2007 SUBARU IMPREZA roof

10
Illustrated index &Exterior1) Engine hood (page 11-4)
2) Headlight switch (page 3-22)
3) Replacing bulbs (page 11-45)
4) Wiper switch (page 3-27)
5) Moonroof (page 2-24)
6) Door locks (page 2-4)
7) Tire pressure (page 11-31)
8) Flat tires (page 9-4)
9) Tire chains (page 8-11)
10) Front fog light button (page 3-26)
11) Tie-down hooks (page 9-11)
12) Towing hook (page 9-11)

1) Rear window defogger button(page 3-29)
2) Fuel filler lid and cap (page 7-4)
3) Child safety locks (page 2-18)
4) Tie-down/Towing hook (page 9-12)
5) Trunk (page 2-20)
6) Rear gate (page 2-23)
7) Roof rail (page 8-14) 11
– CONTINUED –

12 &Interior
! Passenger compartment area
1) Lower anchorages for child restraint
system (page 1-29)
2) Seatbelt (page 1-9)
3) Moonroof (page 2-24)
4) Parking brake lever (page 7-24)
5) Front seat (page 1-2)
6) Rear seat (page 1-6)

!Anchorage location
! Sedan
1) For left seat
2) For center seat
3) For right seat
Three upper anchorages are installed on the rear shelf behind the rear seat. !
Wagon1) For left seat
2) For center seat
3) For right seat
There is an anchorage for the center seating position at the rear edge of the
roof, and anchorages for each of the two
window-side seating positions on the rear
wall of the cargo area. !
To hook the top tether
! Sedan
1. Attach the child restraint top tether
hook to the appropriate upper anchorage.
2. Tighten the top tether securely.
Please contact your SUBARU dealer if
you have any question regarding the
installation of a child restraint system. Seat, seatbelt and SRS airbags
1-33
– CONTINUED –

1-50Seat, seatbelt and SRS airbags
to deploy if the vehicle is struck from the
side or from behind, or if it rolls onto its
side or roof, or if it is involved in a low-
speed frontal collision.
1) First impact
2) Second impact
In an accident where the vehicle is
impacted more than once, the driver ’s
and/or front passenger ’s SRS frontal
airbag(s) will deploy only once on the firstimpact.
Example: In the case of a double collision,
first with another vehicle, then against a
concrete wall in immediate succession,
once either or both of the driver ’s and front
passenger ’s SRS frontal airbags is/are
activated on the first impact, it/they will not
be activated on the second impact. &
SRS side airbag
The SRS side airbag is stored in the door
side of each front seat seatback, which
bears an “SRS AIRBAG ”label.
In a moderate to severe side impact
collision, the SRS side airbag on the
impacted side of the vehicle deploys
between the occupant and the door panel
and supplements the seatbelt by reducing
the impact on the occupant ’s chest and
head.
WARNING
The SRS side airbag is designed as
only a supplement to the primary
protection provided by the seatbelt.
They do not do away with the need
to fasten seatbelts. It is also impor-
tant to wear your seatbelt to help
avoid injuries that can result when
an occupant is not seated in a
proper upright position.
WARNING
Do not sit or lean unnecessarily
close to either front door. The SRS
side airbag is stored in both front
seat seatbacks next to the door, and
it provides protection by deploying
rapidly (faster than the blink of an
eye) in the event of a side impact
collision. However, the force of SRS
side airbag deployment may cause
injuries if your head or other parts of
the body are too close to the SRS
side airbag.

1-54Seat, seatbelt and SRS airbags
! Examples of the types of accidents in which the SRS side airbag is unlikely to
deploy.
1) The vehicle is involved in an oblique
side-on impact.
2) The vehicle is involved in a side-on impact in an area outside the vicinity of
the passenger compartment.
3) The vehicle strikes a telephone pole or similar object.
4) The vehicle is involved in a side-on impact from a motorcycle.
5) The vehicle rolls onto its side or roof.
There are many types of collisions which
might not necessarily require SRS side
airbag deployment. In the event of acci-
dents like those illustrated, the SRS side
airbag may not deploy depending on the
level of accident forces involved.

Keys..................................................................... 2-2
Key number plate ................................................ 2-2
Immobilizer (Turbo models) ................................ 2-3
Security ID plate .................................................. 2-3
Security indicator light ........................................ 2-4
Key replacement ................................................. 2-4
Door locks ........................................................... 2-4
Locking and unlocking from the outside .. ............ 2-4
Locking and unlocking from the inside ................ 2-5
Key lock-in prevention function ........................... 2-5
Power door locking switches ............................. 2-6
Remote keyless entry system ............................ 2-7
Locking the doors ............................................... 2-7
Unlocking the doors ............................................ 2-8
Illuminated entry ................................................. 2-8
Vehicle finder function ......................................... 2-8
Sounding a panic alarm ....................................... 2-8
Selecting audible signal operation ....................... 2-8
Replacing the battery .......................................... 2-9
Replacing lost transmitters ................................. 2-10
Alarm system ..................................................... 2-13
System operation ............................................... 2-13 Activating and deactivating the alarm system
..... 2-13
If you have accidentally triggered the alarm system ............................................................ 2-14
Arming the system ............................................ 2-14
Disarming the system ........................................ 2-15
Valet mode ........................................................ 2-16
Passive arming .................................................. 2-16
Tripped sensor identification .............................. 2-17
Shock sensors (dealer option).. .......................... 2-17
Child safety locks .............................................. 2-18
Windows ............................................................. 2-18
Power windows ................................................. 2-18
Trunk lid (Sedan) ............................................... 2-20
To open and close the trunk lid from outside . ..... 2-21
To open the trunk lid from inside. ....................... 2-21
To cancel the trunk lid release . .......................... 2-21
Internal trunk lid release handle ......................... 2-21
Rear gate (Wagon) ............................................. 2-23
Moonroof (if equipped) ...................................... 2-24
Tilt function ....................................................... 2-24
Sliding function ................................................. 2-25
Sun shade ......................................................... 2-26 Keys and doors
2

2-14Keys and doors
“ AL oF ”and the horn sounds twice,
indicating that the system is now deacti- vated.
If the system was previously deactivated:
The odometer/trip meter screen displays “ AL on ”and the horn sounds once,
indicating that the system is now acti- vated. NOTE
You may have the above setting
change done by your SUBARU dealer. & If you have accidentally trig-
gered the alarm system
! To stop the alarm
Do any of the following operations: . Press any button on the remote trans-
mitter.. Cycle the ignition switch from the
“ LOCK ”to “ON ”position three times within
5 seconds. & Arming the system
! To arm the system using remote transmitter
1. Close all windows and the moonroof (if
so equipped).
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and
the trunk lid) are locked.
5. Close all doors (and the rear gate on
the Wagon).
: Press to Arm the system.: Press to Disarm the system.
Security indicator light
6. Briefly press the “
”button (for less
than 2 seconds). All doors (and the rear
gate on the Wagon) will lock, an electronic
chirp will sound once, the turn signal lights
will flash once, and the indicator lights will
start flashing rapidly. After rapid flashing
for 30 seconds (standby time), the indi-
cator lights will then flash slowly (twice
approximately every 2 seconds), indicat-
ing that the system has been armed for surveillance.
If any of the doors, (rear gate or trunk lid)
is not fully closed, an electronic chirp
sounds five times, the turn signal lights
flash five times to alert you that the doors
(or the rear gate) are not properly closed.
When you close the door, the system will
automatically arm and doors will automa-
