2007 TOYOTA 4RUNNER Navigation Manual

76
4U5052bG
2. Enter the location in the same way as
for a destination search. (See “Destination
search” on page 24.)
When registration of home is completed, the
“Memory Point” screen will be displayed.
4U5053G
3. Touch “OK”.
To edit registered information, see “ — Editing
memory points” on page 71.
— Deleting home
4U5054G
1. Touch “Delete”.
2. To delete home, touch “Yes”. To cancel
the deletion, touch “No”.
— Registering area to avoid
Areas you want to avoid because of traffic
jams, construction work or other reasons can
be registered as areas to avoid.
4U5055G
1. Touch “Register”.
4U5056aG
2. Enter the location in the same way as
for a destination search, or display the
map of the area to be avoided. (See
“Destination search” on page 24.)

77
4U5057G
3. Set the cursor in the center of the
area to avoid, and touch “Enter”.
4U5058G
4. Touch either or to change
the size of the area to be avoided.
5. Touch “OK”.
INFORMATION
If a destination is input in the area to
avoid or the route calculation cannot
be made without running through the
area to avoid, a route passing through
the area to be avoided may be shown.
Up to 10 locations can be registered
as points/areas to avoid. If there are
10 locations already registered, the
following message will be displayed:
“Unable to register additional points.
Perform operation again after
deleting unnecessary points.”.
— Editing area to avoid
The name, location and/or area size of a reg-
istered area can be edited.
4U5059G
1. Touch “Edit”.
4U5060G
2. Touch the desired area button.

78
4U5061G
3. Touch the touchscreen button to be
edited.
“Name”: To edit the name of the area to
avoid. The names can be displayed on the
map. (See page 78.)
“Location”: To edit area location. (See page
79.)
“Area Size”: To edit area size. (See page
79.)
“Active”: To turn on or off the area to avoid
feature. To turn on the feature touch “ON” on
the “Edit Area to Avoid” screen. To turn off the
feature touch “OFF” on the “Edit Area to
Avoid” screen.
4. Touch “OK”.
To change “Name”
1. Touch “Name” on the “Edit Area to
Avoid” screen.
4U5106G
2. Enter the name using alphanumeric
keys.
Up to 24 letters can be entered.
3. Touch “OK”.
The previous screen will be displayed.DISPLAYING NAMES OF AREAS TO BE
AVOIDED
The name of an area to be avoided that may
be displayed on the map can be set.
4U5062G
To show the name, touch “ON” on the
“Edit Area to Avoid” screen. To not show
it, touch “OFF”.

79
To change “Location”
1. Touch “Location” on the “Edit Area to
Avoid” screen.
4U5063G
2. Touch the eight directional touch
screen button to move the cursor to the
desired point on the map.
3. Touch “Enter”.
The previous screen will be displayed.
To change “Area Size”
1. Touch “Area Size” on the “Edit Area to
Avoid” screen.
4U5064G
2. Touch either or to change
the size of the area to be avoided.
3. Touch “OK”.
The previous screen will be displayed.
— Deleting area to avoid
4U5065G
1. Touch “Delete” on the “My Places”
screen.
4U5103G
2. Touch the touchscreen button to be
deleted.
“Delete All”: To delete all registered areas to
avoid in the system.
3. To delete the area, touch “Yes”. To can-
cel the deletion, touch “No”.

80
— Deleting previous points
The previous destination can be deleted.
4U5108G
1. Touch “Delete Previous Points”.
4U5066G
2. Touch the touchscreen button you
want to delete.
“Delete All”: To delete all previous points in
the system.
4U5067G
3. To delete the point, touch “Yes”. To
cancel the deletion, touch “No”.
Setup
Setting the items shown on the “Setup”
screen can be done. (See page ix.)
1. Push the “MENU” button.
4U5024aG
2. Touch “Setup”.

81
4U5087G
3. Touch the items to be set.
4. Touch “OK”.
The previous screen will be displayed.
INFORMATION
To reset all setup items, touch “Default”.
Distance unit
Distance unit can be changed.
1. Touch “Setup” on the “Menu” screen.
4U5090G
2. Touch “km” or “miles” of “Distance” to
choose the distance unit.
The selected button is highlighted.
3. Touch “OK”.
INFORMATION
This function is available only in English
or Spanish. To switch language, see
“Select language” on page 148.
Estimated travel time
The speed that is used for the calculation of
the estimated travel time and the estimated
arrival time can be set.
1. Touch “Setup” on the “Menu” screen.
4U5091G
2. Touch “Set Speed” of the “Estimated
Travel Time”.

82
4U5069G
3. Touch or to set the average ve-
hicle speeds for “Residential”, “Main
street”, and “Freeway”.
To set the default speeds, touch “Default”.
4. After setting of the desired speeds is
completed, touch “OK”.
INFORMATION
The displayed time to the destination
is the approximate driving time that is
calculated based on the selected
speeds and the actual position along
the guidance route.
The time shown on the screen may
vary greatly depending on progress
along the route, which may be af-
fected by road conditions such as
traffic jams, and construction work.
It is possible to display up to 99 hours
59 minutes.
Input key layout
Key layout can be changed.
1. Touch “Setup” on the “Menu” screen.
4U5092G
2. Touch “ABC” or “QWE” of “Keyboard
Layout” to choose the Input key layout.

83 LAYOUT TYPE
4U5070G
“ABC” type
4U5071G
“QWE” type
The selected button is highlighted.
3. Touch “OK”.
Time zone
Time zone can be changed.
1. Touch “Setup” on the “Menu” screen.
4U5093G
2. Touch “Change” of “Time Zone”.
The “Adjust Time Zone” screen will be dis-
played on the display.
4U5072G
3. Touch the desired time zone.
The selected button is highlighted.
“Daylight Saving Time”: Daylight saving
time can be set or cancelled.
To set daylight saving time, touch “ON”, and
to cancel it, touch “OFF”.
4. Touch “OK”.
