
There may be a case that “−−” appears
momentarily when the “POWER” switch is
quickly set to ON. It is normal if it goes
out soon. 2. Driving range
(“CRUISING RANGE”)
The distance the vehicle can travel with
the remaining fuel is calculated and
displayed based on the quantity of re-
maining fuel and past fuel consumption.
The driving range display indicates the
approximate distance that you can drive
until the fuel gauge reaches “E”. It is
different from the actual distance traveled.
If the fuel gauge malfunctions, the mileage
figure will not appear.
When the vehicle is refueled, the driving
range is recalculated.
The actual driving range varies with driv-
ing habits and road conditions. If fuel con-
sumption is good, the driving range will be
longer than indicated. If fuel consumption
is poor, the driving range will be shorter
than indicated.
If the low fuel level warning light comes
on, refuel the vehicle even if the display
indicates that the vehicle can be driven
further. 3. Average fuel consumption after re-
fueling (“TANK AVG”)
Average fuel consumption after refuel-
ing is calculated and displayed based
on total driving distance and total fuel
consumption.
Every time you refuel the vehicle, the dis-
played value is reset.
4. Driving distance (“SINCE START”)
The driving distance after the hybrid
system started is displayed.
Every time you turn on the hybrid system,
the driving distance display is reset. 5. Average vehicle speed (“AVG SPEED”)
Average vehicle speed is calculated and
displayed based on total driving dis-
tance and total driving time.

’07Camry hybrid_U (L/O 0610)
156
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
(h) Electric Power Steering SystemWarning Light
This light comes on when the power
steering control system fails.
CAUTION
If this light comes on, take your ve-
hicle to the Toyota dealer as soon as
possible. In this case, you may feel
the heavy steering wheel maneuver-
ing. Drive your vehicle while gripping
the steering wheel firmly.
(i) Open Door Warning Light and Buzz- er
This light remains on until all the doors
and trunk lid are completely closed.
The buzzer also sounds once when any
of the doors or trunk lid is not completely
closed at the vehicle speed 5 km/h (3
mph) or more. Stop the vehicle and close
the door and trunk lid completely. (j) SRS Warning Light
This indicator comes on when the
“POWER” switch is set at ON. It goes
off after about 6 seconds. This means
the SRS front airbags and seat belt pre-
tensioners are operating properly.
This warning light system monitors the
airbag sensor assembly, front airbag sen-
sors, side and curtain shield airbag sen-
sors, curtain shield airbag sensors, driv-
er ’s seat position sensor, driver ’s seat belt
buckle switch, front passenger occupant
classification system, “AIRBAG ON” indi-
cator light, “AIRBAG OFF” indicator light,
front passenger ’s seat belt buckle switch,
seat belt pretensioner assemblies, inflat-
ors, interconnecting wiring and power
sources.
If any of the following conditions occurs,
this indicates a malfunction of the airbags
or seat belt pretensioners. Contact your
Toyota dealer as soon as possible to.
The light does not come on when the
“POWER” switch is set at ON or re-
mains on for more than 6 seconds.
The light comes on or starts flashing
while driving.The SRS warning light and “AIRBAG OFF”
indicator light will come on if there is a
malfunction in the front passenger occu-
pant classification system.
(k) Low Tire Pressure Warning Light
This light warns that the tire pressure of
one or more of your tires (including the
spare tire) is low. The light comes on
when the “POWER” switch is set at ON.
It goes off when the “READY” light comes
on. This indicates that the tire pressure
warning system is functioning properly.
If the warning light comes on, stop your
vehicle in a safe place as soon as pos-
sible and check that the inflation pressure
of all tires (including the spare tire) is as
specified on the tire and loading informa-
tion label. (See “Checking tire inflation
pressure” on page 359 in Section 7−
2.)
The light should go off a few minutes after
the tire pressure is adjusted.
If the warning light blinks (comes on after
blinking for 1 minute), the tire pressure
warning system may be malfunctioning.
Contact your Toyota dealer.
For details, see “Tire pressure warning
system” on page 168 in Section 1 −7.

’07Camry hybrid_U (L/O 0610)
259
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The compass sensor is in the inside
rear view mirror.
NOTICE
Do not put magnets or a metal object
on or near the inside rear view mirror
of the vehicle. Doing this may cause
malfunction of the compass sensor.
CALIBRATING THE COMPASS (deviation
calibration)
The direction display on the compass
deviates from the true direction deter-
mined by the earth’s magnetic field. The
angle of deviation varies according to the
geographic position of the vehicle.
To adjust this deviation, stop the vehicle,
then push and hold the switch until the
zone number appears on the display.
Then push the switch, referring to the fol-
lowing map to select the number of the
zone where the vehicle is.
